Mohr-Coulomb Failure Criterion of Ultra-high Performance Concrete is Based on the Shear Strength Parameters
-
摘要: 通过对4种钢纤维体积含量（0%、1%、2%和3%）的超高性能混凝土在5档围压（0、10、20、40和60 MPa）下进行常规三轴压缩试验，基于直线型摩尔强度包络线及试验数据推导出每种钢纤维含量超高性能混凝土在不同围压下内摩擦角φ和黏聚力c，由c值和φ值计算确定Mohr-Coulomb破坏准则中的参数，得到不同围压不同钢纤维含量下的MohrCoulomb破坏准则，经检验这种随围压与钢纤维含量不同而变参数值的Mohr-Coulomb破坏准则能较好的描述超高性能混凝土三轴抗压强度的发展规律。Abstract: Through the conventional triaxial compression experiment of ultra-high performance concrete with 4 kinds of steel fiber volume contents（0%,1%,2% and 3%）at 5 grades confining pressures（0,10,20,40 and 60 MPa）, The specific values of internal friction angle φ and adhesion c in different confining pressure of each steel fiber content ultra-high performance concrete are deduced from the test data, the parameter in the Mohr-Coulomb failure criterion is determined by the c and φ values, and the specific expression of Mohr-Coulomb failure criterion under different confining pressures and different steel fiber contents are obtained too. It is found that the Mohr-Coulomb failure criterion can better describe the development law of the triaxial compressive strength of ultra-high performance concrete.
-
-
[1] 张倩倩,魏亚,张景硕,等.钢纤维掺量对活性粉末混凝土断裂性能的影响[J].建筑材料学报,2014,17(1):24-29. ZHANG Q Q,WEI Y,ZHANG J S,et al. Influence of steel fiber content on fracture properties of RPC[J]. Journal of Building Materials,2014,17(1):24-29.
[2] 鞠杨,贾玉丹,刘红彬,等.活性粉末混凝土钢纤维增强增韧的细观机理[J].中国科学(E辑:技术科学),2007,37(11):1 403-1 416. JU Y,JIA Y D,LIU H B,et al. Strengthening and toughening mechanisms of reactive powder concrete by steel fiber[J]. Science in china(Series E:Technological Sciences,in Chinese),2007,37(11):1 403-1 416.
[3] 鞠杨,刘红彬,陈健,等.超高强度活性粉末混凝土的韧性与表征方法[J].中国科学(E辑:技术科学),2009,39(4):793-808. JU Y,LIU H B,CHEN J,et al.Toughness and characterization method of ultra high strength active powder concrete[J]. Science in China(Series E:Technological Sciences,in Chinese),2009,39(4):793-808.
[4] 王晓飞,王阳平.钢纤维活性粉末混凝土力学特性[J].建筑材料学报,2015,18(6):942-945. WANG X F,WANG Y P.Mechanical properties of RPC with different steel fiber volume contents[J]. Journal of Building Materials,2015,18(6):942-945.
[5] 安明喆,王华,王月,等.超高性能混凝土在海水冻融作用下的耐久性[J].中国铁道科学,2018,39(2):1-7. AN M Z,WANG H,WANG Y,et al.Durability of reactive powder concrete under action of seawater freeze-thaw cycle[J]. China railway science,2018,39(2):1-7.
[6] 闫光杰.200 MPa级活性粉末混凝土(RPC200)的破坏准则与本构关系研究[D].北京:北京交通大学,2005. YAN G J.Study on failure criterion and constitutive relationship of200 MPa reactive powder concrete(RPC 200)[D]. Beijing:Beijing jiaotong University,2005.
[7] 余自若,秦鑫,安明喆.活性粉末混凝土的常规三轴压缩性能试验研究[J].中国铁道科学,2012,33(2):38-42. YU Z R,QING X,AN M Z. Experimental research on the conventional triaxial compressive properties of reactive powder concrete[J].China railway science,2012,33(2):38-42.
[8] 仵鹏涛.三向应力状态下超高性能混凝土材料静态力学性能研究[D].天津:天津大学,2019. WU P T. Study of static mechanical properties of ultra high performance concrete under triaxial stress states[D]. Tianjin:Tianjin University,2019.
[9] 梁伟,吴佩刚,赵光仪,等.高强混凝土三轴强度规律与破坏准则[J].建筑结构,2003,33(1):17-19. LIANG W,WU P G,ZHAO G Y,et al. Triaxial strength law and failure criterion of high-strength concrete[J]. Building structure, 2003,33(1):17-19.
[10] 周俊.三向应力状态下高性能混凝土的本构关系研究[M].合肥:合肥工业大学,2011. ZHOU J. A study on constitutive relationship of high performance concrete under triaxial stress states[M]. HeFei,HeFei university of technology,2011.
[11] OTTOSEN N S. A failure criterion for concrete. Journal of ASCE,1977,103(EM4):527-535.
[12] 吴礼程,王哲,刘迪,等.围压及钢纤维掺量对超高性能混凝土力学特性的影响[J].建筑材料学报,2018,21(2):208-215. WU L C,WANG Z,LIU D,et al. Effect of confining pressure and steel fiber volume content on mechanical property of reactive powder concrete[J]. Journal of Building Materials, 2018,21(2):208-215.
[13] 王晓飞,周海龙,王海龙.超高性能混凝土的抗剪强度[J].硅酸盐学报,2022,50(8):1-6. WANG X F,ZHOU H L,WANG H L. Shear strength of ultra high performance concrete[J]. Journal of the Chinese Ceramic Society.2022,50(8):1-6.
