秸秆炭强化镁镧氧化物对沼液磷的回收效果

马艳茹; 孟海波; 沈玉君; 丁京涛; 周海宾; 张朋月; 朱明; 牛智有; 艾平

doi:10.11975/j.issn.1002-6819.2022.05.023

秸秆炭强化镁镧氧化物对沼液磷的回收效果

1.
华中农业大学工学院，农业农村部长江中下游农业装备重点实验室，武汉 430070
2.
农业农村部规划设计研究院，农业农村部资源循环利用技术与模式重点实验室，北京100125

基金项目: 农业农村部规划设计研究院自主研发项目"畜禽养殖粪水酸化贮存保氮减排关键技术装备熟化与转化（SH202105）"

计量
- 文章访问数: 200
- HTML全文浏览量: 0
- PDF下载量: 2157
出版历程
- 收稿日期: 2021-10-12
- 修回日期: 2022-01-10
- 发布日期: 2022-03-14

Enhanced phosphorus recovery from biogas slurry by biochar of straw with Mg/La oxide

1.
College of Engineering, Huazhong Agricultural University, Key Laboratory of Agricultural Equipment in Mid-lower Yangtze River, Ministry of Agriculture and Rural Affairs, Wuhan 430070, China
2.
Institute of Energy and Environmental Protection, Academy of Agricultural Planning and Engineering, Key Laboratory of Technologies and Models for Cyclic Utilization from Agricultural Resources, Ministry of Agriculture and Rural Affairs, Beijing 100125, China

摘要

摘要: 为回收沼液中的磷元素，前期研究采用了由镁镧金属离子调控合成的层状双金属氢氧化物（Mg/La0.1-LDO）材料，发现其具有丰富的层间离子和纳米粒子，在磷吸附方面体现了优异性能，但材料回收的分散性及原料成本高等因素降低了其应用价值。该研究利用农作物（水稻、玉米）秸秆固定强化Mg/La0.1-LDO，通过共热解法制备了不同温度（400、500和600 ℃）的秸秆炭镁镧双金属氧化物纳米复合材料（BC-LDO），考察不同条件下制备的BC-LDO对沼液磷的回收能力和机理。结果表明，高温（600 ℃）热解更有助于纳米粒子固定在秸秆炭上，秸秆炭强化镁镧氧化物复合材料（6YBC-LDO）含有丰富的介孔和微孔，更易与磷酸盐结合形成LaPO4沉淀和配体交换形成Mg3(PO4)2内球络合物，6YBC-LDO对磷酸盐具有高度选择吸附性并可多次重复利用，能在30 min内回收沼液中90%的磷，饱和吸附量达366.39 mg/g。将该材料应用于沼气工程沼液磷回收处理中，投加2 g/L吸附剂可去除沼液中90%以上的磷酸盐，表明采用6YBC-LDO处理沼液具有良好应用前景。
- 沼液 /
- 秸秆 /
- 炭 /
- 镁镧氧化物 /
- 磷 /
- 回收
Abstract: Phosphorus has been widely used as the essential component in the fertilizer and feed of agriculture, but it is a non-renewable resource. Biogas slurry rich in phosphorus can serve as a recyclable agricultural waste resource. Phosphorus recovery from the biogas slurry can be widely expected to realize nutrient management and utilization, particularly for the green and sustainable development of circular agriculture. Therefore, it is necessary to recover the phosphate from the biogas slurry for sustainable agriculture. Alternatively, adsorption is one of the main technologies in nutrient recovery. Different types of adsorbents have been developed to capture phosphate, including biochar, metal-based materials, minerals, functionalized silica, and various modified wastes. Among them, the layered double oxides (LDO) can often be coupled with the biochar-based materials, which are taken as an adsorbent and as a host substance, due to the multiple parent materials. The introduction of biochar materials can improve the recovery rate of phosphorus in a cost-saving way. More importantly, the biochar-based materials with unique pores and abundant surface functional groups can greatly contribute