基于核磁共振干湿循环影响下土壤斥水性分析

李同海; 赵仕

doi:10.19720/j.cnki.issn.1005-9369.2021.06.007

基于核磁共振干湿循环影响下土壤斥水性分析

李同海¹,
赵仕²

1. 中铁十七局集团有限公司;
2. 华南理工大学土木与交通学院

基金项目:

国家自然科学基金项目(51909095)

详细信息

作者简介:
李同海(1974-),男,高级工程师,研究方向为路基工程及土壤渗流特性。E-mail:yang_jy2016@163.com

中图分类号: S152.7
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 刊出日期: 2021-06-24

Analysis on soil water repellency under influence of dry-wet cycle based on NMR

LI Tong-hai¹,
ZHAO Shi²

1. China Railway 17th Bureau Group Co., Ltd.;
2. School of Civil Engineering and Transportation, South China University of Technology

摘要

摘要: 为探究干湿循环对土壤斥水性的影响,揭示斥水性随含水率变化内在机理,测定1～3次干湿循环过程中水滴穿透时间（WDPT）和不同含水率土壤核磁共振（T₂）曲线,建立孔隙水分布与WDPT内在联系。结果表明,随土壤含水率增加,WDPT值先增后减;相同含水率下,吸湿过程WDPT值略高于脱湿过程;1次循环后,土壤斥水性出现大幅衰减（减小65%以上）。含水率减小,T₂曲线积分面积和峰值均随之减小;含水率低于17.1%时,T₂曲线最大值明显减小。研究发现,干湿循环不会改变土壤斥水性对含水率的依赖;给定相对湿度下,孔径大于临界孔径rC的孔隙水同时开始蒸发,较大孔隙内水首先蒸发;孔隙内"填充气"变化是导致土壤斥水性对含水率依赖的主要原因。
- 干湿循环 /
- 斥水性 /
- 核磁共振 /
- “填充气”
Abstract: This study explored the effect of dry-wet cycle on soil water repellency, and revealed the internal mechanism of water repellency changing with water contents. The water drop penetration time（WDPT） during 1-3 dry-wet cycle was tested, and the change law of soil water repellency in the process of drying and wetting was analyzed; the T2 curve of specimen under different water contents in drying process was also measured to establish the internal relationship between pore water distribution and WDPT. The results showed that the WDPT of soil first increased and then decreased with the increase of water content; under the same water content, the WDPT during the moisture absorption process was slightly higher than that during the dehumidification process; the soil water repellency decreased significantly（more than 65%） after one cycle. The integral area and peak value of T2 curve decreased with the decrease of water content; the maximum value of T2 curve decreased significantly when the water content was less than 17.1%. This study found that dry-wet cycle did not change the dependence of soil water repellency on water content; at a certain relative humidity, the evaporation of water in the pore with pore size larger than rCoccurred simultaneously, but the water in the larger pores finished this evaporation first. The change of "filling gas" was the main reason that caused the dependence of soil water repellency on moisture content.
- dry-wet cycle /
- soil water repellency /
- nuclear magnetic resonance（NMR） /
- "filling gas"

HTML全文

参考文献(21)

[1]	Czachor H, Doerr S H, Lichner L. Water retention of repellent and subcritical repellent soils:New insights from model and experimental investigations[J]. Journal of Hydrology, 2010, 380:104-111.
[2]	Bombino G, Andiloro S, Folino A, et al. Short-term effects of olive oil mill wastewater application on soil water repellency[J].Agricultural Water Management, 2021, 244:1-10.
[3]	李进前,王起才,张戎令,等.膨胀土增湿过程中膨胀规律的试验研究[J].水利水运工程学报, 2018(3):86-94.
[4]	Renáta S, Massimo I, Lubomir L, et al. Impact of climate, soil properties and grassland cover on soil water repellency[J]. Geoderma, 2021, 383:1-15.
[5]	Subedi S, Kawamoto K, Komatsu T, et al. Contact angles of waterrepellent porous media inferred by tensiometer-TDR probe measurement under controlled wetting and drying cycles[J]. Soil Science Society of America Journal, 2013, 27:1944-1954.
[6]	Lourengo S D N, Wakefield C F, Morley C P, et al. Wettability decay in an oil-contaminated waste-mineral mixture with drywet cycles[J]. Environmental Earth Science, 2015, 74:2563-2569.
[7]	杨松,吴珺华,黄剑峰.表面张力与接触角对膨胀土干缩开裂影响的试验研究[J].岩土工程学报, 2017, 39(9):1645-1652.
[8]	Dekker L W, Ritsema C J. Wetting patterns and moisture variability in water repellent Dutch soils[J]. Journal of Hydrology, 2000,(231-232):148-164.
[9]	李毅,商艳玲,李振华,等.土壤斥水性研究进展[J].农业机械学报, 2012, 43(1):68-75.
[10]	陈俊英,吴普特,张智韬,等.土壤斥水性对含水率的响应模型研究[J].农业机械学报, 2012, 43(1):63-67, 82.
[11]	GB/T50123-2019.土工试验方法标准[S].北京:中国计划出版社, 2019.
[12]	Conte P, Stefano C D, Ferro V, et al. Assessing hydrological connectivity inside a soil by fast-field-cycling nuclear magnetic resonance relaxometry and its link to sediment delivery processes[J].Environmental Earth Sciences, 2017, 76:526.
[13]	刘勇健,李彰明,郭凌峰,等.基于核磁共振技术的软土三轴剪切微观孔隙特征研究[J].岩石力学与工程学报, 2018, 37(8):1924-1932.
[14]	Testamanti M N, Rezaee R. Determination of NMR T2cut-off for clay bound water in shales:A case study of carynginia formation,Perth Basin, Western Australia[J]. Journal of Petroleum Science and Engineering, 2017, 149:497-503.
[15]	范宜仁,刘建宇,葛新民,等.基于核磁共振双截止值的致密砂岩渗透率评价新方法[J].地球物理学报, 2018, 61(4):1628-1637.
[16]	叶万军,吴云涛,杨更社,等.干湿循环作用下古土壤细微观结构及宏观力学性能变化规律研究[J].岩石力学与工程学报,2019, 38(10):2126-2137.
[17]	宋勇军,张磊涛,任建喜,等.基于核磁共振技术的弱胶结砂岩干湿循环损伤特性研究[J].岩石力学与工程学报, 2019, 38(4):825-831.
[18]	杨松,马泽慧,王磊,等.躺滴法测量干湿循环条件下土壤固-液接触角的滞后特性[J].农业工程学报, 2018, 34(2):114-119.
[19]	杨松,王磊,周明凯,等.干湿循环对土壤斥水性的影响[J].土壤, 2019, 51(6):1196-1201.
[20]	中国国家标准化管理委员会. GB/T 21650. 1-2008压汞法和气体吸附法测定固体材料孔径分布和孔隙度,第1部分:压汞法[S].北京,中国标准出版社, 2008.
[21]	王小虎,彭宇,吉克尼都,等.压汞后水泥基材料的孔隙结构变化[J].硅酸盐学报, 2019, 47(11):1521-1526.
