近断层地震动组合斜入射下沥青混凝土面板堆石坝响应研究

许斯年; 宋志强; 李闯

近断层地震动组合斜入射下沥青混凝土面板堆石坝响应研究

西安理工大学省部共建西北旱区生态水利国家重点实验室

基金项目:

国家自然科学基金重点项目(52039008)

陕西省自然科学基础研究计划面上项目(2022JM-276)

陕西省教育厅青年创新团队科研计划项目(22JP052)

详细信息

作者简介:
许斯年(1999—),男,陕西西安人,硕士研究生,研究方向为水工结构抗震

通讯作者:
宋志强(1981—),男,辽宁开原人,博士,教授,博士生导师,主要从事水工结构抗震研究

中图分类号: TV641.4;TV312
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2023-10-11
- 刊出日期: 2024-08-27

Seismic response of asphalt concrete face rockfill dam under combined oblique incidence of near-fault ground motions

State Key Laboratory of Eco-hydraulics in Northwest Arid Region of China, Xi’an University of Technology

摘要

摘要: 西部地区水利工程多建于复杂地震断裂带附近，因此近场地震动的脉冲效应对水工建筑物所产生的影响不可忽略。近断层地震动往往由P波、SV波等共同组成，到达地表后明显带有一定角度，垂直入射假定不再适用，因此有必要开展近断层脉冲型地震动组合斜入射对沥青混凝土面板堆石坝地震响应影响的研究。基于地表二维地震动反演确定P波、SV波斜入射时程，构建近断层地震动组合斜输入模型，选取脉冲型和非脉冲型各5条地震动记录，研究近断层地震动组合斜入射对沥青混凝土面板加速度、应力和坝体永久变形的影响规律。结果表明：与地震动垂直入射相比，面板水平向加速度随P波角度的增大而增大，随SV波角度的增大而减小，竖向加速度及坝体永久变形的规律则相反；面板拉应力随着P波、SV波角度的增大而增大；近断层地震动的脉冲特性对堆石坝的响应有显著放大作用，其中面板拉应力最大增加了116%。
- 沥青混凝土面板堆石坝 /
- 近断层地震动 /
- 组合斜入射 /
- 脉冲效应 /
- 地震响应
Abstract: Water conservancy projects in the western region of China are mostly built near complex earthquake fault zones, and the pulse-like effect of near-field ground motions on hydraulic structures cannot be ignored. The near-fault ground motion is often composed of P-waves and SV-waves. When the seismic waves reach the surface, they often hit the ground at a certain angle, and the assumption of vertical incidence is no longer applicable. Therefore, it is necessary to clarify the impact of combined oblique incidence of near-fault pulse-like ground motions on the seismic response of asphalt concrete face rockfill dams. Based on the surface two-dimensional seismic motion inversion, the oblique incidence time history of P-waves and SV-waves were obtained, and a combined oblique incidence model of near-fault ground motions was constructed. Five pulse-like and non-pulse-like ground motions were selected to study the influence of the combined oblique incidence of near-fault ground motions on the acceleration, stress, and permanent deformation of asphalt concrete panels. The results show that compared to the vertical incidence of ground motions, the horizontal acceleration of the panel increases with the increase of P-wave angle and decreases with the increase of SV-wave angle, while the vertical acceleration of the panel and permanent deformation of the dam body are on the opposite; the tensile stress of the panel increases with the increase of P-wave and SV-wave angles; the pulse-like characteristics of near-fault ground motions have a significant amplification effect on the seismic response of the dam, with a maximum increase of 116% in panel tensile stress.
- asphalt concrete face rockfill dam /
- near-fault ground motion /
- combined oblique incidence /
- pulse-like effect /
- seismic response

HTML全文

参考文献(24)

