Rapid Detection of Stored Grain Pests in Flour Based on GC-MS and E-nose
-
摘要: 储粮害虫会降低粮食及其产品的重量、品质和营养健康指数，并且我国粮虫检测方式仍然以人工检测为主。为满足储粮害虫快速检测的需求，采用气相色谱-质谱联用仪(GC-MS)获得了赤拟谷盗(Tribolium castaneum(Herbst))的主要特定挥发性有机化合物(VOCs),根据这些化合物的性质筛选出多个金属氧化物气敏传感器，并以传感器阵列为核心开发了储粮害虫电子鼻检测装置。该装置采集了赤拟谷盗、被赤拟谷盗侵染的面粉、被长头谷盗(Latheticus oryzae Waterhouse)侵染的面粉3种实验对象的气味信息，提取每条响应曲线的相对变化值和相对积分值作为原始特征矩阵(10×2),使用主成分分析(PCA)和偏最小二乘回归算法(PLSR)对原始特征矩阵进行分析，并通过建立回归预测模型，实现了对面粉中赤拟谷盗和长头谷盗虫口密度的预测。优化后的传感器数量由10个减少至8个，赤拟谷盗样品的两个主成分累计的贡献率为79.4%。基于PLSR的预测模型对面粉中赤拟谷盗的数量有很好的预测效果(校正集：相关系数r=0.88,均方根误差为8.09;验证集：r=0.89,均方根误差为7.75);该预测模型对面粉中长头谷盗的数量也有很好的预测效果(校正集：r=0.94,均方根误差为5.85;验证集：r=0.94,均方根误差为6.08)。研究结果表明：该装置能够满足判别储粮中不同虫口密度样本的基本需要，并且具有可靠的稳定性。Abstract: Grain storage pests can reduce the weight, quality and nutritional health index of grain and its products, and the way of grain pest detection in China is still dominated by manual detection. To meet the needs of modern detection of grain storage pests, gas chromatography-mass spectrometry（GC-MS） was used to obtain the main specific volatile organic compounds（VOCs） of Tribolium castaneum（Herbst）, screened multiple metal oxide gas sensors with the obtained compounds as reference. Then the air chamber for sensor response was optimally designed and an electronic nose detection device for grain storage pests was developed based on the composed sensor array. The device collected odor information from three experimental subjects, including T.castaneum, the flour during infestation of T.castaneum and the flour during infestation of Latheticus oryzae Waterhouse. Relative change values and relative integration values of the response curve corresponding to each sensor as the original feature matrix（10×2）. Principal component analysis（PCA） and partial least squares regression algorithm（PLSR） were used to optimize the original feature matrix. Finally, a predictive regression model was built to forecast the population density of T.castaneum and Latheticus oryzae Waterhouse in flour. Two GC-MS studies were carried out for the purpose to collect 12 distinct volatile chemical compounds of T.castaneum that were not found in other grain insects or stored grains. The number of sensors was reduced from 10 to 8, and the contribution of the two principal components of the T.castaneum samples was increased to 79.4%. The odor of the flour itself would be a great interference to the electronic nose detection of T.castaneum, and under the condition of no flour interference, the electronic nose device can discriminate between samples with varying insect population densities. The PLSR-based prediction model was highly effective in predicting the number of T.castaneum in flour（correction set: correlation coefficient r=0.88, root mean square error（RMSE） was 8.09; validation set: correlation coefficient r=0.89,RMSE was 7.75）; the prediction model was also highly effective in predicting the number of Latheticus oryzae Waterhouse in flour（correction set: correlation coefficient r=0.94, RMSE was 5.85; validation set: r=0.94, RMSE was 6.08）. The research results indicated that the device can meet the needs of distinguishing samples with different insect densities in stored grains and had reliable stability. This method also provided a method reference for detecting other pests in stored grain.
-
-
[1] LOPEZ-CASTILLO L M,SILVA-FERNANDEZ S E,WINKLER R,et al.Postharvest insect resistance in maize[J].Journal of Stored Products Research,2018,77:66-76.
