稻茬田小麦宽幅精量少耕播种机的设计与试验

胡红; 李洪文; 李传友; 王庆杰; 何进; 李问盈; 张祥彩

doi:10.11975/j.issn.1002-6819.2016.04.004

稻茬田小麦宽幅精量少耕播种机的设计与试验

1.
中国农业大学工学院，北京 100083
2.
北京市农业机械试验鉴定推广站，北京 100079

基金项目: 公益性行业（农业）科研专项资助项目（201503136）

计量
- 文章访问数: 3655
- HTML全文浏览量: 0
- PDF下载量: 1110
出版历程
- 收稿日期: 2015-07-09
- 修回日期: 2016-01-16
- 发布日期: 2016-02-14

Design and experiment of broad width and precision minimal tillage wheat planter in rice stubble field

1.
College of Engineering, China Agricultural University, Beijing 100083, China
2.
Beijing Agricultural Machinery Testing and Extension Station, Beijing 100079, China

摘要

摘要: 为解决长江中下游稻麦轮作区稻茬田免耕播种小麦机具堵塞及土壤黏附严重等问题，结合当地稻茬田播种小麦需要开排水沟的农艺要求，提出了"种-肥-种"宽幅精量播种和带状旋耕相结合的防堵思路，设计了双翼铧式开沟器、宽幅精量排种机构、种沟双圆盘开沟器和浮动覆土板等关键部件，研究设计了一种稻茬田小麦宽幅精量少耕播种机。试验结果表明，宽幅播种方式与带状旋耕相结合较好解决了稻茬田播种小麦堵塞的问题，小麦播幅平均为74.6 mm，平均播深为39 mm，播深合格率为86.7%，施肥方式为侧下方深施肥，平均施肥深度为81 mm，施肥深度合格率为93.3%，均满足国家标准。厢沟平均深度为175 mm，沟面宽度为238 mm，满足排水要求。该研究为应用于稻麦轮作区稻茬田小麦少免耕播种机的设计提供了参考。
- 农业机械 /
- 设计 /
- 农作物 /
- 稻茬田 /
- 条带旋耕 /
- 防堵
Abstract: Abstract: Lacking of suitable machinery and heavy blocking are the major constraints for directly drilling wheat seed in rice stubble field due to the heavy straw load and heavy soil in rice-wheat cropping system in the middle and lower reaches of the Yangtze River region. Therefore, most farmers are reluctant to plant wheat in winter and a large number of croplands are idled. In order to solve the blocking problem in rice-wheat cropping system in the middle and lower reaches of the Yangtze River region, in view of meeting the agronomic requirements of opening ditch and reducing soil adhesion when sowing wheat in rice stubble field, a new anti-blocking method was proposed, which combined "seed-fertilizer-seed" broad width and precision planting mode with strip rotary tillage, and a broad width and precision minimal-tillage wheat planter was developed, which integrated the strip rotary tillage and broad width and precision seeding functions, and could finish ditch opening, strip rotary tillage, side deep fertilizing, broad width and precision seeding, and covering and compacting soil in the same run. Besides, the design and optimization for the key components were done, including double-wing ditch opener, double-shaft spiral indent roller seed-metering device and floating covering scraper. The stubbles among seed-fertilizer belts were cut and mixed with soil, and double-wing ditch openers dug the drainage ditch at the same time. The mean width of seed-fertilizer belts was 338 mm, in which 2 rows of seed and one row of fertilizer were set. The floating covering scraper was little wider than the seed-fertilizer belt, and when covering seeds and compacting soil in seed-fertilizer belts, it made ensure that there was good contact between seeds and soil. To evaluate the technology and the planter, laboratory experiments were conducted in Engineering College of China Agricultural University and field trials were conducted in Tuanfeng, Hubei Province. The laboratory experiments demonstrated that each indent of double-shaft spiral indent roller seed-metering device could only be filled with one grain of wheat seed at most, and the leakage rate of seed filling was 6.25%. The mean width of seeding rows was 74.6 mm, which reached the requirement of wide seeding. The field trials showed that the mean depth and width of ditch that was dug by double-wing ditch opener, were 175 and 238 mm respectively, which met the requirement of drainage. The mean sowing depth was 39 mm, and the qualified rate of sowing depth was 86.7%; the mean fertilizing depth was 81 mm, and the qualified rate of fertilizing depth reached 93.3%. Both of them met the requirements of national standard. When using the floating covering scraper to cover and compact soil, the soil adhesion was reduced by 48.34% compared with general press wheel. The slipping ratio of land wheel was 7.8%, and the blocking problem did not happen while the planter was working. The broad width and precision minimal-tillage wheat planter offers a new method of drilling wheat seed in rice stubble field, which can reduce blockage caused by the heavy rice stubble and decrease soil adhesion, and meets the requirements of opening ditch and broad width and precision seeding at the same time.
- agricultural machinery /
- design /
- crops /
- rice stubble field /
- anti-blocking /
- strip tillage

