自走式果园喷雾机设计与试验

梁俊鹏; 王贤斐; 李景彬; 李亚丽; 丁龙朋; 温宝琴; 张志元; 丁惠哲

doi:10.13427/j.cnki.njyi.20240018.010

自走式果园喷雾机设计与试验

1. 石河子大学机械电气工程学院;
2. 现代农业机械兵团重点实验室

基金项目:

兵团财政科技计划项目(2021BB003)

石河子大学创新发展专项(KX01210205)

详细信息

作者简介:
梁俊鹏(1996-),男,新疆温泉人,硕士研究生,(E-mail)1483140983@qq.com

通讯作者:
温宝琴(1980-),女,宁夏吴忠人,教授,硕士生导师,(E-mail)wendy-wbq@163.com

中图分类号: S491
计量
- 文章访问数: 0
- HTML全文浏览量: 2
- PDF下载量: 0
出版历程
- 收稿日期: 2022-08-18
- 刊出日期: 2024-07-31

Design and Experiment of Self-propelled Orchard Sprayer

1. College of Mechanical and Electrical Engineering, Shihezi University;
2. Xinjiang Production and Construction Crops Key Laboratory of Modern Agricultural Machinery

摘要

摘要: 针对新疆果园喷雾施药作业劳动强度大、雾滴穿透性差、机具适用范围小等问题，结合果园农机农艺及病虫害防治要求，设计了一款自走式果园喷雾机，主要由履带式行走系统、喷雾系统和远程控制系统等组成。通过计算分析确定各部分主要结构参数，并通过有限元模拟分析机架结构合理性。为验证喷雾机作业性能，以喷头流量为试验因素，以喷雾附着率与喷雾穿透性为试验指标，针对整机喷杆喷雾装置与风送喷雾装置开展田间试验。结果表明：在相同工作条件下，喷杆式喷雾装置平均喷雾附着率高于风送式喷雾装置，两种喷雾装置平均喷雾附着率分别为71.99%与66.35%,均能满足喷雾附着要求。在穿透性试验中，风送式喷雾装置内外冠层药液沉积变异系数平均比喷杆式喷雾装置小14%,风送式喷雾装置穿透性明显强于喷杆式喷雾装置。喷雾机两种喷雾装置在附着率与穿透性上都有较好的作业效果，可根据果树不同生长时期以及不同农艺需求选择适合的喷雾方式，来达到更好的喷雾效果。
- 果园 /
- 喷雾机 /
- 自走式 /
- 风送式 /
- 喷杆式
Abstract: A self-propelled orchard spray was designed to solve the problems of high labor intensity, poor penetration of fog droplets and serious pesticide pollution in orchard spray in Xinjiang, combined with the requirements of orchard agricultural machinery, agronomy and pest control. The whole machine is mainly composed of crawler walking system, spray system and remote control system. The main structural parameters of each part are determined by calculation and analysis, and the rationality of the frame structure is analyzed by finite element simulation. In order to verify the operating performance of the spray, field tests were carried out on the whole machine spray bar spray device and air-driven spray device with the nozzle flow as the test factor and the spray adhesion rate and spray penetration as the test indicators. The test results show that under the same working conditions, the average spray adhesion rate of the spray bar spray device is higher than that of the air driven spray device. The average spray adhesion rates of the two spray devices are 71.99% and 66.35% respectively, which can meet the spray adhesion requirements. In the penetration test, the variation coefficient of the inner and outer canopy liquid deposition of the wind fed spray device is on average 14% smaller than that of the spray rod spray device, and the penetration of the wind fed spray device is significantly stronger than that of the spray rod spray device. The two kinds of spray devices of spray have good operating effects in terms of adhesion and penetration. At the same time, suitable spray methods can be selected according to different growth periods of fruit trees and different agronomic needs to achieve better spray effects.
- orchard /
- sprayer /
- self propelled /
- air supply type /
- spray bar type

HTML全文

参考文献(29)

