Experiment study on convective and radiation drying of Dahongpao Zanthoxylum bungeanum Maxim under different temperature and humidity
-
摘要: 为对比大红袍花椒热风干燥、热风—红外与热风—微波联合干燥的特性和品质，揭示对流辐射联合干燥大红袍花椒的干燥过程，指导大红袍花椒生产实践。通过薄层干燥试验，研究三种干燥方式在不同温度（50℃、60℃、70℃）和相对湿度（10%、30%、50%）条件下的干燥曲线和有效水分扩散系数，结合Weibull函数的尺度参数α、形状参数β及估算有效水分扩散系数进行干燥动力学分析，采用扫描电子显微镜（SEM）观察干制花椒油苞结构，提取挥发油进行气相色谱质谱（GC-MS）分析。结果表明：热风干燥时间最长，升温降湿有利于提高热风干燥速率、缩短干燥时间，但对热风—红外和热风—微波干燥影响较小；Weibull函数能很好地模拟三种干燥方式，α随干燥条件变化明显，β>1,水分迁移是由物料表面和内部共同控制，估算水分扩散系数变化范围分别为1.303×10-7～2.815×10-7 m2/min、7.646×10-7～9.628×10-7 m2/min、2.200×10-6～2.778×10-6 m2/min,且与温湿度变化相关；热风干燥和热风—红外干燥能较好地保留花椒油苞，热风—微波干燥花椒油苞更为饱满；热风—微波干燥后花椒挥发油提取量最高（7.5%）,烯烃类物质相对含量最大，热风干燥花椒提取挥发油含量最低，但挥发油中化合物种类最多。热风—红外联合干燥在缩短干燥时间和保持品质方面是较好的选择。Abstract: In order to compare the drying characteristics and quality of Dahongpao Zanthoxylum bungeanum Maxim（ZBM） under hot air drying, hot air-infrared drying and hot air-microwave drying methods, and reveal the thin layer drying process of convection-radiation combined drying to guide the production practice, the effects of hot air drying, hot air-infrared drying and hot air-microwave drying under the condition of different hot air temperatures（50 ℃, 60 ℃, 70 ℃） and different air relative humidity（10%, 30%, 50%） were analyzed by contrast with drying curve and effective moisture diffusivity. The drying kinetics was analyzed by combining the scale parameter（α）, shape parameters（β） of Weibull function and the calculated moisture diffusion coefficient, the oil bud structure and volatile oil components of dried ZBM were analyzed by scanning electron microscope（SEM） and gas chromatography mass spectrometry（GC-MS） respectively. The results show that the drying time of hot air drying was longest. Increasing the temperature or decreasing the humidity was helpful to improve the drying rate and shorten the drying time, but it had little effect on hot air-infrared and hot air-microwave drying. Weibull function could well simulate the drying curves of three drying methods. The scale parameter（α） was related to the drying time and changed obviously with drying conditions. The shape parameter β＞1, it showed that water migration was jointly controlled by the surface and interior of the material. The calculated moisture diffusion coefficient variation ranges of the three drying methods were 1.303×10-7-2.815×10-7 m~2/min、7.646×10-7-9.628×10-7 m~2/min、2.200×10-6-2.778×10-6 m~2/min respectively, and were related to the change of hot air temperature and humidity. Through SEM observation on the dried peel of ZBM, it was found that the structure of oil bud dried by hot air and hot air-infrared were well preserved, while oil bud was more full after hot air-microwave drying; and the content of volatile oil extracted from ZBM after hot air-microwave drying was the most（7.5%） by using GC-MS analysis, the relative content of olefins was the largest. The volatile oil extracted from ZBM by hot air drying was the lowest, but the volatile oil had the most kinds of compounds. Considering the quality and drying characteristics of dried Dahongpao ZBM, the hot air-infrared combined drying method was the better method.
-
-
[1] 刘安成,尉倩,崔新爱,等.花椒采收现状及研究进展[J].中国农机化学报,2019,40(3):84-87. Liu Ancheng,Wei Qian,Cui Xin'ai,et al.Current situation and research progress on fruit picking of Zanthoxylum bungeanum Maxim [J].Journal of Chinese Agricultural Mechanization,2019,40(3):84-87.