HTML全文

参考文献(33)

[1]	郭淑敏，马帅，陈印军. 中国粮食主产区主要粮食作物比较优势与发展对策研究[J]. 中国农学通报，2006，22(1)：391－396.Guo Shumin, Ma Shuai, Chen Yinjun. The study of comparative advantage and countermeasures of main grain production in the main grain production area in China[J]. Chinese Agricultural Science Bulletin, 2006, 22(1): 391－396. (in Chinese with English abstract)
[2]	马力，杨林章，沈明星，等. 基于长期定位试验的典型稻麦轮作区作物产量稳定性研究[J]. 农业工程学报，2011，27(4)：117－124.Ma Li, Yang Linzhang, Shen Mingxing, et al. Study on corp yield stability in a typical region of rice-wheat rotation based on long-term fertilization experiment[J]. Transaction of the Chinese Society of Agricultural Engineering (Transaction of the CSAE), 2011, 27(4): 117－124. (in Chinese with English abstract)
[3]	石春林，金之庆，葛道阔，等. 气候变化对长江中下游平原粮食生产的阶段性影响和适应性对策[J]. 江苏农业学报，2001，17(1)：1－6.Shi Chunlin, Jin Zhiqing, Ge Daokuo, et al. Gradual effects of climate change on food production and adaption strategies in the middle and lower valley of Yangtze River[J]. Jiangsu Journal of Agricultural Sciences, 2001, 17(1): 1－6. (in Chinese with English abstract)
[4]	杨利，张建峰，张富林，等. 长江中下游地区氮肥减施对稻麦轮作体系作物氮吸收、利用与氮素平衡的影响[J]. 西南农业学报，2013，26(1)：195－202.Yang Li, Zhang Jianfeng, Zhang Fulin, et al. Effects of reducing N application on crop N uptake, utilization and soil N balance under Rice-Wheat rotation system on middle and lower reaches of Yangtze river region[J]. Southwest China Journal of Agricultural Sciences, 2013, 26(1): 195－202. (in Chinese with English abstract)
[5]	夏晓东，吴崇友，张敏. 长江中下游稻田机械化保护性耕作研究展望[C]//农业部南京农业机械化研究所.中国农机化发展论坛：水稻生产机械化技术交流会论文集. 南京：[出版者不详]，2006.
[6]	张礼钢，夏晓东，缪冬平. 长三角地区稻麦轮作田机械化保护性耕作技术进展[J]. 农业工程，2012，2(9)：4－8.Zhang Ligang, Xia Xiaodong, Miao Dongping. Mechanization conservational tillage technology process in rice-wheat rotation field in the Yangtze River delta area[J]. Agricultural Engineering, 2012, 2(9): 4－8. (in Chinese with English abstract)
[7]	张秀梅，张居敏，夏俊芳，等.水旱两用秸秆还田耕整机关键部件设计与试验[J].农业工程学报，2015，31(11)：10－16.Zhang Xiumei, Zhang Jumin, Xia Junfang, et al. Design and experiment on critical component of cultivator for straw returning in paddy field and dry land[J]. Transactions of the Chinese Society of Agricultural Engineering (Transaction of the CSAE), 2015, 31(11): 10－16. (in Chinese with English abstract)
[8]	Singh A. Evaluation of wheat sowing technologies under paddy residue conditions[J]. International Journal of Forestry and Crop Improvement, 2015, 6(1): 43－48
[9]	Singh R P, Dhaliwal H S, Humphreys E, et al. Economic assessment of the Happy Seeder for rice-wheat systems in Punjab, India[C]//AARES 52nd Annual conference, Canberra, ACT, Australia, 2008: 2－23.
[10]	Olaf E. Cropping systems and crop residue management in the Trans-Gangetic Plains: Issues and challenges for conservation agriculture from village surveys[J]. Agricultural Systems, 2011,104(1): 54－62.
[11]	Olaf E, Umar F, Malik R K, et al. On-farm impacts of zero tillage wheat in South Asia's rice-wheat systems[J]. Field Crops Research, 2008, 105(3): 240－252.