[1]	董晶.果树病虫害防治现状与对策[J].农业开发与装备,2019(3):75.
[2]	韩景红.我国植保机械和施药技术的现状问题及对策[J].农业与技术,2018,38(12):91.
[3]	SE-WOON HONG,LINGYING ZHAO,HEPING ZHU.CFD simulation of airflow inside tree canopies discharged fromair-assisted sprayers[J].Computers and electronics in agriculture,2018,149:121-132.
[4]	边永亮,杜亚光,李建平,等.风机及导流装置在果园植保中的应用与前景分析[J].现代农业装备,2020,41(6):17-24.
[5]	何雄奎.改变我国植保机械和施药技术严重落后的现状[J].农业工程学报,2004(1):13-15.
[6]	张海锋,许林云.果园喷雾机发展现状及展望[J].中国农机化学报,2014,35(3):112-118.
[7]	宋坚利,何雄奎,张京,等.“Π”型循环喷雾机设计[J].农业机械学报,2012,43(4):31-36.
[8]	姜红花,白鹏,刘理民,等.履带自走式果园自动对靶风送喷雾机研究[J].农业机械学报,2016,47(S1):189-195.
[9]	霍鹏,李建平,杨欣,等.果园仿形喷杆施药装置设计与动力学仿真[J].农机化研究,2022,44(1):31-37.
[10]	董祥,张铁,燕明德,等.3WPZ-4型风送式葡萄喷雾机设计与试验[J].农业机械学报,2018,49(S1):205-213.
[11]	刘冬梅,杨杭旭,周宏平,等.密植矮化茶园地面低容量仿形喷雾液滴沉积性能研究[J].农业机械学报,2019,50(10):96-105.
[12]	宋树杰,瞿济伟,李翊宁,等.农用车底盘偏置转向轴驱动轮运动与动力特性试验[J].农业工程学报,2015,31(23):28-34.
[13]	徐高伟,宋裕民,邱绪云,等.果园电动自走式履带底盘动力系统匹配设计与试验[J].农机化研究,2022,44(4):251-255.
[14]	王韦韦,谢进杰,陈黎卿,等.3YZ-80A型履带自走式玉米行间喷雾机设计与试验[J].农业机械学报,2021,52(9):106-114.
[15]	迟媛,蒋恩臣.履带车辆转向时最大驱动力矩的计算[J].农业工程学报,2009,25(3):74-78.
[16]	李耀明,李有为,徐立章,等.联合收获机割台机架结构参数优化[J].农业工程学报,2014,30(18):30-37.
[17]	吴伟斌,廖劲威,洪添胜,等.山地果园轮式运输机车架结构分析与优化[J].农业工程学报,2016,32(11):39-47.
[18]	祝露,王德成,尤泳,等.履带式林间草带收割机设计与试验[J].农业机械学报,2021,52(4):126-133.
[19]	邱威,孙浩,孙玉慧,等.低矮果园环流式循环风送喷雾机设计与试验[J].农业工程学报,2021,37(6):18-25.
[20]	刘洋,李斌,董云成,等.南疆红枣种植与收获现状调研[J].新疆农机化,2021(3):32-34,44.
[21]	丁素明,薛新宇,张玲,等.自走式果园风送喷雾机的研制[J].中国农机化学报,2016,37(4):54-58,62.
[22]	张晓辛,吕晓兰,丁素明,等.果园风送式喷雾机仿形喷雾试验研究[J].中国农机化,2011(3):68-72.
[23]	戴奋奋.风送喷雾机风量的选择与计算[J].植物保护,2008(6):124-127.
[24]	李龙龙,何雄奎,宋坚利,等.果园仿形变量喷雾与常规风送喷雾性能对比试验[J].农业工程学报,2017,33(16):56-63.
[25]	DONALD DEKEYSER,ASHENAFI T DUGA,PIETER VERBOVEN,et al.Assessment of orchard sprayers using laboratory experiments and computational fluid dynamics modelling[J].Biosystems engineering,2013,114(2):157-169.
[26]	李超,张晓辉,姜建辉,等.葡萄园立管风送式喷雾机的研制与试验[J].农业工程学报,2013,29(04):71-78.
[27]	LAV R KHOT,REZA EHSANI,GENE ALBRIGO,et al.Air-assisted sprayer adapted for precision horticulture:Spray patterns and deposition assessments in small-sized citrus canopies[J].Biosystems engineering,2012,113(1):76-85.
[28]	农业部南京农业机械化研究所.JB/T9782-2014 植保机械通用试验方法[S].北京:中华人民共和国工业和信息化部,2014.
[29]	PALLEJA T,LANDERS A J.Real time canopy density estimation using ultrasonic envelope signals in the orchard and vineyard[J].Computers and electronics in agriculture,2015,115(3):108-117.
