基于割线模量的散体材料桩复合地基沉降计算

李传勋; 刘聪

基于割线模量的散体材料桩复合地基沉降计算

李传勋,
刘聪

江苏大学土木工程与力学学院

基金项目:

国家自然科学基金资助项目(42377183)

详细信息

作者简介:
李传勋(1978—),男,吉林榆树人,教授,博士生导师(lichuanxun@yeah.net),主要从事岩土工程的研究;刘聪(1995—),男,江苏徐州人,硕士研究生(lc10044001@163.com),主要从事复合地基的研究

中图分类号: TU433
计量
- 文章访问数: 18
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2022-03-13
- 刊出日期: 2024-07-09

Settlement calculation of stone columns-improved composite foundation based on secant modulus

Faculty of Civil Engineering and Mechanics, Jiangsu University

摘要

摘要: 基于土体侧限条件下的应力-应变关系曲线均为双曲线的现象，且应用割线模量计算土体的竖向应变更有助于实现程序计算，首先利用土体割线模量与压缩指数和压缩模量的关系，得到桩周土体割线模量的确定方法.在此基础上，基于等应变假设条件得到考虑土体非线性压缩的桩土应力比，并提出改进的应力修正法和复合模量法，以实现散体材料桩复合地基非线性沉降计算.最后结合模型试验和实际工程算例，对2个改进的沉降计算方法开展验证分析.研究结果表明：室内模型试验中，改进的应力修正法和复合模量法的沉降计算值与试验值误差均小于1.00 mm,表明改进的沉降计算方法具有一定的可靠性；实际工程算例中，改进的复合模量法计算值与实测值间误差为8.70%,远小于JGJ 79—2012《建筑地基处理技术规范》中规定的复合模量法误差(55.06%),改进的应力修正法计算值与实测值误差为8.73%,远小于JGJ 79—2012中规定的应力修正法误差(55.11%).对比分析表明，改进的沉降计算方法优于JGJ 79—2012中的复合模量法和应力修正法，且改进方法计算值更接近实测值，说明改进方法具有更好的可靠性和适用性.
- 复合地基 /
- 散体材料桩 /
- 沉降计算 /
- 复合模量法 /
- 应力修正法
Abstract: The stress-strain relationship of soils under confining conditions is hyperbolic. In this case, secant modulus can be adopted to calculate the vertical strain of soils, which is helpful to realize the settlement calculation. The secant modulus of the soil around stone columns was determined according to the relationship between the secant modulus and the compression index and compression modulus. The column-soil stress ratio considering the nonlinear compressibility of soils was proposed based on the assumption of equal strain, and the improved stress correction method and composite modulus method for nonlinear settlement calculation of composite foundations with stone columns were further provided. The two improved methods for the settlement calculation were verified by the model test and actual project. The results show that for the laboratory model test, the differences between the measured results and the calculated results by the improved composite modulus method and modified stress correction method are less than 1.00 mm, which indicates that the improved method for settlement calculation is reliable. For the actual project, the error between the improved composite modulus method and the measured results is 8.70%, which is less than the specified error of 55.06% by the composite modulus method in the JGJ 79—2012. The error between the improved stress correction method and the measured results is 8.73%, which is less than the specified error of 55.11% by the stress correction method in the JGJ 79—2012. The comparative analysis shows that the improved settlement calculation method is better than the composite modulus method and stress correction method in the JGJ 79—2012, and the calculated results by the improved method are closer to the measurement results, which indicates that the improved method has better reliability and applicability.
- composite foundation /
- stone columns /
- settlement calculation /
- composite modulus method /
- stress correction method

HTML全文

参考文献(16)

