中压配电网络低电压补偿调控技术及实现

杨伟奇; 高晓阳; 朴在林

doi:10.11975/j.issn.1002-6819.2016.z1.028

中压配电网络低电压补偿调控技术及实现

1.
甘肃农业大学工学院，兰州 730070
2.
沈阳农业大学信息与电气工程学院，沈阳 110866

基金项目: 国家科技支撑计划子课题（2006baj04b06-002)

计量
- 文章访问数: 1758
- HTML全文浏览量: 0
- PDF下载量: 829
出版历程
- 收稿日期: 2015-04-21
- 修回日期: 2015-10-20
- 发布日期: 2016-01-30

Implementation of low voltage compensation control in medium voltage distribution network

1.
College of Engineering, Gansu Agricultural University, Lanzhou 730070, China
2.
College of Information and Electric Engineering, Shenyang Agricultural University, Shenyang 110866, China

摘要

摘要: 电压是电能质量考核的一个重要指标。处于系统末端的农村中、低压配电网络在用电高峰期"低电压"现象频繁出现，严重影响了农民正常生产生活用电。该文结合辽宁西丰地区中压配电网络，基于线路调压器调压和无功补偿的基本原理，研究了线路调压器以线路末端远程监测电压为依据和无功补偿以线路首端无功潮流为依据的上位机远程控制的低电压协调控制治理方法。通过远程调控技术实现了在最大潮流下线路的功率因数由补偿前0.97提高到0.99，10 kV线路线损率比协调控制前下降了6%，配电变压器原边电压合格率由原有的22%达到了100%。该文集成应用无线通信技术和自动化综合补偿和调压技术，有效地改善了中、低压配电网络的电压合格率和电能损失率。
- 农村地区 /
- 电 /
- 远程控制 /
- 低电压 /
- 无功补偿 /
- 线路调压 /
- 协调控制
Abstract: Abstract: Voltage is an important assessment criterion of power quality. The low voltage phenomena (LVP) frequently appeared in the power distribution network especially at the rural areas of China, which had been key technical problem to be solved by the local departments of State Grid Corporation of China (SGCC). However, LVP happened mostly at the end of the rural medium voltage distribution system in the peak season, by which the electric power consumption of farming and farmers were seriously affected, and also lay behind the development of agricultural economy.Insufficient primary voltage of the distribution transformer was the main cause of rural low voltage phenomena. Increasing rural substation sites or the conductor section could also improve the power quality, but the investment cycle was too long and the rate of return lower. It is not suitable for large-scale popularization and application in rural areas. The thesis presented a synthesized optimal dynamic compensation method for low voltage in the whole electric power line, which was adopted practically and led in Xifeng medium voltage distribution network of Liaoning. First, based on the line voltage-regulation theory with voltage regulator and the terminal voltage monitored by feeder terminal unit (FTU), the voltage level of the whole electric power line was up to the national criteria with the power on-load tapping voltage regulator controlled by the remote host computer. In the meantime, at the basis of reactive power flow of the head line, and with the constraint condition of voltage in the nodes of reactive power compensators installed, the reactive compensation commands were sent by the remote host computer. The total reactive power capacity was 440 kvar (kilovolt ampere reactive) in each node of compensators，in which 50 kvar was as static compensation and the other as dynamic separated into 4 groups. According to the output of reactive power tide at the transformer substation, 1 static and 4 set of dynamic capacitor banks were composed of 17 different combinations in every compensation node, which was optimized for grouping parallel capacitor switch by the remote host computer based on the principle of reactive balance. Finally the national supervision standards of reactive power dynamic balance were reached after above computerized dynamic adjusting measures taken in the whole experimental power grid. The experimental results showed that the line power factor increased to 0.99 from 0.97 under the maximum power flow after the synthesized compensation implementation, and 10KV line active power loss rate decreased by 6 percent compared with before, and distribution transformer primary qualified voltage rate rose to 100% from original 22%. In the paper, several theories and methods of wireless communication and computer control and line-automation were integrated into the practical application example of comprehensive voltage compensation, which effectively improved the voltage level and fluctuating range, the qualified voltage rate and the power loss rate in the rural low and medium voltage distribution network.It has good reference value of engineering. The proposed methods also come up with new solutions for the intelligent development of reactive power compensation of rural substation.
- rural areas /
- electricity /
- remote control /
- low voltage /
- reactive power compensation /
- line voltage regulation /
- integrated control

HTML全文

参考文献(17)