[12]	Botta G, Tolón-becerra A, Lastra-bravo X, et al. Alternatives for handling rice (Oryza sativa L.) straw to favor its decomposition in direct sowing systems and their incidence on soil compaction[J]. Geoderma, 2015(239/240): 213－222.
[13]	Singh Y, Bhardwaj A K, Singh G, et al. Rice (oryza sativa) stubble height for zero-till wheat (triticum aestivum) sowing under a rice-wheat cropping system[J]. The Indian Journal of Agricultural Sciences, 2002, 72(12): 726－727.
[14]	Sidhu H S, Singh M, Humphreys E, et al. The happy seeder enables direct drilling of wheat into rice stubble[J]. Australian Journal of Experimental Agriculture, 2007, 47(7): 844－854.
[15]	Pannu C J S, Shukla L N. Tractor front-mounted cross-conveyor paddy straw thrower[J]. AMA-Agricultural Mechanization in Asia Africa and Latin America, 2010, 41(2): 35－42.
[16]	程少兰. 保护性耕作技术在南方水田地区应用的初步探索[C]//农业部南京农业机械化研究所.中国农机化发展论坛：水稻生产机械化技术交流会论文集.南京，2006.
[17]	金梅，梁苏宁，张文毅，等. 多功能施肥播种机的研发[J].中国农机化学报，2015，36(1)：4－6，17.Jin Mei, Liang Suning, Zhang Wenyi, et al. Development of multi-function fertilizing seeder[J]. Journal of Chinese Agricultural Mechanization, 2015, 36(1): 4－6,17. (in Chinese with English abstract)
[18]	李朝苏，汤永禄，解立胜，等. 2BMFDC-6型稻茬麦半旋播种机设计与性能试验[J]. 西南农业学报，2011，24(2)：789－793.Li Chaosu, Tang Yonglu, Xie Lisheng, et al. Design and experiment of 2BMFDC-6 Half-tillage seeder of wheat after rice[J]. Southwest China Journal of Agricultural Sciences, 2011, 24(2): 789－793. (in Chinese with English abstract)
[19]	王刚. 稻茬覆盖地小麦保护性耕作技术及机具研究[D]. 北京：中国农业大学，2006.Wang Gang. Study on Conservation Tillage Technology and Seeder about Wheat in Paddy Stubble-straw Field[D]. Beijing: China Agricultural University, 2006. (in Chinese with English abstract)
[20]	李兵，王继先，张健美，等. GBSL-180型双轴式旋耕灭茬播种机设计[J]. 农业机械学报，2008，39(3)：180－182.Li Bing, Wang Jixian, Zhang Jianmei, et al. Design and study of GBSL-180 type two-axle rotary tiller-seeder[J]. Transactions of the Chinese Society for Agricultural Machinery, 2008, 39(3): 180－182. (in Chinese with English abstract)
[21]	朱惠斌，李洪文，何进，等. 稻茬地双轴驱动防堵式小麦免耕播种机[J]. 农业机械学报，2013，44(6)：39－44.Zhu Huibin, Li Hongwen, He Jin, et al. No-till wheat seeder with two-axel drive anti-blocking in rice stubble field[J]. Transactions of the Chinese Society for Agricultural Machinery, 2013, 44(6): 39－44. (in Chinese with English abstract)
[22]	张青松，汲文峰，廖宜涛，等. 油菜直播机铧式开畦沟前犁曲面分析与阻力特性试验[J]. 农业机械学报，2014，45(2)：130－135.Zhang Qingsong, Ji Wenfeng, Liao Yitao, et al. Surface analysis and resistance characteristic experiment on ditch plow ahead of direct rapeseed seeder[J]. Transactions of the Chinese Society for Agricultural Machinery, 2014, 45(2): 130－135. (in Chinese with English abstract)
[23]	李拴良，任长宏，格桑曲珍，等. 宽幅硬茬播种对冬小麦生长、产量及品质的效应[J]. 麦类作物学报，2015，35(1)：80－85.Li Shuanliang, Ren Changhong, Gesangquzhen, et al. Effect of no-tilled wide planting pattern on growth, yield and quality of winter wheat[J]. Journal of Triticeae Crops, 2015, 35(1): 80－85. (in Chinese with English abstract)
