不同水热条件对秸秆微波水热碳化产物组成和结构特性影响

牛文娟; 黄金芝; 钟菲; 张诗麟; 孟令凯; 朱彤; 袁巧霞

doi:10.11975/j.issn.1002-6819.2019.10.026

不同水热条件对秸秆微波水热碳化产物组成和结构特性影响

1.
农业农村部长江中下游农业装备重点实验室，华中农业大学工学院，武汉 430070
2.
湖北工程学院化学与材料科学学院，孝感 432000

基金项目: 国家自然科学基金（No. 31701310）；中央高校基本科研业务费专项（No. 2662015QD009）

计量
- 文章访问数: 875
- HTML全文浏览量: 0
- PDF下载量: 533
出版历程
- 收稿日期: 2018-10-07
- 修回日期: 2019-04-18
- 发布日期: 2019-05-14

Effects of different hydrothermal conditions on compositions and structural characteristics of microwave-assisted hydrothermal carbonization products from crop residues

1.
Key Laboratory of Agricultural Equipment in Mid-lower Yangtze River, Ministry of Agriculture, College of Engineering, Huazhong Agricultural University, Wuhan 430070, China
2.
College of Chemistry and Materials Science, Hubei Engineering University, Xiaogan 432000, China

摘要

摘要: 为了解秸秆微波水热碳化过程中产物形成机制及其理化结构演变规律，该文采用控制变量法进行了单因素试验设计，研究了水热温度、停留时间、催化剂和原料种类对秸秆微波水热产物组成和结构特性的影响。结果表明，随着水热温度升高和停留时间延长，液相产物的pH值先降低后增加，最低值为3.13，电导率和PO43(-P质量浓度先增加后下降，最大值分别为9.38 mS/cm和308 mg/L，NH4+-N质量浓度增加，260 ℃最大值为155 mg/L，而水热焦的产率、H/C和O/C下降，固定碳、C、高位热值增加。高温和长停留时间使水热焦生成较多纳米碳微球结构，且使其O-H键先增多后减少。高温和K2CO3使水热焦的芳香烃结构和C=O、C-O含氧官能团增强，而长停留时间使其先增强后减弱。高温和长停留时间使水热焦的比表面积、孔体积和孔径均先增加后降低，而K2CO3使水热焦的纳米碳微球和比表面积增加，最大比表面积为10.975 9 m2/g。玉米秆、水稻秆和油菜秆水热焦的纳米碳微球结构最明显，棉花秆水热焦的比表面积和孔体积最大。
- 秸秆 /
- 温度 /
- 微波水热 /
- 水热焦 /
- 停留时间 /
- 结构特征
Abstract: Abstract: It is important to fully understand the formation mechanism and the physicochemical characteristics evolution of the microwave-assisted hydrothermal products from crop residues, which is also of great significance for high added value utilization of crop residues and quality control of hydrothermal products. The control variable method was used to design the single factor experiment. The effects of hydrothermal temperature, retention time, catalyst and crop residue types on the compositions and structural characteristics of the microwave-assisted hydrothermal products from rice straw, corn stover, rape stalk and cotton stalk were studied. The results showed that with the increase of hydrothermal temperature and retention time, the pH value of the liquid products decreased first and then increased, reaching the lowest value of 3.13, while the electrical conductivity and PO43(-P concentration of the liquid products increased first and then decreased, and the NH4+-N concentration of the liquid products increased and reached the highest concentration of 155 mg/L at 260 ℃. With the increase of hydrothermal temperature and retention time, the yields, H/C and O/C of hydrothermal cokes decreased, while the fixed carbon, C and higher heating value (HHV) of hydrothermal cokes increased. The addition of alkaline catalyst of K2CO3 decreased the C content, HHV value, carbon conversion rate and energy conversion rate of hydrothermal cokes from crop residues, while increased the O/C content of hydrothermal cokes. The carbon conversion rates and energy conversion rates of hydrothermal cokes from crop residue can reach 56.65%-98.13% and 58.22%-92.19%, respectively. With the increase of hydrothermal temperature and retention time, the fragmentation degree in the surface and interior of hydrothermal cokes of the four crop residues were getting more seriously, and the surface and interior of hydrothermal cokes exhibited more nano carbon microsphere structures, while the O-H bond of the hydrothermal cokes of the four crop residues increased first and then decreased. Higher hydrothermal temperature increased the aromatic hydrocarbon structures of C=C, C-H, C-C and active oxygen functional groups of C=O and C-O of hydrothermal cokes, while the aromatic hydrocarbon structures and active oxygen functional groups of hydrothermal cokes increased first and then decreased with the increase of retention time. With the increase of hydrothermal temperature and retention time, the specific surface area, pore volume and pore diameter of hydrothermal cokes from crop residue increased first and then decreased. The addition of alkaline catalyst of K2CO3 increased the aromatic hydrocarbon structures, active oxygen functional groups, specific surface area, pore volume and pore diameter of hydrothermal cokes from crop residue. Comparing the four types of hydrothermal cokes from crop residues, the yields of hydrothermal cokes from cotton stalk and rice straw were higher, and the contents of C, H, volatile matter and the higher heating value of hydrothermal coke from rape stalk were the highest. The nano carbon microsphere structures of hydrothermal cokes from corn stover, rice straw and rape stalk were relatively obvious. Comparing the hydrothermal cokes from the other three types of crop residues, the specific surface area and pore volume of hydrothermal coke from cotton stalk were the largest, while the pore diameter was the smallest.
- straw /
- temperature /
- microwave-assisted hydrothermal /
- hydrothermal coke /
- retention time /
- structural characteristic