[2] Tian J,Ma Y,Tian L,et al.Comparative physiology and transcriptome response patterns in cold-tolerant and cold-sensitive varieties of Zanthoxylum bungeanum Maxim [J].Industrial Crops and Products,2021,167(17):113562.
[3] 李玄.花椒果皮黄酮多酚类物质提取及抗氧化抑菌活性研究[D].咸阳:西北农林科技大学,2018. [4] 李雪磊.热性中药附子、干姜、花椒保肝作用的研究[D].哈尔滨:黑龙江中医药大学,2016. [5] 王娟,杜静怡,贾雪颖,等.花椒精油及其水提物的香气活性成分分析[J].食品工业科技,2021(20):229-241. Wang Juan,Du Jingyi,Jia Xueying,et al.Characterization of the aroma-active compounds in essential oil and water extract of Zanthoxylum bungeanum [J].Science and Technology of Food Industry,2021(20):229-241.
[6] 韩胜男,李妍,张晓杭,等.花椒挥发油的提取工艺优化及抗肿瘤活性分析[J].食品科学,2014,35(18):13-16. Han Shengnan,Li Yan,Zhang Xiaohang,et al.Extraction and antitumor activity of essential oil from Zanthoxylum bungeanum seeds [J].Food Science,2014,35 (18):13-16.
[7] 范韩杰,陈一阳,刘峰.“互联网+”背景下韩城花椒的数字营销策略研究[J].山西农经,2022(7):125-127. [8] 周秀梅.花椒间歇式热风干燥试验研究[D].重庆:西南大学,2008. [9] 景娜娜.干燥和贮藏方式对花椒品质的影响[D].咸阳:西北农林科技大学,2021. [10] Sriwichai T,Sookwong P,Siddiqui M W,et al.Aromatic profiling of Zanthoxylum myriacanthum (makwhaen) essential oils from dried fruits using different initial drying techniques [J].Industrial Crops and Products,2019,133:284-291.
[11] 王教领,宋卫东,任彩红,等.我国香菇干燥技术研究进展[J].中国农机化学报,2021,42(7):76-83. Wang Jiaoling,Song Weidong,Ren Caihong,et al.Research on the drying progress of lentinus edodes in China [J].Journal of Chinese Agricultural Mechanization,2021,42(7):76-83.
[12] 陈凯.枸杞红外干燥工艺研究[D].天津:天津科技大学,2016. Chen Kai.Study on infrared drying of Lycium Barbarum L [D].Tianjin:Tianjin University of Science & Technology,2016.
[13] Murugesan K,Thomas H R,Cleall P J.An investigation of the influence of two-stage drying conditions on convective drying of porous materials [J].International Journal of Numerical Methods for Heat & Fluid Flow,2002,12(1):29-46.
[14] 李星仪,张悦,谢永康,等.热风干燥过程相对湿度对香菇品质的影响[J].农业工程学报,2020,36(24):281-291. Li Xingyi,Zhang Yue,Xie Yongkang,et al.Effects of relative humidity on the exterior quality of shiitake mushrooms (Lentinus edodes) during hot air drying [J].Transactions of the Chinese Society of Agricultural Engineering,2020,36(24):281-291.
[15] Yu X L,Zielinska M,Ju H Y,et al.Multistage relative humidity control strategy enhances energy and exergy efficiency of convective drying of carrot cubes [J].International Journal of Heat and Mass Transfer,2020,149:119231.
[16] Ramírez C,Astorga V,Nuňez H,et al.Anomalous diffusion based on fractional calculus approach applied to drying analysis of apple slices:The effects of relative humidity and temperature [J].Journal of Food Process Engineering,2017,40(5):e12549.
[17] Sasongko S B,Hadiyanto H,Djaeni M,et al.Effects of drying temperature and relative humidity on the quality of dried onion slice [J].Heliyon,2020,6(7).
[18] Xu W,Islam M N,Cao X,et al.Effect of relative humidity on drying characteristics of microwave assisted hot air drying and qualities of dried finger citron slices [J].LWT-Food Science & Technology,2021,137:110413.
