Development of a Portable Calibration System for a Multifunctional Power Platform Based on CODESYS
-
摘要: 基于CODESYS平台开发了一款工具系统，既能在产品下线时，辅助精确装配角度传感器，标定空挡位置等，又能在田间使用时，灵活智能化调整车速、作业施肥量、播种量等，提高产品可靠性的同时，增加了用户的操作体验感。开发的系统，标定对象主要为：电动推杆、角度传感器、左/右速度传感器、施肥电机等。开发的工具系统交付用户，于生产线和田间实际使用，经过便携式、智能化的标定功能的测试，既验证提高了关键零部件的系统可靠性，又验证了开发工具系统的功能性。Abstract: In this paper, a a tool based on CODESYS platform is developed, which not only assists in precise assembly of angle sensor and calibration of neutral position on the production line, but also flexibly and intelligently adjusts the speed, operation fertilization amount, seeding amount, etc.In the field it is used to improve the reliability of the product and enhance the user’s operating experience.The system developed in this paper mainly calibrates electric rods, angle sensors, left/right speed sensors, fertilization motors, etc.It has been delivered to users for practical use on production lines and fields.After testing with portable and intelligent calibration functions, it has not only verified the improvement of the system reliability of key components, but also verified the functionality of the tool system developed in this paper.
-
Keywords:
- Key parts /
- Calibration system /
- Control system /
- Intelligent adjustment
-
-
[1] 曾山,姚腊梅,李凝,等.气吸式辣椒精量穴直播机的研制与试验[J].华南农业大学学报,2020,41(3):102-109. [2] 刘娇,徐国华.物联网在规模化辣椒种植生长分析中的应用[J].农机化研究,2020,42(9):238-242. [3] 朱凤武,岳仕达,于丰华,等.基于电动推杆的玉米剥皮机角度控制系统[J].吉林农业大学学报,2014,36(3):366-370. [4] 宋纪元,朱爱斌,屠尧,等.单兵救援助力外骨骼机器人的设计与特性分析[J].兵工学报,2022,43(9):2037-2047. [5] 周文娟.遥控变速系统中电动推杆式换向与遥控装置的研究[D].沈阳:东北农业大学,2016. [6] 董笑辰,马晨普,王雪迪.内燃电传动拖拉机电传动及控制系统的设计[J].拖拉机与农用运输车,2020,47(1):44-47.
