气吸针式摇摆叶菜精量播种机设计与试验研究

王晨健; 赵倩; 郭文忠; 贾冬冬; 王琨琦; 贾海遥

doi:10.13427/j.cnki.njyi.2021.07.010

气吸针式摇摆叶菜精量播种机设计与试验研究

1. 西安工业大学机电工程学院;
2. 北京农业智能装备技术研究中心

基金项目:

宁夏回族自治区重点研发计划农业农村领域重大项目(2019BBF02010)

陕西省农业科技创新与攻关目(2016NY-149)

陕西省教育厅产业项目(2013JC26)

详细信息

作者简介:
王晨健(1993-),男,西安人,硕士研究生,(E-mail)2470877259@qq.com

通讯作者:
郭文忠(1970-),男,宁夏中卫人,教授,硕士生导师,(E-mail)guowz@nercita.org.cn

中图分类号: S223.2
计量
- 文章访问数: 1
- HTML全文浏览量: 0
- PDF下载量: 2
出版历程
- 收稿日期: 2020-04-22
- 刊出日期: 2021-06-30

Design and Test of Precision Seeding Machine of Air Suction Needle Sowing for Leaf-vegetables

1. College of Mechanical and Electrical Engineering, Xi’an Technology University;
2. Beijing Research Center of Intelligent Equipment for Agriculture

摘要

摘要: 针对叶菜类种子粒径小且无规则形状、传统播种机存在精量化程度不高及播种成功率低等问题。以气吸针式播种方式为基础,设计了一种气吸针式摇摆叶菜精量播种机,并采用笔型气缸将直线往复运动转化为播种机摇摆往复运动来实现气缸运动一次完成两次播种。设计了导种结构代替传统播种机垂直运动方向的机械结构,并加入了振动装置使种子处于高频振动状态,提高种子吸附成功率的同时,也避免了种子间相互粘连。依据叶菜种子的三维尺寸,通过理论计算得出了实现种子吸附的临界气流速度为10.1m/s,且采用仿真软件对播种机核心部件笔型气缸的量程、吸嘴内腔结构和负压分流管的结构进行了确定。搭建了气吸针式摇摆叶菜精量播种试验平台,以负压大小、吸嘴口直径大小、种盘振动强度为试验因素,以漏播率、重播率、单粒率为试验指标,进行三因素三水平正交试验,通过对方差与极差的分析确定了试验因素的最优组合参数,即负压大小-25kPa、吸嘴口直径大小0.6mm、种盘振动强度64Hz;依据此参数组合进行播种验证试验,漏播率为2.75%、重播率为5.5%和单粒率为91.75%,可满足叶菜的精量播种要求,为叶菜精量播种提供了一种新的方法。
- 叶菜 /
- 气吸针式 /
- 精量播种 /
- 仿真 /
- 正交试验
Abstract: For the seeds with small particle size and irregular shape of leafy vegetables, the conventional seeding machine has problems such as low degree of precision and low seeding success rate. Based on the method of air suction needle seeding, this paper designs the air suction needle swing type leaf vegetable precision seeding machine, which uses the linear reciprocating motion of the cylinder is converted into the rotary rocking motion of the seeding machine to realize the cylinder movement ones and complete the seeding twice; designed the mechanical structure of the traditional planter to replace the vertical movement of the seeding machine; added the vibration device to make the seed in high-frequency vibration state, improve the success rate of the adsorption seed, and also reduce the mutual adhesion between the seeds. According to the three-dimensional size of the leaf seed, the critical air flow rate for seed adsorption was 10.1 m/s by theoretical calculation, the range of the pen-shaped cylinder, the structure of the inner cavity of the suction nozzle and the structure of the negative pressure shunt tube were determined using simulation software.Through the construction of the air suction needle swing type leaf vegetable precision seed metering test platform, the negative pressure, the diameter of the nozzle, the vibration intensity of the seed disk were taken as test factors,and the leakage rate, re-broad rate, single-grain rate were used as test indicators. Three-factor and three-level orthogonal tests were carried out.The optimal combination parameters of the test factors are determined by analysis of variance and range the negative pressure is-25 kPa, the diameter of the nozzle is 0.6 mm、the vibration intensity of the seed disc is 64 Hz.According to this parameter combination, seed verification test,the leakage rate is 2.75%,the replay rate is 5.5%, the single grain ratio is 91.75%. It can meet the precision seeding requirements of leafy vegetables, and provides a new method for the precision seeding of leafy vegetables.
- leafy vegetables /
- air suction needle type /
- precision seeding /
- simulation /
- orthogonal test

HTML全文

参考文献(34)