to the pore structure and surface functional group density of composites, where the ions can be highly concentrated in recycled materials. Herein, a new composite adsorbent of biochar-LDO was proposed to recover the nutrient elements from the biogas slurry using adsorption, in order to effectively recover the phosphorus for better resource utilization. The synthesis temperature of composite material was also evaluated to improve the adsorption performance of phosphorus. It was found that the layered bimetallic oxide (Mg/La0.1-LDO) synthesized by the quantitative control of magnesium and lanthanum presented rich interlayer ions and nanoparticles in the early stage, indicating an excellent performance in the phosphorus adsorption. However, the dispersion of nanomaterials in the solution and the high cost of raw materials relatively reduced the value of material recycling and application. Therefore, the straw of crops (rice and corn) was added to fix and strengthen the Mg/La0.1-LDO, where the biochar-magnesium/lanthanum bimetal oxide nanocomposite (BC-LDO) was prepared for the phosphorus recovery from biogas slurry using the co-pyrolysis at different temperatures (400℃, 500℃ and 600℃). The resulting BC-LDO was then characterized to determine the recovery capacity by the SEM-EDX/TEM/FTIR/XRD techniques. The results showed that the pyrolysis at a high temperature (600 ℃) was more conducive to the fixation of nanoparticles on the straw biochar (6YBC-LDO), which was rich in meso- and micro-porous materials. The particle size of the nanocomposite decreased significantly (between 12 and 20 nm), with the increase in pyrolysis temperature. These nanocomposites were also easier to combine with the phosphate to form LaPO4 precipitation and Mg3(PO4)2 inner-sphere complexation. According to the Langmuir equation, the maximum phosphate uptake of 6YBC-LDO was estimated to be 366.39 mg/g, which was significantly higher than that of 5YBC-LDO and 4YBC-LDO. The kinetic investigation showed that the 6YBC-LDO effectively adsorbed the high phosphorus (69 mg/g) within 30 min, and strongly enriched the straw biochar, indicating an excellent phosphate adsorbent. The 6YBC-Mg/La0.1-LDO presented a high selective adsorption capacity for the phosphate, which was reused many times after desorption. The 6YBC-LDO rapidly removed more than 90% phosphate in the biogas slurry, where the phosphate concentration was reduced to less than 8.25 mg/L within 1 h. Consequently, the 6YBC-LDO has an excellent application prospect in the nutrient recovery from the biogas slurry.
- biogas slurry /
- straw /
- biochar /
- magnesium lanthanum oxide /
- phosphorus /
- recovery

