双辊式食用菌培养料翻堆机翻堆装置设计与试验

王善文; 谢秋菊; 谢守勇; 邓成志; 黎展鹏

doi:10.13733/j.jcam.issn.2095-5553.2023.02.007

双辊式食用菌培养料翻堆机翻堆装置设计与试验

1. 西南大学工程技术学院;
2. 西南大学丘陵山区农业装备重庆市重点实验室

基金项目:

重庆市社会事业与民生保障科技创新专项重点研发项目(cstc2017shms-zdyfX0006)

详细信息

作者简介:
王善文,男,1997年生,重庆开州人,硕士研究生,研究方向为智能检测与控制。E-mail:353592544@qq.com

通讯作者:
谢守勇,男,1969年生,重庆开州人,博士,教授,研究方向为农业智能装备,智能检测与控制。E-mail:xsyswu@163.com

中图分类号: S223
计量
- 文章访问数: 2
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2021-11-07
- 刊出日期: 2023-02-14

Design and experiment on turning device of turning machine for double-roller type edible fungus culture material

1. College of Engineering and Technology, Southwest University;
2. Chongqing Key Laboratory of Agricultural Equipment in Hilly and Mountainous Areas, Southwest University

摘要

摘要: 为解决现阶段食用菌生产基地人工翻堆方式存在作业环境差、劳动强度大、工作效率低以及物料混合不均等问题，提出一种双辊式翻堆装置的翻堆机。该翻堆装置利用双螺旋方式对抛刀进行分布设计，根据分层切削原理，利用小半径抛刀作业来实现较大翻堆深度；通过构建双辊翻堆的离散元仿真模型，利用EDEM软件对翻堆装置的工程进程和不同工况下颗粒流动、碰撞和抛撒情况进行分析，通过仿真分析和Central Composite Design试验分析确定双辊轴间距525.17 mm,轴线夹角35.25°的最优组合。最后进行实地试验验证离散元模拟翻堆机翻堆作业的可行性并对翻堆机作业性能进行测试，试验结果表明：作业后料堆混合系数为0.714,作业功耗为1.828 kW,表明该翻堆机具有良好的破碎与混合效果。
- 食用菌 /
- 翻堆机 /
- 双辊结构 /
- 离散元 /
- 翻堆装置
Abstract: In order to solve the problems of poor working environment, high labor intensity, low work efficiency and uneven mixing of materials in the manual turning method of edible fungi production base at the present stage, a kind of turning machine with double-roller turning device was proposed. The turning device used a double-helix method to design the distribution of the throwing knives according to the principle of layered cutting, the small-radius throwing knives was used to achieve a large turning depth. By building a discrete element simulation model for double-roller turning piles, the EDEM software was used. The engineering process of the turning device and the particle flow, collision and scattering of particles under different working conditions were analyzed. Through simulation analysis and Central Composite Design test analysis, the optimal combination determined that the double-roller axis spacing was 525.17 mm and the axis angle was 35.25°. Finally, the field test was carried out to verify the feasibility of the discrete element simulation of the turning operation of the turning machine and the test results showed that the mixing coefficient of the pile after operation was 0.714, and the operating power consumption was 1.828 kW, which shows that the compost turner has good crushing and mixing effects.
- edible fungi /
- turning machine /
- double-roller structure /
- discrete element /
- turning device

HTML全文

参考文献(23)

