不同成型方法对沥青混合料路用性能和细观结构的影响

任天琦, 张海涛, 张雪芹, 孙俊锋

任天琦, 张海涛, 张雪芹, 孙俊锋. 不同成型方法对沥青混合料路用性能和细观结构的影响[J]. 森林工程, 2022, 38(4): 172-180.
引用本文: 任天琦, 张海涛, 张雪芹, 孙俊锋. 不同成型方法对沥青混合料路用性能和细观结构的影响[J]. 森林工程, 2022, 38(4): 172-180.
REN Tian-qi, ZHANG Hai-tao, ZHANG Xue-qin, SUN Jun-feng. Influence of Different Forming Methods on Road Performance and Meso-structure of Asphalt Mixture[J]. Forest Engineering, 2022, 38(4): 172-180.
Citation: REN Tian-qi, ZHANG Hai-tao, ZHANG Xue-qin, SUN Jun-feng. Influence of Different Forming Methods on Road Performance and Meso-structure of Asphalt Mixture[J]. Forest Engineering, 2022, 38(4): 172-180.

不同成型方法对沥青混合料路用性能和细观结构的影响

基金项目:

黑龙江省交通运输厅重点项目(JTT-2019)

东北林业大学博士基金项目资助(2572021AW10)

详细信息
    作者简介:

    任天琦,硕士研究生。研究方向为路面结构与材料。E-mail:2871521352@qq.com

    通讯作者:

    张海涛,博士,教授。研究方向为路面结构与材料。E-mail:zht6781@163.com

  • 中图分类号: U414

Influence of Different Forming Methods on Road Performance and Meso-structure of Asphalt Mixture

  • 摘要: 为研究不同成型方法对沥青混合料路用性能和空隙结构的影响,采用马歇尔击实仪和旋转压实仪制作了AC-16(粗集料最大公称粒径为16 mm碎石的中粒式沥青混凝土,级配连续)、SUP-16(粗集料最大公称粒径为16 mm碎石的中粒式沥青混凝土,连续级配但有禁区)和PAC-13(粗集料最大公称粒径为13 mm碎石的沥青混凝土,开级配)的沥青混合料试件。以动稳定度、抗弯拉强度和冻融劈裂强度比等作为评价指标,对比分析不同成型方法对其路用性能的影响。同时,采用断面扫描和空隙图像识别(PCAS)进行试件断面的图像处理,分析2种压实条件下不同混合料类型的空隙率、空隙数量和空隙分析维数等结构参数的变化规律。结果表明,采用旋转压实成型方法获得的沥青混合料的路用性能较好,同时,旋转压实成型方法获得的混合料试件断面的空隙参数均小于马歇尔击实成型方法,表明旋转压实能够有效改善沥青混合料内部空隙的结构分布,使沥青混合料试件成型的均匀性更好,路用性能更强。因此,旋转压实试件的路用性能比击实成型试件的路用性能好。
    Abstract: In order to study the effects of different forming methods on road performance and void structure of asphalt mixtures, the specimens of AC-16(Medium grained asphalt concrete with coarse aggregate of maximum nominal particle size 16 mm crushed stone, with continuous gradation), SUP-16(Medium grained asphalt concrete with coarse aggregate of maximum nominal particle size of 16 mm crushed stone, continuously graded but with prohibited areas) and PAC-13(Asphalt concrete with a maximum nominal particle size of 13 mm crushed stone in coarse aggregate, open graded) were fabricated by using Marshall compaction and gyratory compaction instruments. The dynamic stability, flexural tensile strength and freeze-thaw splitting strength ratio were used as evaluation indexes to compare and analyze the effects of different forming methods on their road performance. Meanwhile, section scanning and void image recognition(PCAS) were used for image processing of specimen sections, the change laws of structural parameters such as void ratio, void number and void analysis dimension of different mix types under two compaction conditions were analyzed. The results showed that the asphalt mixes obtained by gyratory compaction molding method had better road properties. At the same time, the void parameters in the cross-section of the specimens obtained by gyratory compaction were smaller than those of Marshall compaction, which indicated that gyratory compaction can effectively improve the structural distribution of the internal voids in asphalt mixture, resulting in better uniformity of the specimens and better road performance. Therefore, the road performance of the rotary compaction specimen was better than that of the compaction specimen.
  • [1] 李林萍,张帆.温拌沥青混合料马歇尔击实和旋转压实密实曲线的比较分析[J].公路工程,2015,40(1):29-32,47.

    LI L P,ZHANG F.Comparative analysis of warm mix asphalt Marshall and gyratory compaction densification curve[J].Highway Engineering,2015,40(1):29-32,47.

    [2] 李智,徐伟,王绍怀,等.不同压实成型沥青混合料的数字图像分析[J].土木工程学报,2003,36(12):68-73.

    LI Z,XU W,WANG S H,et al.Digital image analysis of compacted asphalt mixture with different means[J].China Civil Engineering Journal,2003,36(12):68-73.

    [3] 易富,金艳,苏剑.两种压实方法下沥青混合料空隙分布特性细观分析[J].公路交通科技,2014,31(3):26-31.

    YI F,JIN Y,SU J.Mesoscopic analysis of air void distribution of asphalt mixture in two compaction methods[J].Journal of Highway and Transportation Research and Development,2014,31(3):26-31.

    [4] 周杰,王曦林,郑存艳,等.沥青混合料Superpave与马歇尔设计方法的比较[J].武汉理工大学学报,2007,29(9):68-70.