HTML全文

参考文献(32)

[1]	肖华，徐杏，周昕，等. 膜技术在沼气工程沼液减量化处理中的应用[J]. 农业工程学报，2020，36(14)：226-236.Xiao Hua, Xu Xing, Zhou Xin, et al. Application of membrane technology for volume reduction of biogas slurry[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2020, 36(14): 226-236. (in Chinese with English abstract)
[2]	Jiang D, Chu B, Amano Y, et al. Removal and recovery of phosphate from water by Mg-laden biochar: Batch and column studies[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2018, 558: 429-437.
[3]	马艳茹，丁京涛，赵立欣，等. 沼液中氮的回收利用技术研究进展[J]. 环境污染与防治，2018，40(3)：339-344.Ma Yanru, Ding Jingtao, Zhao Lixin, et al. Advances in recycling reuse of nitrogen from biogas slurry[J]. Environmental Pollution and Control, 2018, 40(3): 339-344. (in Chinese with English abstract)
[4]	Everaert M, Slenders K, Dox K, et al. The isotopic exchangeability of phosphate in Mg-Al layered double hydroxides[J]. J Colloid Interface Sci, 2018, 520: 25-32.
[5]	Kong L, Tian Y, Pang Z, et al. Needle-like Mg-La bimetal oxide nanocomposites derived from periclase and lanthanum for cost-effective phosphate and fluoride removal: Characterization, performance and mechanism[J]. Chemical Engineering Journal, 2020, 382: 122963.
[6]	Dox K, Everaert M, Merckx R, et al. Optimization of phosphate recovery from urine by layered double hydroxides[J]. Sci Total Environ, 2019, 682: 437-446.
[7]	Zhang S, Jiao Q, Wang C, et al. In situ synthesis of Mg/Fe LDO/carbon nanohelix composites as absorbing materials[J]. Journal of Alloys and Compounds, 2016, 658: 505-512.
[8]	Daud M, Hai A, Banat F, et al. A review on the recent advances, challenges and future aspect of layered double hydroxides (LDH)-Containing hybrids as promising adsorbents for dyes removal [J]. Journal of Molecular Liquids, 2019, 288: 110989
[9]	Qiao W, Bai H, Tang T, et al. Recovery and utilization of phosphorus in wastewater by magnetic Fe3O4/Zn-Al-Fe-La layered double hydroxides(LDHs)[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2019, 577: 118-128.
[10]	Alagha O, Manzar M S, Zubair M, et al. Comparative adsorptive removal of phosphate and nitrate from wastewater using biochar-MgAl LDH nanocomposites: Coexisting anions effect and mechanistic studies[J]. Nanomaterials, 2020, 10(2): 336-355.
[11]	程福龙，聂凡贵，赵嫦欣，等. 生物炭 Mg/Al-LDHs 复合材料对磷的吸附特性及机理[J]. 农业工程学报，2021，37(2)：226-234.Cheng Fulong, Nie Fangui, Zhao Changxin, et al. Phosphorus adsorption characteristics and mechanism of biochar loaded Mg/Al-LDHs composites[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2021, 37(2): 226-234. (in Chinese with English abstract)
[12]	Ahmaruzzaman M. Biochar based nanocomposites for photocatalytic degradation of emerging organic pollutants from water and wastewater[J]. Materials Research Bulletin, 2021, 140: 111262.
[13]	董良杰，李金铭，赵博骏，等. 硝酸改性秸秆水热炭的结构表征及铅吸附机制研究[J]. 农业机械学报，2021，52(5)：267-278.Dong Liangjie, Li Jinming, Zhao Bojun, et al. Structure characterization and Pb(II) adsorption mechanism of nitric acid modified hydrochars from straw[J]. Transactions of the Chinese Society for Agricultural Machinery, 2021, 52(5): 267-278. (in Chinese with English abstract)
[14]	牛文娟，黄金芝，钟菲，等. 不同水热条件对秸秆微波水热碳化产物组成和结构特性影响[J]. 农业工程学报，2019，35(10)：205-213.Niu Wenjuan, Huang Jinzhi, Zhong Fei, et al. Effects of different hydrothermal conditions on compositions and structural characteristics of microwave-assisted hydrothermal carbonization products from crop residues[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2019, 35(10): 205-213. (in Chinese with English abstract)
[15]	Yang F, Zhang S, Sun Y, et al. Assembling biochar with various layered double hydroxides for enhancement of phosphorus recovery[J]. Journal of Hazardous Materials, 2019, 365: 665-673.
[16]	Schneider M, Drenkova-Tuhtan A, Szczerba W, et al. Nanostructured ZnFeZr oxyhydroxide precipitate as efficient phosphate adsorber in waste water: Understanding the role of different material-building-blocks [J]. Environmental Science: Nano, 2017, 4(1): 180-190.
