Preparation and Identification of Zearalenone Complete Antigen
-
摘要: 为了降低基层检测部门检测谷物中玉米赤霉烯酮（ZEN）的成本,研制国产化检测试剂盒非常必要,而试剂盒的研制离不开完全抗原的支持。本试验的主要内容是将ZEN肟化,生成玉米赤霉烯酮肟（ZENO）,再用DCC-NHS活性酯法将ZENO与牛血清白蛋白（BSA）、鸡卵白蛋白（OVA）偶联合成ZEN完全抗原,最后透析将未偶联的小分子ZEN除去,得到的即为完全抗原。包被原ZEN-BSA浓度为1.62 mg·mL-1,免疫原ZEN-OVA浓度为1.33mg·mL-1。采用UV法、SDS-PAGE法对完全抗原进行鉴定,同时建立间接ELISA方法验证包被原ZEN-BSA。结果表明:采用活性酯法合成的ZEN完全抗原在319nm处出现新的吸收峰,且SDS-PAGE图表明ZEN-BSA分子量集中在60～70kDa,ZEN-OVA分子量集中在40～50kDa,不同于BSA和OVA分子量,但相差不大。根据紫外扫描图计算得到ZEN-BSA结合比为7.0∶1,ZEN-OVA结合比为6.1∶1。根据免疫学方法可知,OD450nm值随着毒素浓度的增加而减小。本试验利用3种方法对ZEN完全抗原进行鉴定,证明ZEN完全抗原偶联成功。Abstract: In order to reduce the cost of detecting zearalenone（ZEN）in grains by the basic-level testing department,it is necessary to develop a domestically produced testing kit,and the development of the kit need the support of complete antigen.The main content of this experiment is to oximize ZEN to produce zearalenone oxime（ZENO）,and then combine ZENO with bovine serum albumin（BSA）and chicken ovalbumin（OVA）by the DCC-NHS active ester method.ZEN complete antigen.Finally,dialysis removes the unconjugated small molecule ZEN,and the result is complete antigen.The original coating ZEN-BSA concentration was1.62 mg·mL-1,and the immunogen ZEN-OVA concentration was 1.33 mg·mL-1.The UV method and SDSPAGE method were used to identify the complete antigen.At the same time,an indirect ELISA method was established to verify the original coating ZEN-BSA.The results showed that the ZEN complete antigen synthesized by the active ester method had a new absorption peak at 319 nm,and the SDS-PAGE chart showed that the molecular weight of ZEN-BSA was concentrated at 60-70 kDa,and the molecular weight of ZEN-OVA was concentrated at 40-50 kDa.Different from the molecular weight of BSA and OVA but not much different.The ZEN-BSA binding ratio was 7.0∶1 and the ZEN-OVA binding ratio was 6.1∶1 calculated according to the UV scan.According to the immunological method chart,the OD450 nmvalue decreased with the increase of the toxin concentration.This test uses three methods to identify the ZEN complete antigen,which proves that the ZEN complete antigen coupling is successful.
-
Keywords:
- zearalenone /
- antigen synthesis /
- enzyme-linked immunosorbent assay /
- toxin detection
-
-
[1] 甄玉萍.玉米赤霉烯酮的提取纯化及其产生菌的产毒性研究[D].齐齐哈尔:齐齐哈尔大学,2016. [2] ABDELLAH Z,MIGUEL S J,CARLOS M J,et al.Review on the toxicity,occurrence,metabolism,detoxification,regulations and intake of zearalenone:an oestrogenic mycotoxin[J].Food and Chemical Toxicology,2007,45(1):1-18.
[3] 中华人民共和国国家卫生和计划生育委员会,国家食品药品监督管理总局.食品中真菌毒素限量:GB 2761-2017[S].北京:中国标准出版社,2017. [4] KLARI'CM S,CVETNI'CZ,PEPELJNJAK S,et al.Co-occurrence of aflflatoxins,ochratoxin A,fumonisins,and zearalenone in cereals and feed,determined by competitive direct enzyme-linked immunosorbent assay and thin-layer chromatography[J].Archives of Industrial Hygione&Toxicdogy,2009,60(4):427-434.
[5] OK H E,CHOI S,KIM M,et al.HPLC and UPLC methods for the determination of zearalenone in noodles,cereal snacks and infant formula[J].Food Chemistry,2014,163:252-257.
[6] CHEN D,CAO X,TAO Y,et al.Development of a liquid chromatography-tandem mass spectrometry with ultrasound-assisted extraction and auto solid-phase clean-up method for the determination of Fusariumtoxins in animal derived foods[J].Journal of Chromatography A,2013,1311:21-29.
