Analysis of floodgate pier vibration induced by underflow dissipation and vibration reduction measures
-
摘要: 底流式泄洪闸在大流量泄洪时常伴随着闸墩剧烈振动。针对泄洪闸闸墩振动问题，以某水电站为例，基于水弹性物理模型试验和原型观测，提出改善闸墩结构和优化水库调度方案的两种减振措施。物理模型试验为研究闸墩振动提供了数据支撑，而原型观测结果验证了模型试验的可靠性。结果表明：当泄流量为5 400 m3/s时，通过优化水库调度，采用“低孔+表孔”联合泄洪的方式，表孔的泄流量从单独泄洪时的5 400 m3/s转变为联合泄洪时的低孔泄流量3 481 m3/s+表孔泄流量1 919 m3/s,表孔闸墩的振动位移标准差可从182.3μm减小到51.7μm,振动削减效果为71.6%;当表孔泄流量为10 030 m3/s时，通过对闸墩进行加固，闸墩的振动位移标准差可由288.8μm减小到129.6μm,振动削减效果为55.1%。Abstract: Underflow dissipation floodgates are subjected to severe pier vibrations during high-flow discharge. Addressing to this issue, the hydraulic elasticity model test and prototype observation of a hydropower station were conducted, with which two vibration reduction measures of improving pier structure and optimizing reservoir regulation schemes were proposed. The model test provided data support for the analysis of pier vibrations, while the prototype observation validated the reliability of the model test. When the discharge flow is 5 400 m~3/s, the combined discharge approach of “low orifices and surface orifices” can reduce the flow through surface orifices from 5 400 m~3/s in standalone discharge to 1 919 m~3/s in combined discharge, and the rest 3 481 m~3/s can discharge from the low orifices. In this case, the standard deviation of pier vibration displacement at surface orifices decreases from 182.3 to 51.7 μm, achieving a vibration reduction effect of 71.6%. When the discharge from the surface orifices reaches 10 030 m~3/s, reinforcing the piers can reduce the standard deviation of pier vibration displacement from 288.8 to 129.6 μm, leading to a vibration reduction effect of 55.1%.
-
-
[1] 王睿齐,王海军,沈春颖,等.底流消能工水流结构与掺气浓度分布试验研究[J].水电能源科学,2021,39(5):113-117. [2] 邓淇,沈春颖,马江霞.平面闸门流激振动分析及防振措施[J].中国水运,2021(12):112-114. [3] ZHANG Bozhi,JING Xiaochuan.Theoretical analysis and simulation calculation of hydrodynamic pressure pulsation effect and flow induced vibration response of radial gate structure[J].Scientific Reports,2022,12(1):21932.
[4] ZHOU Chenguang,ZOU Degao,YU Xiang.Influence of seismic wave type and incident direction on the dynamic response of tall concrete-faced rockfill dams[J].Earthquake Science,2022,35(5):343-354.
[5] 何小敏,张浩,齐春风.水电站闸墩-闸门-水体流激振动特性研究[J].西北水电,2020(6):127-132. [6] 胡木生,杨志泽,张兵,等.蜀河水电站弧形闸门原型观测试验研究[J].水力发电学报,2016,35(2):90-100. [7] 安娜.观音阁水库闸墩流激振动与减振措施研究[J].水利规划与设计,2017(4):85-87. [8] 余春海.水利枢纽闸墩泄洪振动原型动力检测与安全评价[J].水利技术监督,2017,25(4):22-24. [9] 陈林,杨敏,李火坤,等.泄洪闸闸墩抗振加固措施研究[J].水利水电技术,2016,47(9):28-33+49. [10] SINGH D K,PAL P,DUGGAL S K.Dynamic pressure on lock gate structure coupled with fluid[J].Vibro Engineering Procedia,2019,29:165-170.
[11] SINGH D K,PAL P,DUGGAL S K.Free vibration analysis of stiffened lock gate structure[J].Journal of Vibration Engineering&Technologies,2018,45(1):1-9.
[12] 苏圣致,杨春霞,饶天华,等.不同开度下某闸门流激振动数值模拟研究[J].水利水电技术(中英文),2023,54(9):148-155. [13] 刘计良,奚宏林,司政,等.基于流固耦合的弧形闸门-闸墩体系的流激振动研究[J].水资源与水工程学报,2023,34(5):149-154+171. [14] 张龑,练继建,李松辉,等.高坝泄洪诱发场地振动传播问题的有限元-无限元耦合分析[J].振动与冲击,2018,37(15):14-26+58. [15] 梁超.高坝泄流诱发结构和场地振动机理和减振方法研究[D].天津:天津大学,2017. [16] 李成业,张龑.高坝泄流诱发底流消能泄水建筑物振动特性试验研究[J].水利水电技术,2015,46(12):53-57. [17] 张艺莹.基于ANSYS预应力闸墩的流激振动分析和减振措施研究[D].郑州:华北水利水电大学,2019. [18] 何小敏.泄洪闸闸墩流激振动特性与加固措施研究[D].天津:天津大学,2014. [19] LI Huokun,ZHONG Yiwei,WEI Bowen,et al.Beat vibration mechanism of a sluice pier under high-speed flood discharge excitation[J].Journal of Low Frequency Noise Vibration and Active Control,2020,39(1):28-43.
[20] 李成业,徐瑛丹.基于ANSYS有限元分析的闸墩流激振动数值模拟[C]//中国水利学会.2023中国水利学术大会论文集(第五分册).郑州:黄河水利出版社,2023. [21] 中华人民共和国住房和城乡建设部,中华人民共和国国家质量监督检验检疫总局.建筑工程容许振动标准:GB 50868-2013[S].北京:中国计划出版社,2013. [22] 张雯雯.水工泄水建筑物振动安全评价方法研究[D].南昌:南昌大学,2015.
