可变形磨损模型下微型离心泵复合磨损研究

王田田; 李俊宏; 南玲博; 陈帝伊; 曹东亮; 韩伟

可变形磨损模型下微型离心泵复合磨损研究

1. 西北农林科技大学水利与建筑工程学院;
2. 中山大学航空航天学院;
3. 海尔集团;
4. 兰州理工大学能源与动力工程学院

基金项目:

国家自然科学基金重点项目(52339006)

详细信息

作者简介:
王田田(1996—),男,博士生,主要从事水动力学及水力机械研究,E-mail:Tiantian7921@163.com

通讯作者:
陈帝伊(1982—),男,教授,博士生导师,主要从事水电站及泵站工程研究,E-mail:diyichen@nwafu.edu.cn

中图分类号: TH311;TH117.1
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2023-08-22
- 刊出日期: 2024-04-24

Complex Wear of Micro Centrifugal Pump under Deformable Wear Model

1. College of Water Resources and Architectural Engineering, Northwest A&F University;
2. School of Aeronautics and Astronautics, Sun Yat-sen University;
3. Haier Group;
4. School of Energy and Power Engineering, Lanzhou University of Technology

摘要

摘要: 为了探究微型离心泵在不同颗粒体积分数下的复合磨损类型与磨损变化，基于计算流体动力学与离散元耦合的方法，通过可变形磨料磨损Archard模型与可变形冲蚀磨损Oka模型对离心泵在不同颗粒体积分数(2%、4%、6%、8%、10%、12%)下的颗粒-部件碰撞占比率、磨损分布与演化进行了研究。通过对比实验发现颗粒体积分数在4%附近时颗粒与叶轮叶片、蜗壳碰撞占比率呈现不同的变化趋势。离心泵磨损以磨料磨损为主，磨料磨损中蜗壳为磨损最严重的部件，占总磨料磨损量的68.5%,随着颗粒体积分数的增加，蜗壳处磨料磨损由断面Ⅷ向断面Ⅰ演化，蜗壳前后端先后磨损。冲蚀磨损高磨损区域主要集中于叶轮叶片，占冲蚀磨损总量的95.83%,蜗壳处冲蚀磨损断面演化规律与磨料磨损变化规律近似，但蜗壳后端最先被磨损。颗粒体积分数对蜗壳磨料磨损变形量影响较大，蜗壳、叶轮磨料磨损变形量与冲蚀磨损变形量具有相似的变化趋势。
- 微型离心泵 /
- 磨料磨损 /
- 冲蚀磨损 /
- 可变形磨损 /
- 颗粒体积分数 /
- CFD-DEM
Abstract: Micro centrifugal pump has a wide range of applications in the field of medical and chemical sewage treatment, but it often faces the problem of wear in use. In order to explore the compound wear type and wear change of micro centrifugal pump under different particle volume fractions, based on the method of computational fluid dynamics and discrete element coupling, and the deformable abrasive wear Archard model and the deformable erosion wear Oka model, the particle-component collision ratio, wear distribution and evolution of centrifugal pumps under different particle volume fractions（2%, 4%, 6%, 8%, 10%, 12%） were studied. The results showed that when the particle volume fraction was near 4%, the impact ratio between impeller blade and volute showed different trends. The wear in centrifugal pump was mainly abrasive wear, and the parts with the most serious wear in the abrasive wear accounted for 68.5% of the total abrasive wear. With the increase of particle volume fraction, the abrasive wear at the volute changed from section Ⅷ to section Ⅰ, and the front and back ends of the volute wear successively. The high wear area of erosion wear was mainly concentrated in the impeller blade, accounting for 95.83% of the total erosion wear. The evolution law of erosion wear section at the volute was similar to the change law of abrasive wear, but the back end of the volute was worn first. The particle volume fraction had more influence on the abrasive wear deformation of volute, and the abrasive wear deformation of volute and impeller had a similar change trend to the erosion wear deformation.
- micro centrifugal pump /
- abrasive wear /
- erosion wear /
- deformable wear /
- particle volume fraction /
- CFD-DEM