[1]	魏汝龙.整理压缩试验资料的一种新方法[J].水利水运科学研究,1980,11(3):90-93.WEI R L.A new method for sorting and compressing test data[J].Journal of Nanjing Hydraulic Research Institute,1980,11(3):90-93.(in Chinese)
[2]	杨光华.现代地基设计理论的创新与发展[J].岩土工程学报,2021,43(1):1-18.YANG G H.Innovation and development of modern theo-ries for foundation design[J].Chinese Journal of Geotechnical Engineering,2021,43(1):1-18.(in Chinese)
[3]	孔洋,阮怀宁,黄雪峰.黄土丘陵沟壑区压实回填土地基沉降计算方法[J].岩土工程学报,2018,40(增刊1):218-223.KONG Y,RUAN H N,HUANG X F.Method for calculating foundation settlement of compacted backfill in hilly and gully regions of loess[J].Chinese Journal of Geotechnical Engineering,2018,40(Sup1):218-223.(in Chinese)
[4]	杨晶,白晓红.压实黄土非线性压缩应力-应变关系在地基沉降计算中的应用[J].岩土力学,2015,36(4):1002-1008.YANG J,BAI X H.Nonlinear compression stress-strain relationship of compacted loess and its application to calculation of foundation settlement[J].Rock and Soil Mechanics,2015,36(4):1002-1008.(in Chinese)
[5]	王伟,宰金珉,卢廷浩.软土工后沉降双曲线模型与指数曲线模型分析[J].江苏大学学报(自然科学版),2008,29(2):173-176.WANG W,ZAI J M,LU T H.Analysis on hyperbolic model and exponential model for post-construction settlement of soft soil[J].Journal of Jiangsu University (Na-tural Science Edition),2008,29(2):173-176.(in Chinese)
[6]	刘保健,张军丽.土工压缩试验成果分析方法与应用[J].中国公路学报,1999,12(1):37-41,100.LIU B J,ZHANG J L.Application and analysing method for soil compression test[J].China Journal of Highway and Transport,1999,12(1):37-41,100.(in Chinese)
[7]	李广信,张丙印,于玉贞.土力学[M].3版.北京:清华大学出版社,2022.
[8]	HOSSEINPOUR I,ALMEIDA M S S,RICCIO M.Full-scale load test and finite-element analysis of soft ground improved by geotextile-encased granular columns[J].Geosynthetics International,2015,22(6):428-438.
[9]	姚宝宽,刘聪,李全军,等.真空井点降水、挤密砂桩联合浅层强夯在软基处理中的应用[J].地基处理,2021,3(2):118-125.YAO B K,LIU C,LI Q J,et al.Application of vacuum well point dewatering and sand compaction pile combined with dynamic compaction method in soft foundation treatment[J].Journal of Ground Improvement,2021,3(2):118-125.(in Chinese)
[10]	张玲,张旭波,徐泽宇,等.基于辛体系的筋箍碎石桩受力变形分析[J].岩土工程学报,2020,42(11):2040-2049.ZHANG L,ZHANG X B,XU Z Y,et al.Stress and deformation analysis of geosynthetic-encased stone columns based on symplectic system[J].Chinese Journal of Geotechnical Engineering,2020,42(11):2040-2049.(in Chinese)
[11]	孙林娜,龚晓南.散体材料桩复合地基沉降计算方法的研究[J].岩土力学,2008,29(3):846-848.SUN L N,GONG X N.Research on settlement calculation method of composite foundation of discrete material piles[J].Rock and Soil Mechanics,2008,29(3):846-848.(in Chinese)
[12]	张玲,赵明华.考虑鼓胀变形的散体材料桩复合地基沉降计算[J].湖南大学学报(自然科学版),2016,43(5):120-124.ZHANG L,ZHAO M H.Settlement calculation of granular material pile composite foundation with consideration of lateral bulging[J].Journal of Hunan University (Nature Science),2016,43(5):120-124.(in Chinese)
[13]	余震,张玉成,张玉平.振冲碎石桩加固软土地基试验研究[J].重庆建筑大学学报,2007,29(6):57-61.YU Z,ZHANG Y C,ZHANG Y P.Test study on vibro replacement stone columns to improve soft soil foundation[J].Journal of Chongqing Jianzhu University,2007,29(6):57-61.(in Chinese)
[14]	曹文贵,刘海涛,张永杰.散体材料桩复合地基桩土应力比计算新方法[J].湖南大学学报(自然科学版),2009,36(7):1-5.CAO W G,LIU H T,ZHANG Y J.A new pile-soil stress ratio calculation method of composite foundation with friable material piles[J].Journal of Hunan University (Nature Science),2009,36(7):1-5.(in Chinese)
[15]	徐龙飞.黄土地区复合地基承载机理室内模型试验研究[D].西安:西北农林科技大学,2014.
[16]	HOSSEINPOUR I,RICCIO M,AIMEIDA M S S.Numerical evaluation of a granular column reinforced by geosynthetics using encasement and laminated disks[J].Geotextiles and Geomembranes,2014,42:363-373.