[1]	李闯,宋志强,王飞.P波空间斜入射下沥青混凝土面板堆石坝响应特性及面板破坏评价[J/OL].工程科学与技术:1-14 [2023-09-21]. https://doi.org/10.15961/j.jsuese.202201174.
[2]	李爽,谢礼立.近场问题的研究现状与发展方向[J].地震学报,2007,29(1):102-111+114.
[3]	HEBBOUCHE A,BENSAIBI M,MROUEH H.Seismic risk analysis of concrete gravity dams under near-fault ground motions[J].Applied Mechanics and Materials,2013,256:2240-2243.
[4]	GORAI S,MAITY D.Seismic response of concrete gravity dams under near field and far field ground motions[J].Engineering Structures,2019,196:109292.
[5]	AKKÖSE M,SIMSEK E.Non-linear seismic response of concrete gravity dams to near-fault ground motions including dam-water-sediment-foundation interaction[J].Applied Mathematical Modelling,2010,34(11):3685-3700.
[6]	BAYRAKTAR A,ALTUNISIK A C,SEVIM B,et al.Near-fault ground motion effects on the nonlinear response of dam-reservoir-foundation systems[J].Structural Engineering and Mechanics,2008,28(4):411-442.
[7]	JIANG Qiuting,ZOU Degao,HAN Huichao,et al.Dynamic response of concrete face rockfill dam affected by polarity reversal of near-fault earthquake[J].Earthquake Engineering and Engineering Vibration,2022,21(1):81-99.
[8]	邹德高,韩慧超,孔宪京.近断层脉冲型地震动作用下面板堆石坝的动力响应[J].水利学报,2017,48(1):78-85.
[9]	邹德高,韩慧超,孔宪京,等.近断层地震动作用下面板堆石坝的加速度分布系数[J].水利学报,2018,49(10):1236-1242.
[10]	唐彧杰,张燎军,翟亚飞,等.近断层地震动作用下混凝土高拱坝损伤特性研究[J].水电能源科学,2021,39(6):64-68.
[11]	刘琳,宋志强,王飞,等.近断层SV波斜入射下沥青混凝土心墙坝响应分析[J].振动与冲击,2021,40(21):97-105.
[12]	宋志强,刘琳,王飞,等.近断层P波斜入射下沥青混凝土心墙坝响应分析[J].振动与冲击,2023,42(7):245-253.
[13]	王飞.空间非一致波动输入下沥青混凝土心墙坝地震响应特性研究[D].西安:西安理工大学,2022.
[14]	何卫平,熊堃,卢晓春.确定性地震动空间差异对重力坝地震响应影响研究[J].水利学报,2019,50(8):913-924.
[15]	李闯,宋志强,王飞,等.地震动空间差异对沥青混凝土心墙土石坝-覆盖层地基系统响应影响研究[J].振动与冲击,2022,41(19):37-47.
[16]	王飞,宋志强,卢韬.近断层地震动斜输入下水电站厂房非线性地震响应研究[J].振动与冲击,2020,39(5):63-73.
[17]	WANG Fei,SONG Zhiqiang,LIU Yunhe,et al.Construction of the spatially varying ground motion field of a bedrock-overburden layer site and its influence on the seismic response of earth-rock dams[J].Arabian Journal of Geosciences,2021,14(18):1914.
[18]	王飞,宋志强,刘云贺,等.SV波斜入射不同自由场构建方法下水电站地面厂房地震响应研究[J].振动与冲击,2021,40(7):9-18.
[19]	刘晶波,吕彦东.结构-地基动力相互作用问题分析的一种直接方法[J].土木工程学报,1998,21(3):55-64.
[20]	马笙杰,迟明杰,陈红娟,等.黏弹性人工边界在ABAQUS中的实现及地震动输入方法的比较研究[J].岩石力学与工程学报,2020,39(7):1445-1457.
[21]	余翔,孔宪京,邹德高,等.覆盖层中混凝土防渗墙的三维河谷效应机制及损伤特性[J].水利学报,2019,50(9):1123-1134.
[22]	傅华,陈生水,凌华,等.高应力状态下堆石料工程特性试验研究[J].水利学报,2014,45(S2):83-89.
[23]	迟世春,吕小龙,贾宇峰.堆石料的动力残余应变模型[J].岩土工程学报,2016,38(2):370-376.
[24]	邹德高,孟凡伟,孔宪京,等.堆石料残余变形特性研究[J].岩土工程学报,2008,30(6):807-812.