HTML全文

参考文献(27)

[1]	冷洪飞,姚志峰,汤远,等.微型离心泵诱导轮与叶轮轴向距离匹配特性[J].农业工程学报,2020,36(12):47-53.LENG Hongfei,YAO Zhifeng,TANG Yuan,et al.Matching characteristics of axial distance between inducer and impeller of micro-centrifugal pump[J].Transactions of the CSAE,2020,36(12):47-53.(in Chinese)
[2]	康灿,曹骞,胡江,等.基于壁面磨损的渣浆泵内固液两相流动分析[J].工程热物理学报,2021,42(9):2292-2297.KANG Can,CAO Qian,HU Jiang,et al.Analysis of solid-liquid two-phase flow in a slurry pump based on wear of hydraulic components[J].Journal of Engineering Thermophysics,2021,42(9):2292-2297.(in Chinese)
[3]	夏铖,赵睿杰,施卫东,等.基于DEM-CFD耦合的泵内颗粒流动特性研究[J].工程热物理学报,2021,42(2):357-369.XIA Cheng,ZHAO Ruijie,SHI Weidong,et al.Numerical investigation of particle induced erosion in a mixed pump by CFD-DEM coupled method[J].Journal of Engineering Thermophsics,2021,42(2):357-369.(in Chinese)
[4]	HUANG S,SU X,QIU G.Transient numerical simulation for solid-liquid flow in a centrifugal pump by DEM-CFD coupling[J].Engineering Applications of Computational Fluid Mechanics,2015,9(1):411-418.
[5]	施卫东,施亚,高雄发,等.基于DEM-CFD的旋流泵大颗粒内流特性模拟与试验[J].农业机械学报,2020,51(10):176-185.SHI Weidong,SHI Ya,GAO Xiongfa,et al.Simulation and experiment on flow characteristics of large particles in vortex pump based on DEM-CFD[J].Transactions of the Chinese Society for Agricultural Machinery,2020,51(10):176-185.(in Chinese)
[6]	DENG L,HU Q,CHEN J,et al.Particle distribution and motion in six-stage centrifugal pump by means of slurry experiment and CFD-DEM simulation[J].Journal of Marine Science and Engineering,2021,9(7):716.
[7]	LIU H X,YANG W X,KANG R.A correlation for sand erosion prediction in annular flow considering the effect of liquid dynamic viscosity[J].Wear,2018,404-405:1-11.
[8]	王田田,池晓清,杨具瑞,等.颗粒特性对离心泵叶轮叶片的磨损分析[J].水动力学研究与进展A辑,2022,37(2):181-189.WANG Tiantian,CHI Xiaoqing,YANG Jurui,et al.Wear analysis of impeller blade of centrifugal pump by particle characteristics[J].Chinese Journal of Hydrodynamics A,2022,37(2):181-189.(in Chinese)
[9]	张自超,李延频,陈德新.双吸离心泵叶轮内泥沙磨损非定常特性研究[J].农业机械学报,2022,53(4):140-148,191.ZHANG Zichao,LI Yanpin,CHEN Dexin.Investigation on unsteady erosion characteristics in impeller of double suction centrifugal pump[J].Transactions of the Chinese Society for Agricultural Machinery,2022,53(4):140-148,191.(in Chinese)
[10]	QIN J Y,WEI C.Coupling of an IOT wear sensor and numerical modelling in predicting wear evolution of a slurry pump[J].Powder Technology,2022,404:117453.
[11]	LI Y,ZENG X,LV W,et al.Centrifugal pump wear for solid-liquid two-phase flows based on computational fluid dynamics-discrete element method coupling[J].Advances in Mechanical Engineering,2020,12(7):378-396.
[12]	骆家银.钻井泵泵阀系统磨损与失效分析研究[D].成都:西南石油大学,2015.LUO Jiayin.Wear and failure analysis of drilling pump valve system[D].Chengdu:Southwest Petroleum University,2015.(in Chinese)