[17]	Hong S P, Yoon H, Lee J, et al. Selective phosphate removal using layered double hydroxide/reduced graphene oxide (LDH/rGO) composite electrode in capacitive deionization[J]. Journal of Colloid and Interface Science, 2020, 564: 1-7.
[18]	霍丽丽，姚宗路，赵立欣，等. 典型农业生物炭理化特性及产品质量评价[J]. 农业工程学报，2019，35(16)：249-257.Huo Lili, Yao Zonglu, Zhao Lixin, et al. Physical and chemical properties and product quality evaluation of biochar from typical agricultural residues[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2019, 35(16): 249-257. (in Chinese with English abstract)
[19]	Ma Y, Shen Y, Meng H, et al. Development of Mg/La-layered double hydroxide nanocomposites and application of recovered phosphorus from modelled biogas slurry[J]. Journal of Material Cycles and Waste Management, 2022, 24(2): 491-505.
[20]	Feng Y, Lu H, Liu Y, et al. Nano-cerium oxide functionalized biochar for phosphate retention: Preparation, optimization and rice paddy application[J]. Chemosphere, 2017, 185: 816-825.
[21]	Hale S E, Alling V, Martinsen V, et al. The sorption and desorption of phosphate-P, ammonium-N and nitrate-N in cacao shell and corn cob biochars[J]. Chemosphere, 2013, 91(11): 1612-1619.
[22]	Liao T, Li T, Su X, et al. La(OH)3-modified magnetic pineapple biochar as novel adsorbents for efficient phosphate removal[J]. Bioresour Technol, 2018, 263: 207-213.
[23]	Koilraj P, Sasaki K. Selective removal of phosphate using La-porous carbon composites from aqueous solutions: Batch and column studies[J]. Chemical Engineering Journal, 2017, 317: 1059-1068.
[24]	Cabral L L, Pereira I C, Perretto F, et al. Adsorption and desorption of phosphate onto chemically and thermochemically pre-activated red ceramic waste: Characteristics, batch studies, and mechanisms [J]. Journal of Environmental Chemical Engineering, 2021, 9(6): 106695.
[25]	闵彬彬，朱宗强，朱义年，等. 桉树遗态Fe/C复合材料表面的磷动态解吸过程研究[J]. 环境污染与防治，2019，41(2)：180-184.Min Binbin, Zhu Zongqiang, Zhu Yinian, et al. The dynamic desorption process of phosphorus on the surface porous biomorph-genetic composite of Fe/C with Eucalyptus wood template[J]. Environmental Pollution and Control, 2019, 41(2): 180-184. (in Chinese with English abstract)
[26]	She Y, Zhang C, Mahardika M A, et al. Pore-scale study of in-situ surfactant flooding with strong oil emulsification in sandstone based on X-ray microtomography[J]. Journal of Industrial and Engineering Chemistry, 2021, 98: 247-261.
[27]	牛聪，陈浩天，李鑫，等. 基于磷去除效果的人工湿地中含活性氧化铝复合基质配比优化[J]. 农业工程学报，2019，35(17)：240-247.Niu Cong, Chen Haotian, Li Xin, et al. Proportional optimization of composite substrates with activated alumina in constructed wetlands considering phosphorus removal of sewage[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2019, 35(17): 240-247. (in Chinese with English abstract)
[28]	Wang F, Ta N, Li Y, et al. La(OH)3 and La2O2CO3 nanorod catalysts for Claisen‐Schmidt condensation[J]. Chinese Journal of Catalysis, 2014, 35(3): 437-443.
[29]	Kong L, Tian Y, Pang Z, et al. Synchronous phosphate and fluoride removal from water by 3D rice-like lanthanum-doped La@MgAl nanocomposites[J]. Chemical Engineering Journal, 2019, 371: 893-902.
[30]	Zhang Z, Yan L, Yu H, et al. Adsorption of phosphate from aqueous solution by vegetable biochar/layered double oxides: Fast removal and mechanistic studies [J]. Bioresour Technol, 2019, 284: 65-71.
[31]	王丽沙，郝瑞霞，李嘉雯，等. 载磷Mg/Al/Fe-LDO的微波辅助溶剂解吸方法特性[J]. 环境科学学报，2019，39(4)：1211-1219.Wang Lisha, Hao Ruixia, Li Jiawen, et al. Characteristics of microwave assisted solvent desorption for phosphorus- adsorbed Mg/Al/Fe-LDO[J]. Acta Science Circumstantiae, 2019, 39(4): 1211-1219. (in Chinese with English abstract)
[32]	王卫东，郝瑞霞，朱晓霞，等. 磷吸附剂Mg/Al-LDO的再生方法及机制[J]. 中国环境科学，2017，37(6)：2092-2099.Wang Weidong, Hao Ruixia, Zhu Xiaoxia, et al. Regeneration method and mechanism of phosphrous adsorbent Mg/Al-LDO[J]. China Environmental Science, 2017, 37(6): 2092-2099. (in Chinese with English abstract)
