Design and Analysis of Three Ridges and Six Rows Peanut Harvest Clamping and Gathering Device
-
摘要: 基于六行三通道夹持归集过程中速度、夹持力等关键参数研究，解析了夹持力与速度比范围。通过对夹持过程中花生植株进行动力学和运动学分析，结合花生荚果-果柄-植株间连接点的物理特性分析，确定花生在夹持输送过程中的受力情况，分析计算得出机具前进速度与夹持输送速度比为1:1.2;由归集处花生植株的受力情况，分析得出花生夹持输送速度与归集速度比范围为1:(1.1～1.2),此时花生植株在不出现夹断的情况下能够顺利归集且不拥堵。通过运动仿真最终确定速度比为1:1.17左右时花生植株不会再出现情况，为提高花生收获效率，最终确定在夹持输送速度与归集速度比为1:1.2,此时花生收获机械的效率最高且不会出现花生植株夹断情况。Abstract: Based on the study of key parameters such as speed and clamping force in the process of six-line and three-channel clamping aggregation, the range of clamping force to speed ratio is analyzed. Through the dynamics and kinematics analysis of peanut plants in the process of clamping, combined with the physical characteristics analysis of peanut pod-stem-plant connection point, the force of peanut in the process of clamping and conveying was determined, and the forward speed of the machine and the clamping and conveying speed ratio was 1:1.2.According to the force of peanut plants at the gathering place, the ratio of peanut clamping and conveying speed to the gathering speed was1:1.1～1.2.At this time, the peanut plants could be successfully gathered without clamping and congestion. Through the motion simulation, it is determined that when the speed ratio is about 1 : 1.17, peanut plants will not appear again. In order to improve the efficiency of peanut harvesting, it is finally determined that when the ratio of clamping and conveying speed and collection speed is 1 : 1.2, the efficiency of peanut harvesting machinery is the highest and peanut plants will not be clipped.
-
Keywords:
- peanuts /
- three ridges and six rows /
- combine harvester /
- harvest
-
-
[1] 尚书旗,李国莹,杨然兵,等.4HQL-2型全喂入花生联合收获机的研制[J].农业工程学报,2009,25(6):125-130. [2] 陈智锴,吴惠昌,张延化,等.半喂入四行花生联合收获机自动限深系统研制[J].农业工程学报,2018,34(15):10-18. [3] 崔军,钟志堂,王成文,等.六行履带式大蒜联合收获机设计[J].农业开发与装备,2021(1):138-139. [4] 栾贵东,孙庆卫,王延耀,等.2垄4行花生联合收获机夹持归集装置的设计与试验[J].农机化研究,2014(1):132-135. [5] 胡志超,王海鸥,王建楠,等.4HLB-2型半喂入花生联合收获机试验[J].农业机械学报,2010,41(4):79-84. [6] 栾贵东,孙庆卫,王延耀,等.2垄4行花生联合收获机夹持归集装置的设计与试验[J].农机化研究,2014,36(1):132-135. [7] 吕小荣,吕小莲,王庭钰,等.半喂入式花生摘果机虚拟仿真分析与试验研究[J].西北农林科技大学学报(自然科学版),2017,45(1):190-196. [8] 南飞飞,卢泽民,李彦明,等.半喂入式花生联合收获机关键工作参数试验与优化[J].农机化研究,2018,40(2):170-173,178. [9] 尚书旗.4HQL-2型挖拔组合式全喂入花生联合收获机的研制[D].青岛:青岛农业大学,2008. [10] 田连祥.花生有序条铺收获机理研究[D].青岛:青岛农业大学,2017. [11] 王东伟,尚书旗,韩坤.4HJL-2型花生捡拾摘果联合收获机的设计与试验[J].农业工程学报,2013,29(11):27-36,294. [12] 王东伟.花生联合收获机关键装置的研究[D].沈阳:沈阳农业大学,2013. [13] WANG DONGWEI,SHANG SHUQI,HAN KUN.Design and test of 4HJL-2 harvester for peanut picking-up and fruit-picking[J].农业工程学报,2013,29(11) :27-36.
