基于土壤植被水文模型的县域夏收作物渍害风险评估

熊勤学

doi:10.11975/j.issn.1002-6819.2015.21.023

基于土壤植被水文模型的县域夏收作物渍害风险评估

熊勤学

1. 长江大学农学院，荆州 434025;
2. 主要粮食作物产业化湖北省协同创新中心，荆州 434025

基金项目: 公益性行业（农业）科研专项项目（201203032）

计量
- 文章访问数: 2262
- HTML全文浏览量: 0
- PDF下载量: 794
出版历程
- 收稿日期: 2015-06-08
- 修回日期: 2015-07-28
- 发布日期: 2015-10-31

Risk evaluation of sub-surface waterlogging of summer crops based on DHSVM model on county scale

Xiong Qinxue

1. College of Agriculture, Yangtze University, JinZhou 434025, China;
2. Hubei collaborative Innovation Center for Grain Industry, JinZhou 434025, China

摘要

摘要: 为开展县级渍害风险评估与区划，该文利用分布式土壤植被水文模型（distributed hydrology soil vegetation model, DHSVM），以天为步长模拟1970年至2014年每年夏收作物生长期（3月、4月）的土壤表层水分的空间分布，结合夏收作物渍害水分指标，分析监利县各区域受渍害情况，进一步得到监利县夏收作物受渍害情况的空间分布，其中无渍害区、轻度渍害区、中度渍害区和重度渍害区分别占监利县农田面积的2.7%、55.7%、26.5%和15.1%。该研究结果为监利县渍害精准治理、农作物产业结构调整与规划提供了基础数据。
- 模型 /
- 水分 /
- 作物 /
- DHSVM模型 /
- 渍害 /
- 风险区划
Abstract: Abstract: Sub-surface waterlogging is one of the main agricultural meteorological disasters affecting summer crops in Jianli County, Hubei Province, China. For sub-surface waterlogging is caused by the long-term influence of high soil moisture on crops, it is not easily identified. Few studies were found on the risk evaluation and zonation of crops injured by sub-surface waterlogging. The researchers of this paper firstly adjusted the parameters of DHSVM (distributed hydrology soil vegetation model) by using soil moisture data collected from February 13 to May 20 in 2014 and verified it with the data collected from May 25 to September 23 in 2014. The result showed that the DHSVM could be used to simulate the soil moisture changes in Jianli County. Based on this model, the influencing parameters of waterlogging injury were input, which included meteorology, soil physical properties, groundwater levels, topography, drainage and irrigation conditions, and the farming system. Then the spatial distributions of soil surface moisture were simulated using the DHSVM with a step of 24 h during the growth seasons (March and April) of summer crops from 1970 to 2014. Also the waterlogging moisture indicators were also used to analyze the injury times of each grid in Jianli County (waterlogging injury occurs when the water level is less than 60 cm and surface soil moisture is higher than 95% of soil saturation for 5 days), and the spatial resolution was 90 m. In this way, the spatial distribution of the sub-surface waterlogging injured ratio (SWIR) was calculated, as well as the indicator of the degree of sub-surface waterlogging injury. According to the different range of SWIR value, the research areas which were at the risk of the sub-surface waterlogging injury, were consequently classified into 4 grades: the severe damage zone (SWIR greater than or equal to 0.6), the moderate damage zone (SWIR greater than or equal to 0.3 and less than 0.6), the mild damage zone (SWIR greater than or equal to 0.1 and less than 0.3), and the damage-free zone (SWIR less than 0.1). Thus the zonation of sub-surface waterlogging injury of summer crops was mapped. With some risk evaluation of each zone, the zonation conformed to the actual situation. Since the method used in this paper is based on the model and all the damage factors are taken into account, it is more accurate than the division only using the meteorological elements and proved to be an applicable method for the zonation of sub-surface waterlogging injury on the county scale.
- models /
- moisture /
- crops /
- DHSVM model /
- sub-surface waterlogging /
- risk evaluation and zonation

HTML全文

参考文献(29)

