Whole-Genome Sequencing and Analysis of Lonsdalea populi Causing Poplar Canker
-
摘要: 欧美杨细菌性溃疡病菌(Lonsdalea populi)是引起杨树溃疡病的主要病原菌,它可引起树干形成层的破坏和树皮的局部坏死。为挖掘其致病基因,本研究利用二代和三代测序技术对欧美杨细菌性溃疡病菌N-5-1进行了全基因组测序。结果表明:该病菌菌株染色体和质粒大小分别为3 832 567 bp和11 289 bp, GC含量分别为55.42%和56.32%。通过对基因组的分析,共预测到3 556个基因,在GO、KEGG和COG数据库分别注释到2 348个、2 785个和2 374个基因。进一步利用Ⅲ型分泌系统数据库注释到501个编码分泌蛋白的基因,在病原互作数据库中注释到了427个病原与宿主互作的基因,其中13个为效应子基因。通过与Lonsdalea属的其他病原菌的基因组进一步比较发现,菌株Lonsdalea populi N-5-1的基因组与Lonsdalea iberica LMG 26264和Lonsdalea populi L2-3的基因组存在良好的共线性关系,且与Lonsdalea populi L2-3的亲缘关系更近。本研究为解析欧美杨细菌性溃疡病菌的基因组结构、功能及亲缘关系提供了科学基础,并为后续深入研究其致病基因及开展树木抗病分子育种提供了基因组信息和基因资源。
-
关键词:
- 欧美杨细菌性溃疡病菌 /
- 全基因组测序 /
- 比较基因组学 /
- 杨树 /
- 溃疡病
Abstract: Lonsdalea populi is one of the major pathogenic bacteria causing poplar canker. It can cause the destruction of the cambium in trunks and local necrosis of the bark. In order to explore the pathogenic genes, the complete genome of Lonsdalea populi N-5-1 was sequenced and assembled in this investigation. Results showed that L. populi N-5-1 carries a chromosome of 3 832 567 bp with 55.42% GC and a plasmid of 11 289 bp with 56.32% GC. Through genomic analysis, 3 556 genes were predicted, and 2 348, 2 785, and 2 374 genes were annotated in the GO, KEGG and COG databases, respectively. 501 genes encoding type Ⅲ secreted protein were found using T3 SS database. 427 genes involved in pathogen-host interaction were annotated using PHI database, including 13 genes encoding effectors. After being compared with other pathogens in the Lonsdalea genus, the genome of L. populi N-5-1 strain was found to have a good synteny with those of Lonsdalea iberica LMG 26264 and Lonsdalea populi L2-3, and be more related to that of Lonsdalea populi L2-3. This investigation provides a useful basis for understanding the structure, function and relationship of the genome of Lonsdalea populi, and genomic information and gene resources for the further study of the pathogenic genes and molecular breeding of trees with resistance to pathogens.-
Keywords:
- Lonsdalea populi /
- Whole-genome sequencing /
- Comparative genomics /
- Poplar /
- Canker
-
-
[1] Benson G.,1999,Tandem repeats finder:a program to analyze DNA sequences,Nucleic Acids Res.,27(2):573-580.
[2] Caillaud M.,Asai S.,Rallapalli G.,Piquerez S.,Fabro G.,and Jones J.D.G.,2013,A downy mildew effector attenuates salicylic acid-triggered immunity in Arabidopsis by interacting with the host mediator complex,PLoS Biol.,11(12):e1001732.
[3] Choi Y.,Kim N.,Mannaa M.,Kim H.,Park J.,Jung H.,Han G.,Lee H.H.,and Seo Y.S.,2020,Characterization of type VI tecretion tystem in Xanthomonas oryzae pv.oryzae and its role in virulence to rice,Plant Pathol.,36(3):289-296.
[4] Coulthurst S.J.,2013,The type VI secretion system-a widespread and versatile cell targeting system,Res.Microbiol.,164(6):640-654.
[5] Delcher A.L.,Bratke K.A.,Powers E.C.,and Salzberg S.L.,2007,Identifying bacterial genes and endosymbiont DNA with glimmer,Bioinformatics,23(6):673-679.
[6] Delcher A.L.,Harmon D.,Kasif S.,White O.,and Salzberg S.L.,1999,Improved microbial gene identification with GLIMMER,Nucleic Acids Res.,27(23):4636-4641.
[7] Galperin M.Y.,2006,Structural classification of bacterial response regulators:diversity of output domains and domain combinations,J.Bacteriol.,188(12):4169-4182.
[8] Gardner P.P.,Daub J.,Tate J.G.,Nawrocki E.P.,Kolbe D.L.,Lindgreen S.,Wilkinson A.C.,Finn R.D.,Griffiths-Jones S.,Eddy S.R.,and Bateman A.,2009,Rfam:updates to the RNA families database,Nucleic Acids Res.,37(Database issue):D136-D140.