[1]	李辉尚,王晓东,杨唯,等.我国蔬菜市场2017年形势分析与后市展望[J].中国蔬菜,2018(1):7-12.
[2]	胡童,齐新丹,李骅,等.国内外蔬菜播种机的应用现状与研究进展[J].江西农业学报,2018,30(2):87-92.
[3]	许剑平,谢宇峰,徐涛.国内外播种机械的技术现状及发展趋势[J].农机化研究,2011,33(2):234-237.
[4]	贾冬冬.种苗负压气吸夹设计与试验研究[D].哈尔滨:东北农业大学,2014.
[5]	陈爽.气吸式播种机的发展现状与功能特点[J].农机使用与维修,2018(8):100.
[6]	杜佳伟,杨学军,刘立晶,等.小粒种子精量播种机研究现状及发展趋势[J].农业工程,2017,7(6):9-13.
[7]	王敬锋.精量播种机排种部件的技术现状及发展特点[J].农机使用与维修,2018 (10):76.
[8]	B B GAIKWAD,N P S SIROHI.Design of a low-cost pneumatic seeder for nursery plug trays[J].Biosystems engineering,2008,99(3):322-329.
[9]	王波,郭颖杰,杨军.气力式排种器的研究及进展[J].农业与技术,2014,34(3):62-63.
[10]	陈学庚,卢勇涛.气吸滚筒式棉花精量穴播器排种性能试验[J].农业机械学报,2010,41(8):35-38.
[11]	张昆,衣淑娟.气吸滚筒式玉米排种器充种性能仿真与试验优化[J].农业机械学报,2017,48(7):78-86.
[12]	倪向东,徐国杰,王琦,等.气吸滚筒阵列式棉花精密排种器设计与试验[J].农业机械学报,2017,48 (12):58-67.
[13]	高筱钧,周金华,赖庆辉.中草药三七气吸滚筒式精密排种器的设计与试验[J].农业工程学报,2016,32(2):20-28.
[14]	刘中正,侯加林,辛杰,等.智能化设施育苗机设计与试验[J].农业机械学报,2016,47 (S1):136-142.
[15]	赵晓顺,于华丽,张晋国,等.槽缝气吸式小麦精量排种器[J].农业机械学报,2013,44 (02):48-51,74.
[16]	REIS A V D,FORCELLINI F A.Precision mechanical seed meter for small seeds:Functional tests [J].Revista brasileira de engenharia agricolae ambiental,2009:651-656.
[17]	OLIMPIA PANDIA,ION SARACIN,LON BOZGA,et al.Studies regarding pneumatic equipment for sowing small seeds in cups[J].Agriculture and agricultural science,2015(6):690-695.
[18]	杜韧.气针式穴盘播种机吸种吸附性能的研究[C]// 北京理工大学、中国机械工程学会机械设计分会.2017机械设计国际会议暨第19届机械设计学术年会论文集,2017.
[19]	杜韧,王晓臣,齐晓巧.气针式穴盘播种机播种装置的研究[J].北华航天工业学院学报,2014,24(2):1-3.
[20]	廖庆喜,张猛,余佳佳,等.气力集排式油菜精量排种器[J].农业机械学报,2011,42 (8):30-34.
[21]	ChuangRen,Qinghui Lai,Zhaoguo Zhang.Internal Flow field Analysis of air-suction roller-type precision metering device [J].Applied mechanics and materials,2014,3403:84-88.
[22]	张敏,吴崇友,张文毅.吸盘式水稻育秧播种器吸孔气流场仿真分析[J].农业工程学报,2011,27(7):162-167,393.
[23]	陈进,李耀明,王希强,等.气吸式排种器吸孔气流场的有限元分析[J].农业机械学报,2007(9):59-62.
[24]	雷小龙,廖宜涛,张闻宇,等.油麦兼用气送式集排器输种管道气固两相流仿真与试验[J].农业机械学报,2017,48(3):57-68.
[25]	杨明金,邱兵,杨玲,等.振动气吸式精密穴播机的排种性能[J].农业工程学报,2010,26 (9):139-143.
[26]	张石平,陈进,李耀明.振动气吸式穴盘精量播种装置种子群“沸腾”运动分析[J].农业工程学报,2008(7):20-24.
[27]	陈学庚,钟陆明.气吸式排种器带式导种装置的设计与试验[J].农业工程学报,2012,28 (22):8-15.
[28]	张鸿雁,张志政,王元.流体力学[M].北京:科学出版社,2004:156-157.
[29]	赵立新,郑立允,王玉果,等.振动气吸式穴盘播种机的吸种性能研究[J].农业工程学报,2003(4):122-125.
[30]	李耀明,赵湛,陈进,等.气吸振动式排种器种盘内种群运动的离散元分析[J].农业机械学报,2009,40(3):56-59,76.
[31]	任玉新,陈海昕.计算流体力学基础[M].北京:清华大学出版社,2006:1-2.
[32]	庄森,田盈辉,蒋晶,等.真空气吸式播种器吸嘴流场的研究[J].农机化研究,2007(11):83-86.
[33]	程修沛,卢彩云,孟志军,等.气吸型孔组合式小麦精密排种器设计与参数优化[J].农业工程学报,2018,34(24):1-9.
[34]	廖宜涛,廖庆喜,王磊,等.气力式小粒径种子精量排种器吸种效果影响因素研究[J].农业工程学报,2018,34(24):10-17.