HTML全文

参考文献(30)

[1]	Nizamuddin Sabzoi, Siddiqui Muhammad Tahir Hussain, Baloch Humair Ahmed, et al. Upgradation of chemical, fuel, thermal, and structural properties of rice husk through microwave-assisted hydrothermal carbonization[J]. Environmental Science and Pollution Research, 2018, 25: 17529－17539.
[2]	Liu Chong, Zhao Qing, Lin Yechun, et al. Characterization of aqueous products obtained from hydrothermal liquefaction of rice straw: Focus on product comparison via microwave-assisted and conventional heating[J]. Energy Fuels, 2018, 32: 510－516.
[3]	Zhang Junting, An Ying, Borrion Aiduan, et al. Process characteristics for microwave assisted hydrothermal carbonization of cellulose[J]. Bioresource Technology, 2018, 259: 91－98.
[4]	Dai Leilei, He Chao, Wang Yunpu, et al. Hydrothermal pretreatment of bamboo sawdust using microwave irradiation[J]. Bioresource Technology, 2018, 247: 234－241.
[5]	Kumar Mayank, Oyedun Adetoyese Olajire, Kumar Amit. A review on the current status of various hydrothermal technologies on biomass feedstock[J]. Renewable & Sustainable Energy Reviews, 2018, 81: 1742－1770.
[6]	Zhao Peitao, Shen Yafei, Ge Shifu, et al. Clean solid biofuel production from high moisture content waste biomass employing hydrothermal treatment[J]. Applied Energy, 2014, 131: 345－367.
[7]	Wu Ke, Gao Ying, Zhu Guangkuo, et al. Characterization of dairy manure hydrochar and aqueous phase products generated by hydrothermal carbonization at different temperatures[J]. Journal of Analytical and Applied Pyrolysis, 2017, 127: 335－342.
[8]	He Xinyan, Liu Zhaoxia, Niu Wenjuan, et al. Effects of pyrolysis temperature on the physicochemical properties of gas and biochar obtained from pyrolysis of crop residues[J]. Energy, 2018, 143: 746－756.
[9]	Zhu Zhangbing, Si Buchun, Lu Jianwen, et al. Elemental migration and characterization of products during hydrothermal liquefaction of cornstalk[J]. Bioresource Technology, 2017, 243: 9－16.
[10]	Toor Saqib Sohail, Rosendahl Lasse, Rudolf Andreas. Hydrothermal liquefaction of biomass: A review of subcritical water technologies[J]. Energy, 2011, 36: 2328－2342.
[11]	Zhai Yunbo, Peng Chuan, Xu Bibo, et al. Hydrothermal carbonisation of sewage sludge for char production with different waste biomass: Effects of reaction temperature and energy recycling[J]. Energy, 2017, 127: 167－174.
[12]	Gao Ying, Liu Yinghui, Zhu Guangkuo, et al. Microwave-assisted hydrothermal carbonization of dairy manure: Chemical and structural properties of the products[J]. Energy, 2018, 165: 662－672.
[13]	梁丰. 催化剂对炭化反应产物性质的影响[D]. 北京：中国农业大学，2014.Liang Feng. Influences of Catalysts on Properties of Carbonization Reaction Products[D]. Beijing: China Agricultural University, 2014. (In Chinese with English abstract)
[14]	Kim Daegi, Lee Kwanyong, Park Ki Young. Upgrading the characteristics of biochar from cellulose, lignin, and xylan for solid biofuel production from biomass by hydrothermal carbonization[J]. Journal of Industrial and Engineering Chemistry, 2016, 42: 95－100.
[15]	Niu Wenjuan, Han Lujia, Liu Xian, et al. Twenty-two compositional characterizations and theoretical energy potentials of extensively diversified China's crop residues[J]. Energy, 2016, 100: 238－250.
[16]	Funke Axel. Fate of plant available nutrients during hydrothermal carbonization of digestate[J]. Chemie Ingenieur Technik, 2015, 87: 1713－1719.