    ZHOU J,WANG X L,ZHENG C Y,et al.Comparison of Superpave and Marshall methodology on asphalt mixture design[J].Journal of Wuhan University of Technology,2007,29(9):68-70.

    [5] 柴金玲,栗威.基于GTM的沥青混合料配合比设计方法试验研究[J].材料导报,2020,34(S2):1283-1287.

    CHAI J L,LI W.GTM-based experimental study on the asphalt mixtures design[J].Materials Reports,2020,34(S2):1283-1287.

    [6] 谢银博,任剑,朱唐亮,等.基于CT扫描与图像处理技术的沥青混合料空隙特征分析[J].上海公路,2021(1):91-96,121.

    XIE Y B,REN J,ZHU T L,et al.Characterization of voids in asphalt mixtures with different grading methods and different grading types[J].Shanghai Highways,2021(1):91-96,121.

    [7] 颜川奇,杨军,左娜,等.沥青混合料初始空隙分布研究[J].中外公路,2015,35(5):296-301.

    YAN C Q,YANG J,ZUO N,et al.Study on initial void distribution of asphalt mixture[J].Journal of China&Foreign Highway,2015,35(5):296-301.

    [8] 杨瑞华,彭妙娟.沥青混合料设计成型方法对SAC沥青混合料路用性能的影响[J].土木工程与管理学报,2018,35(3):96-99,105.

    YANG R H,PENG M J.Study on influence of molding method of asphalt mixture design on road performance of SAC asphalt mixture[J].Journal of Civil Engineering and Management,2018,35(3):96-99,105.

    [9] 何兆益,官志桃,刘奕,等.多孔沥青混合料旋转压实特性与动态模量[J].科学技术与工程,2021,21(19):8204-8211.

    HE Z Y,GUAN Z T,LIU Y,et al.Gyratory compaction characteristics and dynamic modulus of porous asphalt mixture[J].Science Technology and Engineering,2021,21(19):8204-8211.

    [10]

    ZHANG H T,YU T J,HUANG Y L.Comparative analysis of HMA aggregate variability based on impacting and gyratory compaction[J].Construction and Building Materials,2020,242:118055.

    [11] 张海涛,于腾江.Marshall与Superpave沥青混合料压实次数关系的研究[J].公路交通科技,2015,32(10):25-29.

    ZHANG H T,YU T J.Study on relationship between compacting numbers of Marshall asphalt mixture and Superpave asphalt mixture[J].Journal of Highway and Transportation Research and Development,2015,32(10):25-29.

    [12] 刘佳,孟宪东,彩雷洲.不同成型方式对排水沥青混合料性能的影响研究[J].西部交通科技,2021(2):20-24.

    LIU J,MENG X D,CAI L Z.Study on the influence of different forming ways on the performance of drainage asphalt mixture[J].Western China Communications Science&Technology,2021(2):20-24.

    [13] 李鹏飞,张海涛,马盛盛,等.不同成型方法对沥青混合料回弹模量的影响[J].科学技术与工程,2019,19(32):322-325.

    LI P F,ZHANG H T,MA S S,et al.Influence of forming method on resilient modulus of asphalt mixture[J].Science Technology and Engineering,2019,19(32):322-325.

    [14] 胡财军.不同成型方法对高速公路沥青混合料回弹模量的影响[J].交通世界,2021(23):35-36.

    HU C J.Influence of different forming methods on springback modulus of expressway asphalt mixture[J].Transpo World,2021(23):35-36.

    [15] 田引安.热再生沥青混合料精细化设计与路用性能研究[J].公路工程,2022,47(1):142-148.

    TIAN Y N.Study on delicacy design and pavement performance of hot recycled asphalt mixture[J].Highway Engineering,2022,47(1):142-148.

    [16]

    CHENG Y C,BI H P,GONG Y F,et al.Comparative research on Superpave Gyratory Compaction method and Marshall Compaction method in the mix design of AC-16[C]//Proceedings 2011International Conference on Transportation,Mechanical,and Electrical Engineering (TMEE).December 16-18,2011,Changchun.IEEE,2011:2383-2385.

    [17]

    AL-HUMEIDAWI B H.Experimental characterization of rutting performance of HMA designed with aggregate gradations according to Superpave and Marshall methods[J].World Journal of Engineering and Technology,2016,4(3):477-487.

    [18] 朱洪洲,谭祺琦,范世平,等.基于图像技术的沥青混合料细观结构研究进展[J].重庆交通大学学报(自然科学版),2021,40(10):97-110.

    ZHU H Z,TAN Q Q,FAN S P,et al.Research progress of bituminous mixture meso-structure based on image technology[J].Journal of Chongqing Jiaotong University (Natural Science),2021,40(10):97-110.

    [19] 顾盛,陈满军,林莉,等.大空隙沥青混凝土空隙堵塞特性研究[J].森林工程,2021,37(3):126-130.

    GU S,CHEN M J,LIN L,et al.Study on the clogging characterization of large void asphalt concrete[J].Forest Engineering,2021,37(3):126-130.

    [20] 吕悦晶,刘标,张蕾,等.沥青混合料空隙特性分析及多重分形研究[J].中外公路,2021,41,260(2):273-280.

    LYU Y J,LIU B,ZHANG L,et al.Research on void characteristics and multifractal of asphalt mixture[J].Sino-foreign Highway,2021,41(2):273-280.
