退火对冷冻干燥固态果蔬食品模拟体系冰晶结构和质构的影响

马有川; 毕金峰; 易建勇; 冯舒涵; 吴中华

doi:10.11975/j.issn.1002-6819.202210191

退火对冷冻干燥固态果蔬食品模拟体系冰晶结构和质构的影响

马有川^1,2,
毕金峰^2,3,
易建勇^2,3,
冯舒涵^2,3,
吴中华^1,4

1.
天津市科技大学机械工程学院，天津 300222
2.
中国农业科学院农产品加工研究所，北京 100193
3.
农业农村部农产品加工综合性重点实验室，北京 100193
4.
天津市轻工与食品工程机械装备集成设计与在线监控重点实验室，天津 300222

基金项目: 中国农业科学院农产品加工研究所创新工程项目（CAAS- ASTIP-2022-IFST）；天津市研究生科研创新项目（2021YJSB201）；广东省农业科学院学科团队建设项目（202109TD）

计量
- 文章访问数: 39
- HTML全文浏览量: 0
- PDF下载量: 44
出版历程
- 收稿日期: 2022-10-24
- 修回日期: 2023-02-06
- 发布日期: 2023-02-27

Effects of annealing on the ice crystal structure and texture of the solid food simulated system for freeze-dried fruit and vegetable

1.
College of Mechanical Engineering, Tianjin University of Science and Technology, Tianjin 300222, China
2.
Institute of Food Science and Technology, CAAS, Beijing 100193, China
3.
Key Laboratory of Agro-Products Processing, Ministry of Agriculture and Rural Affairs, Beijing 100193, China
4.
Tianjin Key Laboratory of Integrated Design and On-line Monitoring for Light Industry and Food Machinery and Equipment, Tianjin 300222, China

摘要

摘要: 为探究冷冻过程中退火条件对真空冷冻干燥固体果蔬食品模拟体系冰晶结构、干燥特性、微观结构和质构的影响，该试验通过建立真空冷冻干燥果胶-蔗糖凝胶体系模拟果蔬天然网络结构，考察了不同退火条件对冷冻模拟体系的冰晶结构、冷冻干燥模拟体系的微观结构和质构等品质的影响。结果表明，退火温度范围和退火次数是影响冰晶结构、干燥过程和产品质构的重要因素。研究发现，冷冻模拟体系冰晶的直径均值、冰晶比例随退火温度范围增加和退火次数增加而降低；模拟体系的冷冻干燥速率随退火温度范围和退火次数增加而加快；冻干模拟体系的硬度和脆度随退火温度范围和退火次数增加而降低。采用0 ℃退火3次条件下，干燥时间最短约为14.0 h，此时模拟体系冰晶分形维数为1.616，冰晶直径极差为0.98 mm，直径切尾均值为0.16 mm，冰晶比例为75.00%，在脆度阈值为0.784 N时脆度保留效果最好，峰个数为4.33。相关性分析结果表明，模拟体系的干燥时间与冰晶直径分布的离散程度、直径均值呈正相关，与分形维数呈负相关，与冰晶的直径均值和退火到达温度呈正相关。该研究明确了退火条件对模拟体系冰晶形态和冻干后多孔结构的影响，可为真空冷冻干燥食品预冻过程中控制冰晶形成提供理论依据。
- 冷冻干燥 /
- 质构 /
- 冰晶结构 /
- 微观结构 /
- 退火
Abstract: Abstract: Vacuum freeze-drying (FD) can be performed using sublimation, in order to produce a high-quality product with a long shelf-life and crispness texture. But the ice crystals are formed in the process of freezing, due to the long drying time and high energy consumption during vacuum FD. It is a high demand to control the ice crystal formation for energy-saving food products with the desired sensory properties. This study aimed to examine the effect of annealing temperature (-18, -4, 0, and 4℃) and cycles (1-3) on the ice crystal structure and distribution, drying kinetics, microstructure, and texture of the pectin-sucrose simulated system. The pectin-sucrose solid system with the porous scaffolds was established to simulate the skeleton structure of natural fruits and vegetables. Simultaneously, some properties were also similar to those of fruits and vegetables, such as the thermal physical and mechanical properties. An investigation was made to determine the ice crystal distribution and