利用滤光膜和反光作用的新型农光互补方阵原理与建模分析

侯孟婧1; 2

doi:10.13733/j.jcam.issn.2095-5553.2022.03.017

利用滤光膜和反光作用的新型农光互补方阵原理与建模分析

侯孟婧1,
2

1. 国家能源集团绿色能源与建筑研究中心;
2. 北京低碳清洁能源研究院

基金项目:

国家能源集团科技创新项目(GJNY—19—100)

详细信息

作者简介:
侯孟婧,女,1989年生,北京人,博士,工程师,研究方向为光伏农业和光伏发电系统。E-mail:1504127340@qq.com

中图分类号: S214;TM615
计量
- 文章访问数: 1
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2021-05-30
- 刊出日期: 2022-03-14

Principle and modeling analysis of an agro-photovoltaic system using filter film and light reflection

HOU,
2

1. National Institute of Clean-and-Low-Carbon Energy

摘要

摘要: 农光互补作为将光伏发电与农业生产有机结合的新能源应用形式，具有重要的生态效益和经济收益潜力，但因难以解决光伏组件和农作物采光分配的问题而推广不力。设计一种新型农光互补方阵，在光伏组件表面镀制由11层SiO₂膜和11层TiO₂膜组成的滤光多层膜，将农作物光合作用所需的红光和蓝光分离出来，通过方阵倾角的实时调整构成的反射光路照射到地面上，而其他波段的光则透过滤光膜，照射太阳能电池，进行光伏发电。设计该方阵的组件排布形式和阵列间距，使用PVsyst软件建模，计算方阵的发电量和阵列间地面光照，计算结果表明其发电量虽然低于常规固定倾角方阵，但阵列间地面光照增加27.26%，有助于提高农作物的产量，从而提高农光互补项目的综合效益。
- 农光互补 /
- 光伏阵列 /
- 滤光多层膜 /
- PVsyst建模
Abstract: As a new energy application form that organically combines photovoltaic（PV） power generation and agricultural production,agro-photovoltaic integrating system has important ecological benefits and economic potential. However, suffering for the problem of photovoltaic modules and crop lighting distribution, it is difficult to apply it widely. In this regard, a new type of agro-photovoltaic system was designed. A multilayer film filter comprising of 11 layers of SiO₂ film and 11 layers of TiO₂ film was coated on the surface of photovoltaic modules to separate the red and blue light required for crop photosynthesis from solar spectrum. Through real-time adjustment of the inclination of the PV array, the reflected light kept illuminating the ground, while other wavelengths of light passed through the filter film and illuminated the solar cell, leading to generation of photovoltaic power. The PV modules arrangement and spacing of the PV array was designed, and the power generation of the PV array and the ground illumination between the arrays were calculated with PVsyst software modelling. The calculation results showed that although its power generation was lower than the conventional fixed inclination square array, the ground illumination between the arrays had increased by 27.26%, which helped to increase the yield of crops, thereby increasing the comprehensive benefits of the agro-photovoltaic projects.
- agro-photovoltaic /
- PV array /
- multilayer film filter /
- PVsyst software modelling

HTML全文

参考文献(16)

[1]	何旨羿.我国农光互补发展现状及前景分析[J].科技经济导刊,2016,5:113.
[2]	高智丹,任超.我国农光互补技术的发展及前景[J].农家参谋,2018,No.583(10):13.
[3]	张小杭,崔寿福,刘福平.光伏农业的发展概况[J].安徽农业科学,2015,43(19):229-231. Zhang Xiaohang,Cui Shoufu,Liu Fuping.Development survey of photovoltaic agriculture[J].Journal of Anhui Agricultural Sciences,2015,43(19):229-231.
[4]	刘润宝,周宇昊,谢玉荣.江苏仪征大仪100 MWp农光互补发电项目研究[J].节能,2017(3).
[5]	赵斌,汪树升,张文婷.不同结构的光伏温室经济效益对比分析[J].太阳能,2015(11):63-65.
[6]	王泽国,王磊,吉春明.农业大棚光伏结构体系的优化设计研究[J].太阳能,2018(12):67-69,76.
[7]	齐金龙.河北某地区农光互补发电工程研究[D].保定:华北电力大学,2016.
[8]	沈道军,盛春,杨松,等.林农光伏电站实例分析[J].太阳能,2016(2):13,34-36.
[9]	马志强,张振国,张盈.光伏农业产业发展探讨[J].现代农业科技,2019(14):238,240.
[10]	虞建春.“农业+光伏”电站的优化设计探析[J].科技创新与应用,2019(11):89-90.
[11]	欧浪情,何子力,刘路青,等.红,蓝双通道滤光膜对植物生长的影响[J].植物生理学报,2016,52(12):1909-1914.
[12]	张昕昱,张智深,张放心,等.基于植物光合作用的太阳光谱分离技术进展[J].照明工程学报,2018,29(4):17-21.
[13]	Enami Y,Yuan B,Tanaka M,et al.Electro-optic polymer/Ti O2multilayer slot waveguide modulators[J].Applied Physics Letters,2012,101(12):3335.
[14]	张杨,王维,圣桂金,等.Ti O2/Si O2纳米多层膜光学特性研究[J].红外,2007,28(2):12-14.
[15]	连松友,姜国利,余云鹏,等.蓝光过滤多层功能薄膜的遗传算法设计[J].表面技术,2017,46(8):170-175.
[16]	张雪.TiO2/金属(氧化物)多层膜光学特性的研究[D].太原:太原理工大学,2012. Zhang Xue.Study on the optical properties of Ti O2/metal(dioxide) multilayer films[D].Taiyuan:Taiyuan University of Technology,2012.
