Measurement and Control System of Agricultural Greenhouse based on Harmony OS and OTA Technology
-
摘要: 针对目前农业大棚物联网终端软件升级灵活性低、维护成本较高，棚内环境监控智能化程度低等问题，设计了一种基于鸿蒙系统和OTA技术（Over-The-Air technology，空中下载技术）的农业大棚测控系统。在OTA固件升级过程中加入签名、验签流程，确保OTA文件的合法性和完整性，提高系统的安全性。采用Hi3861 WLAN模组搭载鸿蒙系统，结合环境参数传感器模块、OLED显示模块实现对空气温湿度、光照强度、二氧化碳浓度等环境参数的实时采集和显示。使用WiFi通信结合MQTT(Message Queuing Telemetry Transport，消息队列遥测传输)协议将基于Django开发的Web设备管理系统和基于鸿蒙系统的终端设备相结合，通过浏览器登录Web设备管理系统，可实现系统的远程控制，如查看环境数据、开/关照明设备或通风电机等，可实现对终端设备进行OTA固件升级。测试结果表明，该系统能够有效地完成空气温度、空气湿度、光照强度、二氧化碳浓度等环境数据的实时监测，能够通过Web设备对终端环境进行远程监测和控制，对终端设备进行OTA固件升级。Abstract: Aiming at the problems of low flexibility and high maintenance cost for the upgrade and maintenance of the Internet of Things terminal software in agricultural greenhouses, and low intellectualization of environmental monitoring in the greenhouses, an agricultural greenhouses measurement and control system based on Harmony OS and OTA technology（Over-The-Air technology） was researched and designed. To ensure the validity and integrity of the OTA file and improve the security of the system, the signature and verification processes are added during the OTA firmware upgrade process. In this study, the Hi3861 WLAN module equipped with Harmony OS, combined with the environmental parameter sensor module and the OLED display module, realizes the real-time acquisition and display of environmental parameters such as air temperature and humidity, light intensity, and carbon dioxide concentration. Using WiFi communication combined with MQTT（Message Queuing Telemetry Transport） protocol, the Web device management system based on Django and the terminal device based on Harmony OS were combined. The greenhouse environment data can be viewed, the greenhouse facilities can be controlled accordingly, and the OTA firmware upgrade of the terminal equipment can be carried out. The test results show that the system can effectively complete the real-time monitoring of the agricultural greenhouse air temperature, air humidity, light intensity, carbon dioxide concentration, and other environmental data, and can remotely monitor and control the agricultural greenhouse through the Web equipment management system, and can perform OTA firmware upgrade of the terminal equipment.
-
Keywords:
- Harmony OS /
- OTA technology /
- agricultural greenhouse /
- MQTT protocol
-
-
[1] 魏守辉,肖雪梅,钟源,等.日光温室不同时段补光对番茄果实品质及挥发性物质影响[J].农业工程学报,2020,36(8):196-204. [2] 赵荣阳,王斌,姜重然,等.基于物联网的农业大棚生产环境监控系统设计[J].农机化研究,2021,43(11):131-137. [3] 汪言康,周建平,许燕,等.基于物联网的温室大棚智能监控系统研究[J].机床与液压,2019,47(17):103-107,70. [4] 姚引娣,王磊,花静云,等.基于B/S架构的LoRa远程温室监测系统[J].传感器与微系统,2021,40(1):78-80,84. [5] 梁志勋,施运应,覃有燎,等.基于MQTT协议的智慧农业大棚测控系统研究[J].北方园艺,2020(23):161-171. [6] MAHFOUDHI F,SULTANIA A K,FAMAEY J.Overthe-air firmware updates for constrained nb-iot devices[J]. Sensors, 2022, 22(19):2169.
[7] RADOVICI A, CULIC I, ROSNER D, et al. A model for the remote deployment, update, and safe recovery for commercial sensor-based IoT systems[J].Sensors,2020, 20(16):4393.
[8] 沈周锋,郑慧珍.基于鸿蒙系统的农业监测器的研究[J].九江学院学报(自然科学版),2022,37(1):59-62. [9] 郭德财,彭石林.基于海思芯片与鸿蒙操作系统的智慧灌溉系统设计[J].单片机与嵌入式系统应用,2022,22(3):11-15. [10] 汤隆.利用RSA密码数字签名实现网络安全的应用系统设计[J].电脑知识与技术,2018,14(22):29-31. [11] 张键红,肖晗,王继林.高效的基于身份RSA多重数字签名[J].小型微型计算机系统,2018,39(9):1978-1981. [12] 李可,石兆军,周晓俊,等.基于MD5加密的身份认证系统研究[J].网络安全技术与应用,2022(7):21-23. [13] 樊志英.关于加密数据的填充方式的研究[J].现代电子技术,2014,37(22):20-23. [14] 汪洋,姜新通.MVC框架在Python与Django下的设计研究[J].电脑与信息技术,2021,29(1):55-57,63. [15] 陈相余.云平台下消息推送系统的设计与实现[D].成都:电子科技大学,2021. -