[1]	朱建强. 易涝易渍农田排水应用基础研究[M]. 北京：科学出版社，2007.
[2]	蔡述明，王学雷，黄进良，等. 江汉平原四湖地区区域开发与农业持续发展[M]. 北京：科学出版社，1996：28－64.
[3]	吴洪颜，高苹，徐为根，等. 江苏省冬小麦湿渍害的风险区划[J]. 生态学报，2012，32(6)：1871－1879.Wu Hongyan, Gao Ping, Xu Weigeng, et al. Risk division on winter wheat suffering from spring wet damages in Jiangsu Province[J]. Acta Ecologica Sinica, 2012, 32(6): 1871－1879. (in Chinese with English abstract)
[4]	盛绍学，石磊，张玉龙. 江淮地区冬小麦渍害指标与风险评估模型研究[J]. 中国农学通报，2009，25(19)：263－268.Sheng Shaoxue, Shi Lei, Zhang Yulong. Study on waterlogging disaster Index and risk assessment model of winter wheat in Jianghuai region[J]. Chinese Agricultural Science Bulletin 2009, 25(19): 263－268. (in Chinese with English abstract)
[5]	Chowdary V M , Chandran R Vi, Neeti N, et al. Assessment of surface and sub-surface waterlogged areas in irrigation command areas of Bihar state using remote sensing and GIS[J]. Agricultural Water Management, 2008, 95(10): 754－766.
[6]	Singh A. Groundwater modeling for the assessment of water management alternatives[J]. Journal of Hydrology, 2013, 481(2): 220－229.
[7]	Singh A. Validation of SaltMod for a semi-arid part of northwest India and some options for control of waterlogging[J]. Agricultural Water Management, 2012, 115(1): 194－202.
[8]	Groundwater Cell. Groundwater Atlas of Rohtak District[R]. Rohtak, Haryana, India: Department of Agriculture, 2008.
[9]	Singh A, Panda, S N, Flugel W A, et al. Waterlogging and farmland salinization: Causes and remedial measures in an irrigated semi-arid region of India[J]. Irrigation and Drainage, 2012, 61(3): 357－365.
[10]	Singh A, Panda S. Integrated salt and water balance modeling for the management of waterlogging and salinization. I: validation of SAHYSMOD[J]. Journal of Irrigation and Drainage Engineering, 2012, 138(11): 955－963.
[11]	Singh A, Panda S. Integrated salt and water balance modeling for the management of waterlogging and salinization. II: application of SAHYSMOD[J]. Journal of Irrigation and Drainage Engineering, 2012, 138(11): 964－971.
[12]	Band L E. Topographic partition of watersheds with digital elevation models[J]. Water Resources Research, 1986(2): 15－24.
[13]	Wigmosta M S, VailLW, Lettenamaier D P. A distributed hydrological-vegetation model for complex terrain[J]. Water Resource Research, 1994, 30(6): 1665－1679.
[14]	Wigmosta M S, Nijssen B, Storck P. The distributed hydrological soil vegetation model[C]. Mathematical Models of Small Watershed Hydrological and Applications. Sigh V P: Department of Civil and Environment Engineering Louisiana State University, Water Resource Publications, LLC, 2002.
[15]	郝振纯，梁之豪，梁丽乔，等. DHSVM模型在宝库河流域的径流模拟适用性分析[J]. 水电能源科学，2012(30)：119－129.Hao Zhenchun, Liang Zhihao, Liang Liqiao, et al. Adaptablity analysis of DHSVM model in runoff simulation of BaoKu river basin[J]. Water Resources and Power, 2012(30): 119－129. (in Chinese with English abstract)
[16]	王守荣，黄荣辉，丁一汇. 分布式水文-土壤-植被模式的改进及气候水文off-line模拟试验[J]. 气象学报，2002，60(3)：290－300.Wang Shourong, Huang Ronghui, Ding Yihui. Improvements of a distributed hydrology model DHSVM and its climatological hydrological offline simulation experiments[J] ACTA Meteorological Sinica, 2002, 60(3): 290－300. (in Chinese with English abstract)