[7] KONG D,LIU L,SONG S,et al.A gold nanoparticle-based semi-quantitative and quantitative ultrasensitive paper sensor for the detection of twenty mycotoxins[J].Nanoscale,2016,8:5245-5253.
[8] KONG D,XIE Z,LIU L,et al.Development of indirect competitive ELISA and lateral-flflow immunochromatographic assay strip for the detection of sterigmatocystin in cereal products[J].Food and Agricultural Immunology,2017,28(2):260-273.
[9] LI A,TANG L,SONG D,et al.A SERS-active sensor based on heterogeneous gold nanostar core-silver nanoparticle satellite assemblies for ultrasensitive detection of aflflatoxinB1[J].Nanoscale,2016,8:1873-1878.
[10] PENG D,FENG L,PAN Y,et al.Development and validation of an indirect competitive enzyme-linked immunosorbent assay for monitoring organoarsenic compounds in edible chicken,pork and feed[J].Food Chemistry,2016,197:821-828.
[11] 中华人民共和国国家质量监督检验检疫总局,中国国家标准化管理委员会.饲料中玉米赤霉烯酮的测定:GB/T19540-2004[S].北京:中国标准出版社,2004. [12] GEFEN T,VAYA J,KHATIB S,et al.The effect of haptens on protein—carrier immunogenicity[J].Immunology,2015,144(1):116-126.
[13] 王元凯.玉米赤霉烯酮单克隆抗体的制备及高通量定性、定量检测技术的研究[D].上海:上海交通大学,2014. [14] GENDLOFF E H,CASALE W L,RAM B P,et al.Hapten-proteincon jugates prepared by the mixed anhydride method[J].Journal of Immunological Methods,1986,92:15-20.
[15] 曹红翠.紫外分光光度法测定蛋白质的含量[J].广东化工,2007(8):93-94. [16] 曹欢,祭芳,王秀宇,等.玉米赤霉烯酮半抗原及全抗原的合成与鉴定[J].细胞与分子免疫学杂志,2011,27(9):975-978. [17] 李俊锁.兽药残留分析研究进展[J].中国农业科学,1997,30(5):81-87. [18] 陈新建,陈梅英,赵会杰.免疫学技术在植物科学中的应用[M].北京:中国农业大学出版社,1998. [19] 孙亚宁.玉米赤霉烯酮免疫学快速检测技术研究[D].兰州:甘肃农业大学,2017. [20] 陈晓飞.抗玉米赤霉烯酮和黄曲霉毒素B1抗体的制备和评价[D].长春:吉林大学,2014. [21] 唐宁.玉米赤霉烯酮单抗的制备及初步应用[M].扬州:扬州大学,2009. [22] TANG X,LI X,LI P,et al.Development and application of an immunoaffinity column enzyme immunoassay for mycotoxin zearalenone in complicated samples[J].Plos One,2014,9(1):85606.
[23] THONGRUSSAMEE T,KUZMINA N S,SHIM W B,et al.Monoclonal-based enzyme-linked immunosorbent assay for the detection of zearalenone in cereals[J].Food Additives&Contaminants Part A:Chemistry,Analysis,Control,Exposure&Risk Assessment,2008,25(8):997-1006.
[24] 王景琳,张志东,尹世兴,等.玉米赤霉烯酮免疫检测技术研究-兔抗玉米赤霉烯酮抗体研制[J].中国兽医科技,1991,21(l):13-l4. [25] 胥传来,彭池方,郝凯,等.动物源食品中磺胺二甲嘧啶人工抗原的合成研究[J].食品科学,2005(7):118-121. [26] 刘琦,生威,李志,等.基于单克隆抗体的玉米赤霉烯酮检测方法研究[J].食品研究与开发,2017,38(21):111-115. [27] 杨振东,宁炜,徐丹,等.玉米赤霉烯酮人工抗原的合成以及抗体的制备[J].分析科学学报,2011,27(2):158-161. [28] HERMANSON G T.Bioconjugate techniques[M].2nd ed.Rockford,Illinois(USA):Elsevier,2008.
[29] 吕俊美.玉米赤霉烯酮及其衍生物单克隆抗体的制备及免疫试纸检测方法的建立[D].新乡:河南科技学院,2020. [30] 赵红艳.玉米赤霉烯酮胶体金免疫层析试纸条的研制[D].南京:南京农业大学,2015. -