[24]	韩惠芳，赵丹丹，沈加印，等. 灌水量和时期对宽幅精播冬小麦产量及品质特性的影响[J]. 农业工程学报，2013，29(14)：109－114.Han Huifang, Zhao Dandan, Shen Jiayin, et al. Effect of irrigation amount and stage on yield and quality of winter wheat under wide-precision planting pattern[J]. Transactions of the Chinese Society of Agricultural Engineering (Transaction of the CSAE), 2013, 29(14): 109－114. (in Chinese with English abstract)
[25]	古汉虎，向万胜，李玲. 湿地农田"三沟"配套排水整体功能研究[J]. 中国农业大学学报，1997，2(增刊)：130－134.Gu Hanhu, Xiang Wansheng, Li Ling. Study on the integral function of ditching to drain off excessive water in farming soil in wetland[J]. Journal of China Agricultural University, 1997, 2(Supp.): 130－134. (in Chinese with English abstract)
[26]	中国农业机械化科学研究院. 农业机械设计手册：上册[M].北京：中国农业科学技术出版社，2007.
[27]	高焕文，李洪文，姚宗路.轻型高防堵性能免耕播种机研究[J]. 中国工程科学，2007，9(9)：35－39.Gao Huanwen, Li Hongwen, Yao Zonglu. Study on the light no-till seeders with high anti-blockage performance[J]. Engineering Sciences, 2007, 9(9): 35－39. (in Chinese with English abstract)
[28]	贾洪雷，陈忠亮，郭红，等. 旋耕碎茬工作机理研究和通用刀辊的设计[J]. 农业机械学报，2000，31(4)：29－32.Jia Honglei, Chen Zhongliang, Guo Hong, et al. Study on working principle of rotary tillage and stubble cutting and design of universal knife roller[J]. Transactions of the Chinese Society for Agricultural Machinery, 2000, 31(4): 29－32. (in Chinese with English abstract)
[29]	张宇文. 机械式多功能精密排种器的设计[J]. 农业机械学报，2005，36(3)：51－53，50.Zhang Yuwen. Research and design for making a new type of mechanized and multiple functions of precision seed-drilled appliance[J]. Transactions of the Chinese Society for Agricultural Machinery, 2005, 36(3): 51－53,50. (in Chinese with English abstract)
[30]	袁文胜，吴崇友，金诚谦. 异形孔窝眼轮式油菜排种器设计与试验[J]. 农业机械学报，2009，40(5)：72－75.Yuan Wensheng, Wu Chongyou, Jin Chengqian. Design and experiment on seed-metering device with special cells for cole seed[J]. Transactions of the Chinese Society for Agricultural Machinery, 2009, 40(5): 72－75. (in Chinese with English abstract)
[31]	廖庆喜，张猛，余佳佳，等. 气力集排式油菜精量排种器[J]. 农业机械学报，2011，42(8)：30－34.Liao Qingxi, Zhang Meng, Yu Jiajia, et al. Pneumatic centralized metering device for rapeseed[J]. Transactions of the Chinese Society for Agricultural Machinery, 2011, 42(8): 30－34. (in Chinese with English abstract)
[32]	于慧春，刘俊峰，冯晓静，等. 双圆盘开沟器开沟沟形的计算机模拟分析[J]. 河北农业大学学报，2004，27(1)：108－110.Yu Huichun, Liu Junfeng, Feng Xiaojing, et al. Simulation study on the property and motion of the double-disk digger[J]. Journal of Agricultural University of Hebei, 2004, 27(1): 108－110. (in Chinese with English abstract)
[33]	吴明亮，官春云，汤楚宙，等. 2BF-6型稻茬田油菜免耕联合播种机的研究[J]. 农业工程学报，2005，21(3)：103－106.Wu Mingliang, Guan Chunyun, Tang Chuzhou, et al. 2BF-6 type no-tillage combine seeder for rape in stubbly field[J]. Transactions of the Chinese Society of Agricultural Engineering (Transaction of the CSAE), 2005, 21(3): 103－106. (in Chinese with English abstract)