[2] 许德刚,李凡.现代信息技术在储粮害虫检测中的应用[J].中国粮油学报,2021,36(3):185-194.XU Degang,LI Fan.Application of modern information technology in the detection of stored grain insects[J].Journal of the Chinese Cereals and Oils Association,2021,36(3):185-194.(in Chinese) [3] 吕建华,黄宗文,王殿轩,等.储粮害虫检测方法研究进展[J].中国粮油学报,2020,35(11):194-202.LÜ Jianhua,HUANG Zongwen,WANG Dianxuan,et al.Advances in detection methods of stored grain insects[J].Journal of the Chinese Cereals and Oils Association,2020,35(11):194-202.(in Chinese) [4] 张红涛,朱洋,谭联,等.利用机器视觉识别麦粒内米象发育规律与龄期[J].农业工程学报,2020,36(2):201-208.ZHANG Hongtao,ZHU Yang,TAN Lian,et al.Identifying larval development of Sitophilus oryzae in wheat grain using computer vision[J].Transactions of the CSAE,2020,36(2):201-208.(in Chinese) [5] 鲁玉杰,王文敬,任天一,等.储藏物害虫智能化监测与预警系统研究进展[J].粮油食品科技,2021,29(3):208-214.LU Yujie,WANG Wenjing,REN Tianyi,et al.Research progress of intelligent monitoring and early warning system for stored grain pests[J].Science and Technology of Cereals,Oils and Foods,2021,29(3):208-214.(in Chinese) [6] 白旭光.储藏物害虫与防治(2版)[M].北京:科学出版社,2008. [7] 张生芳,刘永平,武增强.中国储藏物甲虫[M].北京:中国农业科技出版社,1998. [8] NEGI A,PARE A,MANICKAM L,et al.Effects of defect action level of Tribolium castaneum (Herbst) (Coleoptera:Tenebrionidae) fragments on quality of wheat flour[J].Journal of the Science of Food and Agriculture,2022,102(1):223-232.
[9] 黄宗文,吕建华,许俊亚.不同初始虫口密度赤拟谷盗成虫危害对小麦粉挥发性物质的影响研究[J].中国粮油学报,2022,37(6):29-35.HUANG Zongwen,LÜ Jianhua,XU Junya.Effects of different initial densities of insect pests on volatile compounds from wheat flour[J].Journal of the Chinese Cereals and Oils Association,2022,37(6):29-35.(in Chinese) [10] NAYAK M K,FALK M G,EMERY R N,et al.An analysis of trends,frequencies and factors influencing the development of resistance to phosphine in the red flour beetle Tribolium castaneum (Herbst) in Australia[J].Journal of Stored Products Research,2017,72:35-48.
[11] CUI K D,HE L M,ZHANG Z Q,et al.Effects of benzothiazole on survival for reduced reproduction and development in Tribolium castaneum Herbst (Coleoptera:Tenebrionidae)[J].Pest Management Science,2020,76(9):3088-3095.
[12] 毕洁,文明明,喻莉君,等.臭氧在储粮害虫防治中的应用研究进展[J].河南工业大学学报(自然科学版),2022,43(1):131-138.BI Jie,WEN Mingming,YU Lijun,et al.Research progress of ozone application in the control of stored grain pests[J].Journal of Henan University of Technology( Natural Science Edition),2022,43(1):131-138.(in Chinese) [13] ATTIA M A,WAHBA T F,SHAARAWY N,et al.Stored grain pest prevalence and insecticide resistance in Egyptian populations of the red flour beetle Tribolium castaneum (Herbst) and the rice weevil Sitophilus oryzae (L.)[J].Journal of Stored Products Research,2020,87:101611.
[14] 刘蔓文.赤拟谷盗CYP346基因家族介导磷化氢抗性的机理研究[D].南京:南京财经大学,2019.LIU Manwen.Study on the mechanisms of phosphine resistance in Tribolium castaneum(Herbst) based on CYP346 family[D].Nanjing:Nanjing University of Finance and Economics,2019.(in Chinese) [15] JOHNSON J B.An overview of near-infrared spectroscopy (NIRS) for the detection of insect pests in stored grains[J].Journal of Stored Products Research,2020,86:101558.
[16] AHMAD M N,SHARIFF A,ARIS I,et al.Identification and determination of the spectral reflectance properties of live and dead bagworms,Metisa plana WALKER (Lepidoptera:Psychidae) using vis/nir spectroscopy[J].Journal of Oil Palm Research,2021,33(3):425-435.
[17] 苗海委,周慧玲.基于深度学习的粘虫板储粮害虫图像检测算法的研究[J].中国粮油学报,2019,34(12):93-99.MIAO Haiwei,ZHOU Huiling.Detection of stored-grain insects image on sticky board using deep learning[J].Journal of the Chinese Cereals and Oils Association,2019,34(12):93-99.(in Chinese) [18] 高雅.基于图像处理的储粮害虫实时识别技术研究[D].郑州:河南工业大学,2019.GAO Ya.Research on real-time identification technology of stored grain pests based on image processing[D].Zhengzhou:Henan University of Technology,2019.(in Chinese) [19] SRIVASTAVA S,MISHRA G,MISHRA H N.Probabilistic artificial neural network and E-nose based classification of Rhyzopertha dominica infestation in stored rice grains[J].Chemometrics and Intelligent Laboratory Systems,2019,186:12-22.