[19] 吴敏,段豪,王振文,等.基于温湿度控制的红外热风联合干燥机设计与试验[J].农业机械学报,2020,51(S1):483-492. Wu Min,Duan Hao,Wang Zhenwen,et al.Design and experiment of infrared-hot air combined dryer based on temperature and humidity control [J].Transactions of the Chinese Society for Agricultural Machinery,2020,51(S1):483-492.
[20] 姜春慧,张倩,杨娜,等.桔梗切片远红外干燥特性及动力学研究[J].中国农机化学报,2021,42(2):92-100. Jiang Chunhui,Zhang Qian,Yang Na,et al.Study on far infrared drying characteristics and kinetics of Platycodon grandiflorum slices [J].Journal of Chinese Agricultural Mechanization,2021,42(2):92-100.
[21] 尹慧敏,聂宇燕,沈瑾,等.基于Weibull分布函数的马铃薯丁薄层热风干燥特性[J].农业工程学报,2016,32(17):252-258. Yin Huimin,Nie Yuyan,Shen Jin,et al.Drying characteristics of diced potato with thin-layer by hot-wind based on Weibull distribution function [J].Transactions of the Chinese Society of Agricultural Engineering,2016,32(17):252-258.
[22] Akar G,Barutçu Mazı I.Color change,ascorbic acid degradation kinetics,and rehydration behavior of kiwifruit as affected by different drying methods [J].Journal of Food Process Engineering,2019,42(3):e13011.
[23] 吴业豪.花椒多孔堆积填充床对流干燥传热传质特性[D].西安:西安科技大学,2021. Wu Yehao.Heat and mass transfer characteristics of convective drying in porous packed bed about Zanthoxylum bungeanum Maxim [D].Xi'an:Xi'an University of Science and Technology,2021.
[24] 张雪峰.黄芪热风干燥机理及能效评价分析[D].重庆:西南大学,2020. [25] 白竣文,王吉亮,肖红伟,等.基于Weibull分布函数的葡萄干燥过程模拟及应用[J].农业工程学报,2013,29(16):278-285. Bai Junwen,Wang Jiliang,Xiao Hongwei,et al.Weibull distribution for modeling drying of grapes and its application [J].Transactions of the Chinese Society of Agricultural Engineering,2013,29(16):278-285.
[26] Onwude D I,Hashim N,Janius R B,et al.Modeling the thin-layer drying of fruits and vegetables:A review [J].Comprehensive Reviews in Food Science and Food Safety,2016,15(3):599-618.
[27] 郑严.花椒微波干燥与热风干燥的对比试验研究[D].重庆:西南大学,2006. Zheng Yan.Comparative experimental study on microwave drying and hot air drying of pepper [D].Chongqing:Southwest University,2006.
[28] 巨浩羽.基于温湿度控制的热风干燥装置设计与试验[D].北京:中国农业大学,2016. Ju Haoyu.Hot air drying technology based on being controlled temperature and humidity and experiment study [D].Beijing:China Agriculture University,2016.
[29] Corzo O,Bracho N,Alvarez C.Weibull model for thin-layer drying of mango slices at different maturity stages [J].Journal of Food Processing and Preservation,2010,34(6):993-1008.
[30] Farahmandfar R,Tirgarian B,Dehghan B,et al.Changes in chemical composition and biological activity of essential oil from Thomson navel orange (Citrus sinensis L.Osbeck) peel under freezing,convective,vacuum,and microwave drying methods [J].Food Science & Nutrition,2020,8(1):124-138.
[31] Rahimmalek M,Goli S A H.Evaluation of six drying treatments with respect to essential oil yield,composition and color characteristics of Thymys daenensis subsp.daenensis.Celak leaves [J].Industrial Crops and Products,2013,42:613-619.
[32] Samadi L,Larijani K,Naghdi Badi H,et al.Qualitative and quantitative variations of the essential oils of Dracocephalum kotschyi Boiss.as affected by different drying methods [J].Journal of Food Processing and Preservation,2018,42(11):e13816.
-