[9] Guo X.,Luo H.M.,Song J.Y.,Sun C.,and Chen S.L.,2012,Research progress of glycosyltransferase in plant secondary metabolism,World Science and Technology(Modernization of Traditional Chinese Medicine and Materia Medica),14(6):2126-2130.(郭溆,罗红梅,宋经元,孙超,陈士林,2012,糖基转移酶在植物次生代谢途径中的研究进展,世界科学技术(中医药现代化),14(6):2126-2130.) [10] He W.,Ren F.J.,Guo L.M.,Li Y.,and Chang J.P.,2009,Pathogen identification of Populus×euramericana canker disease,Scientia Silvae Sinicae,45(6):104-108.(贺伟,任飞娟,郭利民,李永,常聚普,2009,欧美杨溃疡病的病原鉴定,林业科学,45(6):104-108.) [11] Hung N.B.,Ramkumar G.,and Lee Y.H.,2014,An effector gene hopA1 influences on virulence,host specificity,and lifestyles of Pseudomonas cichorii JBC1.,Res.Microbiol.,165(8):620-629.
[12] Ibarra Caballero J.,Zerillo M.M.,Snelling J.,Cranshaw W.,Boucher C.,and Tisserat N.,2014,Genome sequences of strain ATCC 29281 and pin and northern red oak isolates of Lonsdalea quercina subsp.quercina,Genome Announc.,2(3):e00584-14.
[13] Jones J.D.G.,and Dangl J.L.,2006,The plant immune system,Nature,444(7117):323-329.
[14] Kitaoka M.,Miyata S.T.,Brooks T.M.,Unterweger D.,and Pukatzki S.,2011,VasH is a transcriptional regulator of the type VI secretion system functional in endemic and pandemic Vibrio cholerae,J.Bacteriol.,193(23):6471-6482.
[15] Kurtz S.,Phillippy A.,Delcher A.L.,Smoot M.,Shumway M.,Antonescu C.,and Salzberg S.L.,2004,Versatile and open software for comparing large genomes,Genome Biol.,5(2):R12.
[16] Lagesen K.,Hallin P.,RØdland E.A.,Staerfeldt H.H.,Rognes T.,and Ussery D.W.,2007,RNAmmer:consistent and rapid annotation of ribosomal RNA genes,Nucleic Acids Res.,35(9):3100-3108.
[17] Li A.N.,YANG R.L.,WEI Q.,and He W.,2018,Functional analysis of Orphan LqRR2 gene in Lonsdalea quercina subsp.populi,Acta Phytopathologica Sinica,48(4):492-500 (李爱宁,杨若兰,魏强,贺伟,2018,欧美杨细菌性溃疡病菌双组份系统反应调节基因LqRR2的功能研究,植物病理学报,48(4):492-500.) [18] Li B.,Li A.N.,Wei Q.,Wang H.M.,and He W.,2015,Functional analysis of hrcJ gene in Lonsdalea quercina subsp.populi,Scientia Silvae Sinicae,51(12):71-78 (李宾,李爱宁,魏强,王海明,贺伟,2015,欧美杨细菌性溃疡病菌hrcJ基因的功能分析,林业科学,51(12):71-78.) [19] Li Y.,2013,Fungal and bacterial communities in healthy and canker-infected bark of Populus×euramericana cv.‘74/76’ and P.euramericana cv.‘zhonglin 46’,Dissertation for Ph.D.,Beijing Forestry University,Supervisor:He W.,pp.12-15 (李永,2013,健康与染溃疡病107杨、中林46杨树皮真菌和细菌群落研究,博士学位论文,北京林业大学,导师:贺伟,pp.12-15.) [20] Li Y.,Xue H.,Guo L.M.,Koltay A.,Palacio-Bielsa A.,Chang J.,Xie S.,and Yang X.,2017,Elevation of three subspecies of Lonsdalea quercina to species level:Lonsdalea britannica sp.nov.,Lonsdalea iberica sp.nov.and Lonsdalea populi sp.nov.,Int.J.Syst.Evol.Micr.,67(11):4680-4684.
[21] Lowe T.M.,and Eddy S.R.,1997,tRNAscan-SE:a program for improved detection of transfer RNA genes in genomic sequence,Nucleic Acids Res.,25(5):955-964.
[22] Mattinen L.,Nissinen R.,Riipi T.,Kalkkinen N.,and Pirhonen M.,2007,Host-extract induced changes in the secretome of the plant pathogenic bacterium Pectobacterium atrosepticum,Proteomics,7(19):3527-3537.
[23] McDowell J.M.,2019,Focus on activation,regulation,and evolution of MTI and ETI,Mol.Plant Microbe Interact.,32(1):5.
