Design and Experiment of Leek Planting Machine
-
摘要: 根据农艺需求，韭菜进入动态生长期后要进行2～3次培土工作，且随着韭菜假茎不断长高，培土高度也不断增加。为此，针对国内外现有中耕培土机培土易损伤韭菜茎叶、扶苗困难、不适合韭菜多次培土的问题，设计了一种韭菜培土机，经过对扶苗装置、培土刀的理论研究，确定了工作参数，并采用离散元法模拟了韭菜培土过程，分析了培土装置作业参数对土壤颗粒各轴向运动速度和垄上颗粒数量的影响。通过数据处理软件对田间试验结果进行分析，得到了最优组合参数，即刀具转速为370r/min、内挡土板展开角为93°、外挡土板展开角为68°、培土宽度为365mm、培土厚度为94mm、韭菜真叶土壤覆盖量为72g。Abstract: According to the needs of agriculture, leek into the dynamic growth period to carry out 2-3 times of soil cultivation work, leek false stem growing high, soil cultivation height is also increasing, aiming at the existing domestic and foreign soil cultivation machine is easy to damage the stems and leaves of leek, supporting the seedling is difficult, is not suitable for the leek multiple soil cultivation problem, designed a leek soil cultivation machine, after the supporting seedling device, the theoretical research of the soil cultivation knife, The working parameters were determined, the discrete element method was used to simulate the soil raising process of leek, and the effects of the operating parameters of the soil raising device on the axial velocity of soil particles and the number of particles on the ridge were analyzed.Data processing software was used to analyze the field test results, and the optimal combination parameters were obtained, that is, the tool speed was 370r/min, the inner retaining plate expansion Angle was 93°, the outer retaining plate expansion Angle was 68°, the soil width was 365mm, the soil thickness was 94mm, and the soil cover amount of leek true leaf was 72g.
-
Keywords:
- leek /
- soil cultivator /
- seedling support /
- discrete element
-
-
[1] 张研.北京地区安全营养韭菜品质调控与生产对策研究[D].邯郸:河北工程大学,2020. [2] 王娟娟,张曦,蒋靖怡.关于豇豆、芹菜和韭菜质量安全的思考[J].中国蔬菜,2022(6):7-10. [3] 刘轩.韭农安全生产行为影响因素研究[D].保定:河北农业大学,2020. [4] 罗静红,罗芳耀,干雪梅,等.韭黄、韭薹采后处理技术[J].四川农业科技,2022(6):54-56. [5] 高志华.韭黄高产栽培技术[J].园艺与种苗,2021,41(6):43-44. [6] 郭文场,周淑荣,董昕瑜,等.韭黄的栽培管理(1)[J].特种经济动植物,2018,21(6):42-44. [7] 陈海涛,顿国强.基于虚拟样机动力学仿真的大豆扶禾器参数优化[J].农业工程学报,2012,28(18):23-29. [8] 高建民,区颖刚.甘蔗螺旋扶起机构的理论研究及虚拟样机仿真[J].农业工程学报,2004(3):1-5. [9] 贺俊林,胡伟,郭玉富,等.扶禾杆在不对行导入玉米茎秆中的运动仿真[J].农业工程学报,2007(6):125-129. [10] 张永良.基于离散元的逆转旋耕施肥播种机抛土性能仿真及试验研究[D].镇江:江苏大学,2012. [11] 杨庆璐,王学诗,范国强,等小型手扶自走式棉田培土机的设计与试验[J].农机化研究,2019,41(7):69-74. [12] JIANMIN GAO,HUIDONG QI.Soil throwing experiments for reverse rotary tillage at various depths,travel speeds,and rotational Speeds[J].Transactions of the ASABE,2017,60(4):1113-1121.
[13] 徐胜.落石冲击力计算方法研究[D].重庆:重庆交通大学,2016. [14] 潘佛雏.密植作物用植保机械分禾装置的研究[D].石河子:石河子大学,2018. [15] 国家标准局.旋耕机械刀和刀座:GB/T 5669-2017[S].北京:中国标准出版社,2017. [16] 丁为民,王耀华,彭嵩植.正、反转旋耕刀性能分析及切土扭矩比较试验[J].南京农业大学学报,2001,24(1):5. [17] 王恩民.基于SPH法的林地深松刀具阻力特性研究[D].长沙:中南林业科技大学,2019. [18] 周飞科.深松机具设计与试验研究[D].长沙:中南林业科技大学,2018. [19] 仝振伟.烟草中耕培土机复合切削部件设计与试验[D].郑州:河南农业大学,2020. [20] 国家标准局.农业机械试验条件测定方法的一般规定:GB/T 5262-1985[S].北京:中国标准出版社,1985.