[20] 张硕,韩少云,熊黎剑,等.基于气敏传感器阵列特征优化的储粮害虫赤拟谷盗检测[J].农业工程学报,2022,38(10):303-309.ZHANG Shuo,HAN Shaoyun,XIONG Lijian,et al.Detection of stored grain pests Tribolium castaneum (Herbst) based on the feature optimization of gas sensor array[J].Transactions of the CSAE,2022,38(10):303-309.(in Chinese) [21] JIA W S,LIANG G,JIANG Z J,et al.Advances in electronic nose development for application to agricultural products[J].Food Analytical Methods,2019,12(10):2226-2240.
[22] NEETHIRAJAN S,KARUNAKARAN C,JAYAS D S,et al.Detection techniques for stored-product insects in grain[J].Food Control,2007,18(2):157-162.
[23] 邵小龙,杨晓静,徐水红,等.基于软X射线成像的储粮害虫米象生长阶段检测[J].农业工程学报,2020,36(18):309-314.SHAO Xiaolong,YANG Xiaojing,XU Shuihong,et al.Detection of the growth stage of rice weevil as a stored-grain pest based on soft X-ray imaging[J].Transactions of the CSAE,2020,36(18):309-314.(in Chinese) [24] BANGA K S,KOTWALIWALE N,MOHAPATRA D,et al.Assessment of bruchids density through bioacoustic detection and artificial neural network (ANN) in bulk stored chickpea and green gram[J].Journal of Stored Products Research,2020,88:101667.
[25] SOLÀ M,LUNDGREN J G,AGUSTÍ N,et al.Detection and quantification of the insect pest Rhyzopertha dominica (F.) (Coleoptera:Bostrichidae) in rice by qPCR[J].Journal of Stored Products Research,2017,71:106-111.
[26] SANAEIFAR A,ZAKIDIZAJI H,JAFARI A,et al.Early detection of contamination and defect in foodstuffs by electronic nose:a review[J].Trac-Trends in Analytical Chemistry,2017,97:257-271.
[27] LEGGIERI M C,MAZZONI M,FODIL S,et al.An electronic nose supported by an artificial neural network for the rapid detection of aflatoxin B-1 and fumonisins in maize[J].Food Control,2021,123:107722.
[28] 沙坤,李思源,张松山,等.高压静电场下发酵牛肉风味品质及微生物群落特性研究[J].农业机械学报,2023,54(10):371-380,398.SHA Kun,LI Siyuan,ZHANG Songshan,et al.Effect of high voltage electrostatic field on the flavor quality and microbial community of fermented beef[J].Transactions of the Chinese Society for Agricultural Machinery,2023,54(10):371-380,398.(in Chinese) [29] 李玉花,史翰卿,熊赟葳,等.融合电子鼻和视觉技术的鸡肉新鲜度检测装置研究[J].农业机械学报,2022,53(11):433-440.LI Yuhua,SHI Hanqing,XIONG Yunwei,et al.Research of chicken freshness detection device based on electronic nose and vision technology[J].Transactions of the Chinese Society for Agricultural Machinery,2022,53(11):433-440.(in Chinese) [30] NOURI B,FOTOUHI K,MOHTASEBI S S,et al.Detection of different densities of Ephestia kuehniella pest on white flour at different larvae instar by an electronic nose system[J].Journal of Stored Products Research,2019,84:101522.
[31] NIU Y H,HUA L,HARDY G,et al.Analysis of volatiles from stored wheat and Rhyzopertha dominica (F.) with solid phase microextraction-gas chromatography mass spectrometry[J].Journal of the Science of Food and Agriculture,2016,96(5):1697-1703.
[32] NIU Y,HARDY G,AGARWAL M,et al.Characterization of volatiles Tribolium castaneum(H.) in flour using solid phase microextraction-gas chromatography mass spectrometry(SPME-GCMS)[J].Food Science and Human Wellness,2016,5(1):24-29.
[33] VILLAVERDE M L,JUAREZ M P,MIJAILOVSKY S.Detection of Tribolium castaneum (Herbst) volatile defensive secretions by solid phase micro extraction-capillary gas chromatography (SPME-CGC)[J].Journal of Stored Products Research,2007,43(4):540-545.
[34] LAOPONGSIT W,SRZEDNICKI G,CRASKE J.Preliminary study of solid phase micro-extraction (SPME) as a method for detecting insect infestation in wheat grain[J].Journal of Stored Products Research,2014,59:88-95.
[35] DUKIC N,ANDRIC G,GLINWOOD R,et al.The effect of 1-pentadecene on Tribolium castaneum behaviour:repellent or attractant?[J].Pest Management Science,2021,77(9):4034-4039.
[36] ALNAJIM I,AGARWAL M,LIU T,et al.A novel method for the analysis of volatile organic compounds (VOCs) from red flour beetle Tribolium castaneum (H.) using headspace-SPME technology[J].Current Analytical Chemistry,2020,16(4):404-412.