morphology of the frozen simulated system, while the microstructure and texture of the freeze-dried simulated system. The results show that the ice crystal structure, drying characteristics, and product texture depended mainly on the annealing temperature and cycles. Observations of ice crystals showed that the size of ice crystals increased with the annealing temperature and cycles. The ice crystal images were evaluated to analyze the fractal dimension and ice crystal diameter distribution. The fractal dimension, mean diameter, and proportion of ice crystals decreased with the increase of annealing temperature and cycles. The large ice crystals of the simulated system accelerated the drying process in the sublimation drying. Moreover, the drying rate of the food simulated system increased with the decrease of fractal dimension. In addition, the hardness and crushing work of freeze-dried samples decreased with the increase in annealing temperature and cycles. The 0.784 N threshold crispness values showed no significant difference between the annealing (-18, -4, and 0℃) and untreated samples. The increasing annealing time and cycles resulted in a faster initial drying rate and shorter FD time. Especially, the 0℃-3 annealing treatment took the shortest drying time (14.0 h), which was 4% shorter than that of the 0℃-1sample (14.6 h), 12% shorter than that of the 18℃-3 sample (16.0 h), and about 16% shorter than that of the untreated group (16.6 h). The ice crystal morphology of the 0-3℃ food simulated system showed that the fractal dimension was 1.616, the maximum range was 0.98 mm, the trimmed mean diameter is 0.16 mm, and the proportion of ice crystal was 75.00%. This treatment led to a higher retention of crispness (4.33) than the samples treated with 4℃. The pore structure of the 0-3℃ freeze-dried sample showed a larger pore area than that in the lower annealing temperature samples. Correlation analysis showed that the drying time was significantly positively correlated with the fractal dimension and ice crystal numbers, while negatively correlated with the diameter range and proportion of the ice crystal, and annealing temperature. In conclusion, annealing can be expected to improve the drying rate and texture properties of the fruit and vegetable simulated system. The fractal dimension and diameter distribution of ice crystals can also be evaluated for the drying characteristics and texture change during freezing. The finding can provide a strong reference to control the ice crystal formation in the process of vacuum FD fruits and vegetables.
- freeze drying /
- texture /
- ice crystal /
- microstructure /
- annealing