[1]	王建学，王锡凡，陈皓勇. 基于协同进化法的电力系统无功优化[J]. 中国电机工程学报，2004，24(9)：124－129.Wang Jianxue, Wang Xifan, Chen Haoyong. Reactive power optimization based on corproative co-evolutionary approach[J]. Proceedings of the CSEE, 2004, 24(9): 124－129. (in Chinese with English abstract)
[2]	谭东明，朴在林，郑维刚. 配电线路无功优化就地控制与系统控制效果比较[J]. 农业工程学报，2011，27(4)：235－240.Tan Dongming, Piao Zailin, Zheng Weigang. Comparison of reactive power optimization between local and system on distribution lines[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2011, 27(4): 235－240. (in Chinese with English abstract)
[3]	刘传铨，张焰. 电力系统无功补偿点及其补偿容量的确定[D]. 电网技术，2007(12)：78－81.Liu Chuanquan, Zhang Yan. Confirmation of reactive Power Compensation Node and Its optimal Compensation Capacity[D]. Power system Technology, 2007(12): 78－81. (in Chinese with English abstract)
[4]	李隆先. 农网低电压分析及治理[J]. 新疆电力技术，2011(2)：27－30.Li Longxian. Analysis and treatment of low voltage in rural power network[J]. Xinjiang Electric Power Technology, 2011(2): 27－30. (in Chinese with English abstract)
[5]	陈芳，李儒，吴珊珊. 浅谈有载调压变压器在电力系统中的应用[J]. 广东电力，1999，12(4)：62－63.Chen Fang, Li Ru, Wu Shanshan. Application of on-load voltage regulating transformers in electric power system[J]. Guangdong Electric Power, 1999, 12(4): 62－63. (in Chinese with English abstract)
[6]	刘家军，刘栋，姚李孝，等. 农网低电压治理的三级联调方式研究[J]. 西安理工大学学报，2011，1(27)：423－429.Liu Jiajun, Liu Dong, Yao Lixiao, et al. Research on Three Order Voltage Regulation of Rural Power Grid Low-Voltage Controlling[J].Journal of Xi'an University of Technology, 2011, 1(27): 423－429. (in Chinese with English abstract)
[7]	朴在林，祁贺，张志霞，等. 单相配电变压器三线集束导线两火一零供电模式的实施与展望[J]. 中国电力，2003，36(10)：61－64.Piao Zailin, Qi He, Zhang Zhixia, et al. Implementation and prospects of a new low-voltage power supply mode based on single-phase distribution transformer connected to the loads by Bundle Insulation Conductors consisted of two lines and one neutral[J]. Electric Power, 2003, 36(10): 61－64. (in Chinese with English abstract)
[8]	施玉祥，陶晓农. 中低压变电站无功调节的研究[J]. 电力系统自动化，1996，20(9)：54－57.Shi Yuxiang, Tao Xiaonong. Automatic voltage controller and its application to substation[J]. Automation of Electric Power Systems, 1996, 20(9): 54－57. (in Chinese with English abstract)
[9]	黄娟娟，康义，陈凌云. 南方电网无功补偿配置原则与标准探讨[J]. 中国电力，2013，46(3)：43－46.Huang Juanjuan, Kang Yi, Chen Lingyun. Discussion on technical principles and standard for configuring reactive power compensation equipment of china southern power grid[J]. Electric Power, 2013, 46(3): 43－46. (in Chinese with English abstract)
[10]	国家电网公司. 农网"十一五"电压质量和无功电力规划刚要[R]. 北京：国家电网公司，2006.State Grid Corporation of China. "Eleven, five" voltage quality and reactive power planning outline of rural power network[R]. Beijing:State Grid Corporation of China, 2006. (in Chinese with English abstract)
[11]	朴在林，谭东明，郭丹. 农村配电网10 KV线路无功优化智能系统的研究与实施[J]. 农业工程学报，2009，25(12)：206－210.Piao Zailin, Tan Dongming, Guo Dan. Research and implementation on reactive power optimization intelligent system for 10 KV distribution[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2009, 25(12): 206－210. (in Chinese with English abstract)
[12]	胡采娥，杨仁刚. 用电力系统分区方法确定无功源最佳配置地点[J]. 电力系统及其自动化学报，2004，11(3)：46－49.Hu Cai'e, Yang Rengang. Optimal allocation of reactive power sources using network partitioning[J]. Proceedings of Electric Power System and Automation, 2004, 11(3): 46－49. (in Chinese with English abstract)
[13]	孟晓芳，朴在林，解东光. 分布式电源在农村电力网中的优化配置方法[J]. 农业工程学报，2010，26(8)：243－247.Meng Xiaofang, Piao Zailin, Xie Dongguang. Distributed generation optimal placing approach in rural power network[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2010, 26(8): 243－247. (in Chinese with English abstract)
[14]	Gopalakrishnan V, Thirunavukkarasu P, Prasanna R. Reactivepower planning using hybrid evolutionary programming method[M]. IEEE Transactions on Power Electronics, 2004.
[15]	李亚男，张粒子，杨以涵. 考虑电压约束裕度的无功优化及其内点解法[J]. 中国电机工程学报，2001，21(9)：1－4.Li Yanan, Zhang Lizi, Yang Yihan. Reactive power optimisation under voltage constraints margin[J]. Proceedings of the CSEE, 2001, 21(9): 1－4. (in Chinese with English abstract)
[16]	张粒子，舒隽，林宪枢，等. 基于遗传算法的无功规划优化[J]. 中国电机工程学报，2000，20(6)：5－8.Zhang Lizi, ShuJun, Lin Xianshu, et al. Reactive power planning based on genetic algorithm[J]. Proceedings of the CSEE, 2000, 20(6): 5－8. (in Chinese with English abstract)
[17]	耿光飞，杨仁刚. 基于定向变异遗传算法的地区电网无功功率优化[J]. 电网技术，2004，28(10)：42－44.Geng Guangfei, Yang Rengang. Reactive power optimization of regional power network by directed mutation based genetic algorthm[J]. Power System Technology, 2004, 28(10): 42－44. (in Chinese with English abstract)