[17]	康丽莉，王守荣，顾骏强. 分布式水文模型DHSVM对兰江流域径流变化的模拟试验[J]. 热带气象学报，2008，24(2)：176－182.Kang Lili, Wang Shourong, Gu Junqiang. The simulation test of the distributed hydrological model DHSVM on the runoff change of LanJiang river basin[J]. Journal of Tropical Meteorology, 2002, 60(3): 290－300. (in Chinese with English abstract)
[18]	Wigmosta M S, Perkins W A. Simulating the effects of forest roads on watershed hydrology[C]. Wigmosta M.S, Burges S J. Influence of urban and forest land use on the hydrologic geomorphic responses of watersheds, American Geophysical Union, 2013:127-143
[19]	Lan Cuo, Thomas W, Giambelluca, et al. Use of the distributed hydrology soil vegetation model to study road effects on hydrological processes in Pang Khum Experimental Watershed, northern Thailand[J]. Forest Ecology and Management, 2006, 224: 81－94.
[20]	Mohammad S, Ali F. Hydrologic effect of groundwater development in a small mountainous tropical watershed[J]. Journal of Hydrology, 2012, 428/429: 51－67.
[21]	Leung L R, Wigmosta M S, Ghan S J, et al. Application of a subgrid orograph precipitation/surface hydrology scheme to a mountain wateeshed[J]. Journal of Geophysical Research, 1996, 101(D8): 12803－12817.
[22]	Luz A C, Javier T, Antonio D N, et al. Distributed hydrological modeling of a micro-scale rainforest watershed in Amazonia: Model evaluation and advances in calibration using the new HAND terrain model[J]. Journal of Hydrology 2012, 462/463: 15－27.
[23]	刘可群，陈正洪，梁益同，等. 日太阳总辐射推算模型[J]. 中国农业气象，2008，29(1)：16－19.Liu Kequn, Chen Zhenghong, Liang Yitong, et al. Calculation model for daily global solar radiation[J]. Chinese Journal of agrometeorology. 2008, 29(1): 16－19. (in Chinese with English abstract)
[24]	熊勤学，黄敬峰. 利用NDVI指数时序特征监测秋收作物种植面积[J]. 农业工程学报，2009，25(1)：144－148.Xiong Qinxue, Huang Jingfeng. Estimation of autumn harvest crop planting area based on NDVI[J]. Transactions of the Chinese Society of Agricultural Engineering(Transactions of the CSAE), 2009, 25(1): 144－148. (in Chinese with English abstract)
[25]	熊勤学，胡佩敏. 基于HJ卫星混合像元分解法的湖北省四湖地区夏收作物种植信息提取[J]. 长江流域资源与环境，2014，23(6)：869－874.Xiong Qinxue, Hu Peimin. Extraction planting information of summer harvesting crop in ShiHu Region from HJ CCD data using unmixing algorithm method[J]. Resources and Environment in the Yngtze Basin, 2014, 23(6): 869－874. (in Chinese with English abstract)
[26]	吴华山，陈效民，叶民标，等. 太湖地区主要水稻土的饱和导水率及其影响因素研究[J]. 灌溉排水学报，2006，25(2)：46－48.Wu Huashan, Chen Xiaomin, Ye Minbiao, et al. Study on the soil saturated hydraulic conductivity and the infection factors of the main paddy soils in Tai-lake region[J]. Journal of Irrigation and Drainage, 2006, 25(2): 46－48. (in Chinesewith English abstract)
[27]	喻光明. 江汉平原渍害田生态特征的研究[J]. 生态学报，1993，13(3)：252－260.Yu Guangming. Stduy on the ecological characteristics of waterlogging field in Jiang Han Plain[J]. Acta Ecologica Sinica, 1993, 13(3): 252－260. (in Chinese with English abstract)
[28]	陈继元. 渍害低产田判别标准的定量分析[J]. 农田水利与小水电，1989(4)：13－15.
[29]	杨威，朱建强，吴启侠. 油菜受渍对产量的影响及排水指标研究[J]. 灌溉排水学报，2013，32(6)：31－34.Yang Wei, Zhu Jianqiang, Wu Qixia. Influence of waterlogging on rape yield components during different growth stages and study on drainage indexes. Journal of Irrigation and Drainage, 2013, 32(6): 31－34. (in Chinese with English abstract).