[1]	顾可飞,周昌艳,李晓贝.食用菌的营养价值及药用价值[J].食品工业,2017,38(10):228-231. Gu Kefei,Zhou Changyan,Li Xiaobei.Nutritive and medicinal value edible fungi [J].Food Industry,2017,38(10):228-231.
[2]	Sandea D,De Oliveiraa G P,E Moura M A F,et al.Edible mushrooms as a ubiquitous source of essential fatty acids [J].Food Research International,2019,125:1-16
[3]	Muszyńskaa B,Grzywacz-Kisielewskaa A,Kałaa K,et al.Anti-inflammatory properties of edible mushrooms:A review [J].Food Chemistry,2018,243:373-381.
[4]	张金霞,陈强,黄晨阳,等.食用菌产业发展历史、现状与趋势[J].菌物学报,2015,34(4):524-540. Zhang Jinxia,Chen Qiang,Huang Chenyang,et al.History,current situation and trend of edible mushroom industry development [J].Acta Mycology,2015,34(4):524-540.
[5]	中国食用菌协会.2018年度全国食用菌统计调查结果分析[EB/OL]. http://hz.cefa.com.cn/UploadFiles/news/2020/3/ 202003191756353016.pdf,2020-04-16.
[6]	雷孔,张良,胡文洪,等.中国食用菌产业现状及预测[J].食用菌学报,2016,23(2):104-109. Kong Lei,Zhang Liang,Hu Wenhong,et al.The Chinese edible fungi industry-current status and future predictions [J].Journal of Edible Fungi,2016,23(2):104-109.
[7]	Chiumenti A,Da Borso F,Rodar T,et al.Swine manure composting by means of experimental turning equipment [J].Waste Management,2007,27(12):1774-1782.
[8]	徐鹏翔,王大鹏,田学志,等.国内外堆肥翻抛机发展概况与应用[J].环境工程,2013,31(S1):547-549. Xu Pengxiang,Wang Dapeng,Tian Xuezhi,et al.General development situation and application of domestic and overseas compost turners [J].Environmental Engineering,2013,31(S1):547-549.
[9]	秦现增,马戎,张华,等.新远东-圣甲虫设备[J].农机科技推广,2005(1):41.
[10]	Robert R.Innovations in windrow turners [J].Biocycle,2003,44(7):50-54.
[11]	Schedler M,Ortner-Pichlera,Reitbauer E,et al.Interdisciplinary system simulation of a tracked compost turner [J].Procedia Manufacturing,2020,51:1005-1013
[12]	刘永超,钟波,李维华,等.有机肥翻抛机研究现状与发展趋势分析[J].农业机械,2010(26):2-4.
[13]	田晋跃.自行式垃圾翻堆机作业特性分析[J].农业机械学报,2002,33(3):24-26,29. Tian Jinyue.Analysis of working performance on self-moving composting aerators [J].Transactions of the Chinese Society for Agricultural Machinery,2002,33(3):24-26,29.
[14]	彭宝良,胡志超,王海鸥,等.FP2500A型有机肥翻抛机的研制[J].农业工程学报,2008,24(11):126-129. Peng Baoliang,Hu Zhichao,Wang Hai'ou,et al.Development of FP2500A type stack-turning machine for organic fertilizer [J].Transactions of the Chinese Society of Agricultural Engineering,2008,24(11):126-129.
[15]	张钟鸣.大耕深双轴旋耕施肥播种机设计及应用推广[D].扬州:扬州大学,2016.Zhang Zhongming.Design and application promotion of dual-axis rotary tillage and fertilizing planter with large tillage depth [D].Yangzhou:Yangzhou University,2016.
[16]	张银平,杜瑞成,刁培松,等.正反转组合式水稻宽苗带灭茬播种机设计与试验[J].农业工程学报,2017,33(3):7-13. Zhang Yinping,Du Ruicheng,Diao Peisong,et al.Design and experiment of wide band seeding rice seeder with reversed stubble cleaning and anti-blocking [J].Transactions of the Chinese Society of Agricultural Engineering,2017,33(3):7-13.
[17]	鄂智,王霜,陈思旭,等.IT245旋耕刀正反转功耗有限元数值分析[J].机械,2018,45(9):70-76. E Zhi,Wang Shuang,Chen Sixu,et al.Finite element numerical analysis of positive and negative power dissipation of IT245 rotary tiller [J].Machinery,2018,45(9):70-76.
[18]	陈青春,石勇,丁启朔,等.正反转旋耕作业的秸秆混埋效果比较[J].农业工程学报,2015,31(9):13-18. Chen Qingchun,Shi Yong,Ding Qishuo,et al.Comparison of straw incorporation effect with down-cut and up-cut rotary tillage [J].Transactions of the Chinese Society of Agricultural Engineering,2015,31(9):13-18.
[19]	Milkevych V,Munkholm L J,Chen Y,et al.Modelling approach for soil displacement in tillage using discrete element method [J].Soil and Tillage Research,2018,183:60-71.
[20]	王金龙.基于离散元法的稻秆深埋还田刀辊总成优化设计与试验[D].哈尔滨:东北农业大学,2019.
[21]	中国农业机械化科学研究院.农业机械设计手册[M].北京:中国农业科学技术出版社,2007
[22]	Manu M K,Kumar R,Garg A.Decentralized composting of household wet biodegradable waste in plastic drums:Effect of waste turning,microbial inoculum and bulking agent on product quality [J].Journal of Cleaner Production,2019,226:233-241.
[23]	Chiumenti A,Da Borso F,Rodar T,et al.Swine manure composting by means of experimental turning equipment [J].Waste Management,2007,27(12):1774-1782.