HTML全文

参考文献(35)

[1]	BELWAL T, CRAVOTTO C, PRIETO M A, et al. Effects of different drying techniques on the quality and bioactive compounds of plant-based products: a critical review on current trends[J]. Drying Technology, 2022, 40(8): 1539-1561.
[2]	谢焕雄，胡志超，王海鸥，等. 真空冷冻干燥对柠檬挥发性风味化合物保留的影响[J]. 农业工程学报，2018，34(22)：282-290.XIE Huanxiong, HU Zhichao, WANG Haiou, et al. Effect of vacuum freeze-drying methods on retention of volatile flavor compounds of lemon[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2018, 34(22): 282-290. (in Chinese with English abstract)
[3]	于佳慧，王维，唐宇佳，等. 吸波材料辅助发泡蓝莓果浆微波冷冻干燥的试验研究[J]. 农业工程学报，2022，38(18)：284-292.YU Jia Hui, WANG Wei, TANG Yu Jia, et al. Experimental study on the microwave freeze-drying of foamed blueberry puree assisted by wave-absorbing material[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2022, 38(18): 284-292. (in Chinese with English abstract)
[4]	刘业凤，周国梁，李续. 真空冷冻干燥蒜丁实际生产的能耗研究[J]. 农业工程学报，2014，30(10)：242-247.LIU Yefeng, ZHOU Guoliang, LI Xu. Research on energy consumption in actual production of vacuum freeze-dried garlic slice[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2014, 30(10): 242-247. (in Chinese with English abstract)
[5]	马有川，毕金峰，易建勇，等. 预冻对苹果片真空冷冻干燥特性及品质的影响[J]. 农业工程学报，2020，36(18)：241-250.MA Youchuan, BI Jinfeng, YI Jianyong, et al. Effects of pre-freezing on the drying characteristics and quality parameters of freeze drying apple slices[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2020, 36(18): 241-250. (in Chinese with English abstract)
[6]	FENG Y B, PING T C, ZHOU C S, et al. Effect of freeze-thaw cycles pretreatment on the vacuum freeze-drying process and physicochemical properties of the dried garlic slices[J]. Food Chemistry, 2020, 324(15): 126883.
[7]	LUO C, LIU Z Q, MI S, et al. Quantitative investigation on the effects of ice crystal size on freeze-drying: The primary drying step[J]. Drying Technology, 2022, 40(2): 446-458.
[8]	WANG W, WANG S H, PAN Y Q, et al. Porous frozen material approach to freeze-drying of instant coffee[J]. Drying Technology, 2019, 37(16): 2126-2136.
[9]	MA Y C, YI J Y, BI J F, et al. Understanding of osmotic dehydration on mass transfer and physical properties of freeze-dried apple slices: A comparative study of five saccharides osmotic agents[J]. Journal of Food Processing and Preservation, 2022, 46(3): e16328.
[10]	张朔，王维，李一喆，等. 冷冻干燥过程强化中冷冻阶段优化的研究进展[J]. 化工进展，2020，39(8)：2937-2946.ZHANG S, WANG W, LI Y Z, et al. Research progress on optimization of freezing stage in enhancement of freeze-drying[J]. Chemical Industry and Engineering Progress, 2020, 39(8): 2937-2946. (in Chinese with English abstract)
[11]	李恒乐，王维，李强强，等. 具有预制孔隙多孔物料的冷冻干燥[J]. 化工学报，2016，67(7)：2857-2863.LI Hengle, WANG Wei, LI Qiangqiang, et al. Freeze-drying of porous frozen material with prefabricated porosity[J]. Chemical Industry and Engineering Progress, 2016, 67(7): 2857-2863. (in Chinese with English abstract)
[12]	THOMIK M, GRUBER S, KAESTNER A, et al. Experimental study of the impact of pore structure on drying kinetics and sublimation front patterns[J]. Pharmaceutics, 2022, 14(8): 1538.
[13]	ROBLES C M, QUINTANILLA-CARVAJAL M X, MORENO F L, et al. Ice morphology modification and solute recovery improvement by heating and annealing during block freeze-concentration of coffee extracts[J]. Journal of Food Engineering, 2016, 189: 72-81.
[14]	FOERST P, MELO DE CARVALHO T, LECHNER M, et al. Estimation of mass transfer rate and primary drying times during freeze-drying of frozen maltodextrin solutions based on x-ray μ-computed tomography measurements of pore size distributions[J]. Journal of Food Engineering, 2019, 260: 50-57.
[15]	HAN W, MENG Y, HU C, et al. Mathematical model of Ca2+ concentration, pH, pectin concentration and soluble solids (sucrose) on the gelation of low methoxyl pectin[J]. Food Hydrocolloids, 2017, 66: 37-48.
[16]	JIANG Q, ZHANG M, MUJUMDAR A S, et al. Comparative freezing study of broccoli and cauliflower: Effects of electrostatic field and static magnetic field[J]. Food Chemistry, 2022, 397(15): 133751.
[17]	CAO Y, ZHAO L, HUANG Q, et al. Water migration, ice crystal formation, and freeze-thaw stability of silver carp surimi as affected by inulin under different additive amounts and polymerization degrees[J]. Food Hydrocolloids, 2022, 124: 107267.