[13]	周理强,韩栋,喻黎明,等.导流片对Y型网式过滤器性能的影响[J].农业工程学报,2020,36(12):40-46.ZHOU Liqiang,HAN Dong,YU Liming,et al.Effects of guide vanes on performance of Y-screen filter[J].Transactions of the CASE,2020,36(12):40-46.(in Chinese)
[14]	王田田,支嘉才,杨具瑞,等.基于计算流体动力学与离散元法的离心泵内流场及磨损的数值模拟[J].湖南农业大学学报(自然科学版),2022,48(2):235-241.WANG Tiantian,ZHI Jiacai,YANG Jurui,et al.Numerical simulation of flow field and wear in centrifugal pump based on CFD-DEM[J].Journal of Hunan Agricultural University(Natural Sciences),2022,48(2):235-241.(in Chinese)
[15]	王福军.计算流体动力学分析——CFD软件原理与应用[M].北京:清华大学出版社,2004.
[16]	喻黎明,徐洲,杨具瑞,等.CFD-DEM耦合模拟网式过滤器局部堵塞[J].农业工程学报,2018,34(18):130-137.YU Liming,XU Zhou,YANG Jurui,et al.CFD-DEM coupling simulation of local clogging of mesh filter[J].Transactions of the CSAE,2018,34(18):130-137.(in Chinese)
[17]	QIU L C,WU C Y.A hybrid DEM/CFD approach for solid-liquid flows[J].Journal of Hydrodynamics,2014,26(1):19-25.
[18]	CHU K W,WANG B,YU A B,et al.CFD-DEM modelling of multiphase flow in dense medium cyclones[J].Powder Technology,2009,193(3):235-247.
[19]	TANG C,YANG Y C,LIU P Z,et al.Prediction of abrasive and impact wear due to multi-shaped particles in a centrifugal pump via CFD-DEM coupling method[J].Energies,2021,14(9):2391.
[20]	ARCHARD J F,HIRST W.The wear of metals under unlubricated conditions[J].Proceedings of the Royals Society of London.Series A,Mathematical and Physical Sciences,1956,236(1206):397-410.
[21]	ARCHARD J F.Contact and rubbing of flat surfaces[J].Journal of Applied Physics,1953,24(8):981-988.
[22]	OKA Y I,OKAMURA K,YOSHIDA T.Practical estimation of erosion damage caused by solid particle impact.Part 1:effect of impact parameters on a predictive equation[J].Wear,2005,259(1-6):95-101.
[23]	OKA Y I,YOSHIDA T.Practical estimation of erosion damage caused by solid particle impact.Part 2:mechanical properties of materials directly associated with erosion damage[J].Wear,2005,259(1-6):102-109.
[24]	BILAL F S,SEDREZ T A,SHIRAZI S A.Experimental and CFD investigations of 45 and 90 degrees bends and various elbow curvature radii effects on solid particle erosion[J].Wear,2021,476:203646.
[25]	BLANCHARD D,GRIFFITH P,RABINOWICZ E.Erosion of a pipe bend by solid particles entrained in water[J].Journal of Engineering for Industry,1984,106(3):213-217.
[26]	ZHANG Y,REUTERFORS E P,MCLAURY B S,et al.Comparison of computed and measured particle velocities and erosion in water and air flows[J].Wear,2007,263(1-6):330-338.
[27]	夏铖.基于CFD-DEM方法的两级混流泵内部粗颗粒固液两相流特性研究[D].镇江:江苏大学,2020.XIA Cheng.Study on coarse solid-liquid two-phase flow characteristics in a two-stage mixed-flow pump based on CFD-DEM method[D].Zhenjiang:Jiangsu University,2020.(in Chinese)