[24] Ren F.J.,2011,Pathogen identification of populus ×euranmericana canker disease,Thesis for M.S.,Beijing Forestry University,Supervisor:He W.,pp.1-10 (任飞娟,2011,欧美杨溃疡病病原鉴定,硕士学位论文,北京林业大学,导师:贺伟,pp.1-10.) [25] Russell A.B.,Peterson S.B.,and Mougous J.D.,2014,Type VI secretion system effectors:poisons with a purpose,Nat.Rev.Microbiol.,12(2):137-148.
[26] Ryu C.M.,2015,Against friend and foe:type 6 effectors in plant-associated bacteria,J.Microbiol.,53(3):201-208.
[27] Salzberg S.L.,Delcher A.L.,Kasif S.,and White O.,1998,Microbial gene identification using interpolated Markov models,Nucleic Acids Res.,26(2):544-548.
[28] Shan C.L.,2014,Study on the control of rice bacterial brown stripe by regulating vgrG gene of type Ⅵ secretion system,Thesis for M.S.,Zhejiang University,Supervisor:Li B.,pp.20-30 (单长林,2014,调控Ⅵ型分泌系统vgrG基因控制水稻细菌性褐条病,硕士学位论文,浙江大学,导师:李斌,pp.20-30.) [29] Sontag R.L.,Nakayasu E.S.,Brown R.N.,Niemann G.S.,Sydor M.A.,Sanchez O.,Ansong C.,Lu S.Y.,Choi H.,Valleau D.,Weitz K.K.,Savchenko A.,Cambronne E.D.,and Adkins J.N.,2016,Identification of novel host interactors of effectors secreted by Salmonella and Citrobacter,Msystems,1(4):e00032-15.
[30] Soria S.,and Lopez P.M.,1997,Sintomatologiay danos de Erwinia quercina en Espanay surpossible relation conlasecade laencina,Erologa,11:298-301.
[31] Wei Q.,Li A.N.,and He W.,2017,Functional analysis of LqHK1 in Lonsdalea quercina subsp.populi,Scientia Silvae Sinicae,53(4):105-112 (魏强,李爱宁,贺伟,2017,欧美杨细菌性溃疡病菌双组分信号转导系统LqHK1基因的功能,林业科学,53(4):105-112.) [32] Wichmann F.,Vorhölter F.J.,Hersemann L.,Widmer F.,Blom J.,Niehaus K.,Reinhard S.,Conradin C.,and Kölliker R.,2013,The noncanonical type III secretion system of Xanthomonas translucens pv.graminis is essential for forage grass infection,Mol.Plant Pathol.,14(6):576-588.
[33] Winslow C.E.,Broadhurst J.,Buchanan R.E.,Krumwiede C.,Rogers L.A.,and Smith G.H.,1917,The families and genera of the bacteria:preliminary report of the committee of the society of american bacteriologists on characterization and classification of bacterial types,J.Bacteriol.,2(5):505-566.
[34] Yang L.,2013.,Identification and characterization of the pathogenicity-related genes in Lonsdalea quercina N-5-1,Dissertation for Ph.D.,Beijing Forestry University,Supervisor:He W.,pp.12-15 (杨莉,2013,欧美杨溃疡病病菌(Lonsdalea quercina)N-5-1致病相关基因的鉴定与分析,博士学位论文,北京林业大学,导师:贺伟,pp.12-15.) [35] Yang L.,Xu B.,He W.,and Zhang L.,2014,The HrpW protein of Lonsdalea quercina N-5-1 has pectate lyase activity and is required for full bacterial virulence,J.Basic Microb.,54 (10):1126-1135.
[36] Yang R.L.,Deng C.Y.,Wei J.W.,He W.,Li A.N.,and Qian W.,2018,A large-scale mutational analysis of two-component signaling systems of Lonsdalea quercina revealed that KdpD-KdpE regulates bacterial virulence against host poplar trees,Mol.Plant Microbe Interact.,31(7):724-736.
[37] Yu F.H.,Liu C.Y.,Wang H.,Guan T.,Li L.,and Yu S.,2019,Bioinformatic analysis of the complete genome sequence of Pectobacterium carotovorum subsp.brasiliense BZA12 and candidate effector screening,J.Plant Pathol.,101(1):39-49.
[38] Yuan X.,Yu M.,and Yang C.H.,2020,Innovation and application of the type III secretion system inhibitors in plant pathogenic bacteria,Microorganisms,8(12):1956.
[39] Zhang J.,Li W.,Xiang T.,Liu Z.,Laluk K.,Ding X.,Zou Y.,Gao M.,Zhang X.,Chen S.,Mengiste T.,Zhang Y.,and Zhou J.M.,2010,Receptor-like cytoplasmic kinases integrate signaling from multiple plant immune receptors and are targeted by a Pseudomonas syringae effector,Cell Host Microbe,7(4):290-301.
[40] Zhao Z.X.,Wu Z.,and Zhang J.,2016,Crystal structure of the YajQ-family protein XC_3703 from Xanthomonas campestris pv.Campestris,Acta Crystallogra.F,72(Pt 9):720-725.
-