[18]	JIA R, JIANG Q, KANDA M, et al. Effects of heating processes on changes in ice crystal formation, water holding capacity, and physical properties of surimi gels during frozen storage[J]. Food Hydrocolloids, 2019, 90: 254-265.
[19]	REIS F R, LENZI M K, de MU?IZ G I B, et al. Vacuum drying kinetics of yacon (smallanthus sonchifolius) and the effect of process conditions on fractal dimension and rehydration capacity[J]. Drying Technology, 2012, 30(1): 13-19.
[20]	杜茜茜，易建勇，毕金峰，等. 果胶对真空冷冻干燥重组苹果块质构和吸湿特性的影响[J]. 食品科学，2021, 42(24): 54-60.DU Qianqian, YI Jianyong, BI Jinfeng, et al. Effect of pectin on the texture and hygroscopic properties of freeze-dried reconstituted apple cubes[J]. Food Science, 2021, 42(24): 54-60. (in Chinese with English abstract)
[21]	潘治利，骆洋翔，艾志录，等. 不同冻藏温度条件下速冻汤圆品质变化及其机制[J]. 农业工程学报，2018，34(21)：304-310.PAN Zhili, LUO Yangxiang, AI Zhilu, et al. Quality change and its mechanism of quick-frozen rice dumplings under condition of different frozen temperatures[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2018, 34(21): 304-310. (in Chinese with English abstract)
[22]	李文采，田寒友，白京，等. 采用压汞法研究不同冷冻羊肉冰晶结构特征[J]. 农业工程学报，2019，35(20)：280-287.LI Wencai, TIAN Hanyou, BAI Jing, et al. Investigation of ice crystal structure characteristics of different frozen lamb by using mercury intrusion[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2019, 35(20): 280-287. (in Chinese with English abstract)
[23]	WANG Y, JIAO A, QIU C, et al. A combined enzymatic and ionic cross-linking strategy for pea protein/sodium alginate double-network hydrogel with excellent mechanical properties and freeze-thaw stability[J]. Food Hydrocolloids, 2022, 131: 107737.
[24]	XU C, LIU D, ZHANG L, et al. Influence of temperature fluctuations on the state/phase, ice crystal morphology, cell structure, and quality of celery during frozen storage[J]. LWT, 2020, 125: 109219.
[25]	LUAN L, SUN Y, YUAN C, et al. Quality evaluation based on fractal dimension and biochemical changes for hairtail (Trichiurus Haumela) samples subjected to multiple freeze-thaw cycles[J]. International Journal of Food Properties, 2018, 21(1): 2328-2338.
[26]	LUAN L, SUN Y, CHEN S, et al. A study of fractal dimension as a quality indicator of hairtail (Trichiurus Haumela) samples during frozen storage[J]. Scientific Reports, 2018, 8(1): 16468.
[27]	FENG S H, BI J F, YI J Y, et al. Modulation of ice crystal formation behavior in pectin cryogel by xyloglucan: effect on microstructural and mechanical properties[J]. Food Research International, 2022, 159: 111555.
[28]	LEVIN P, MEUNIER V, KESSLER U, et al. Influence of freezing parameters on the formation of internal porous structure and its impact on freeze-drying kinetics[J]. Processes, 2021, 9(8): 1273.
[29]	LUO C, LIU Z, MI S, et al. Quantitative investigation on the effects of ice crystal size on freeze-drying: The primary drying step[J]. Drying Technology, 2022, 40(2): 446-458.
[30]	BASSEY E J, SUN D, ESUA O J, et al. Effects of freeze-thaw pretreatments on the drying characteristics, physicochemical and phytochemical composition of red dragon fruit during mid- and near-infrared drying[J]. Drying Technology, 2023, 41(4): 561-576.
[31]	MONTEIRO R L, LINK J V, TRIBUZI G, et al. Effect of multi-flash drying and microwave vacuum drying on the microstructure and texture of pumpkin slices[J]. LWT, 2018, 96: 612-619.
[32]	武旭瑶，马有川，黄文英，等. 热风干燥过程中果蔬片脆性变化规律[J]. 食品与机械，2022，38(9)：22-28.WU Xuyao, MA Youchuan, HUANG Wenying, et al. Variation of food brittleness of the fruit and vegetable slices during hot air drying process[J]. Food & Machinery, 2022, 38(9): 22-28. (in Chinese with English abstract)
[33]	LIU C J, XUE Y L, GUO J, et al. Citric acid and sucrose pretreatment improves the crispness of puffed peach chips by regulating cell structure and mechanical properties[J]. LWT, 2021, 142: 111036.
[34]	XU X, ZHANG L, FENG Y B, et al. Ultrasound freeze-thawing style pretreatment to improve the efficiency of the vacuum freeze-drying of okra (Abelmoschus esculentus (L. ) Moench) and the quality characteristics of the dried product[J]. Ultrasonics Sonochemistry, 2021, 70: 105300.
[35]	付仁豪，汪春玲，陈政，等. 基于罗非鱼肌肉微结构分形维数表征的冻融过程品质变化分析[J]. 食品科学，2021，42(15)：19-26.FU Renhao, WANG Chunling, CHEN Zhen, et al. Quality change of tilapia fillets during freeze-thaw cycles characterized based on fractal dimension of microstructure[J]. Food Science, 2021, 42(15): 19-26. (in Chinese with English abstract)