[17]	Wu Ke, Zhang Xin, Yuan Qiaoxia. Effects of process parameters on the distribution characteristics of inorganic nutrients from hydrothermal carbonization of cattle manure[J]. Journal of Environmental Management, 2018, 209: 328－335.
[18]	Kruse Andrea, Koch Florian, Stelz Katharina, et al. Fate of nitrogen during hydrothermal carbonization[J]. Energy Fuels, 2016, 30: 8037－8042.
[19]	Wang Tao, Zhai Yunbo, Zhu Yun, et al. Feedwater pH affects phosphorus transformation during hydrothermalcarbonization of sewage sludge[J]. Bioresource Technology, 2017, 245: 182－187.
[20]	Xiao Kangxin, Liu Huan, Li Yang, et al. Correlations between hydrochar properties and chemical constitution of orange peel waste during hydrothermal carbonization[J]. Bioresource Technology, 2018, 265: 432－436.
[21]	Peterson Andrew A, Lachance Russell P, Tester Jefferson W. Kinetic evidence of the maillard reaction in hydrothermal biomass processing: Glucose-glycine interactions in high-temperature, high-pressure water[J]. Industrial & Engineering Chemistry Research, 2010, 49: 2107－2117.
[22]	Reza M Toufiq, Yang Xiaokun, Coronella Charles J , et al. Hydrothermal carbonization (HTC) and pelletization of two arid land plants bagasse for energy densification[J]. Acs Sustainable Chemistry & Engineering, 2016, 4: 1106－1114.
[23]	Liu Fangyan, Yu Ruidong, Guo Minghui. Hydrothermal carbonization of forestry residues: influence of reaction temperature on holocellulose-derived hydrochar properties[J]. Journal of Materials Science, 2017, 52: 1736－1746.
[24]	Reza M Toufiq, Wirth Benjamin, Lueder Ulf, et al. Behavior of selected hydrolyzed and dehydrated products during hydrothermal carbonization of biomass[J]. Bioresource Technology, 2014, 169: 352－361.
[25]	周思邈，韩鲁佳，杨增玲，等. 碳化温度对畜禽粪便水热炭燃烧特性的影响[J]. 农业工程学报，2017，33(23)：233－240.Zhou Simiao, Han Lujia, Yang Zengling, et al. Influence of hydrothermal carbonization temperature on combustion characteristics of livestock and poultry manures[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2017, 33(23): 233－240. (In Chinese with English abstract)
[26]	Peng Chuan, Zhai Yunbo, Zhu Yun, et al. Investigation of the structure and reaction pathway of char obtained from sewage sludge with biomass wastes, using hydrothermal treatment[J]. Journal of Cleaner Production, 2017, 166: 114－123.
[27]	Jain Akshay, Balasubramanian Rajasekhar, Srinivasan M P. Hydrothermal conversion of biomass waste to activated carbon with high porosity: A review[J]. Chemical Engineering Journal, 2016, 283: 789－805.
[28]	Liu Yuxue, Yao Shuai, Wang Yuying, et al. Bio-and hydrochars from rice straw and pig manure: Inter-comparison[J]. Bioresource Technology, 2017, 235: 332－337.
[29]	张进红，林启美，赵小蓉，等. 水热炭化温度和时间对鸡粪生物质炭性质的影响[J]. 农业工程学报，2015，31(24)：239－244.Zhang Jinhong, Lin Qimei, Zhao Xiaorong, et al. Effect of hydrothermal carbonization temperature and time on characteristics of bio-chars from chicken manure[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2015, 31(24): 239－244. (In Chinese with English abstract)
[30]	乔娜. 玉米芯和松子壳的水热碳化及其产物吸附性能研究[D]. 大连：大连理工大学，2015.Qiao Na. Hydrothermal Carbonization of Corncob and Pinenut Shell and the Adsorption Performance of its Product [D]. Dalian: Dalian University of Technology, 2015. (In Chinese with English abstract)
