添加木醋液和生物炭对堆肥重金属钝化的影响

付雪寒; 郭潇君; 刘龙; 周岭

添加木醋液和生物炭对堆肥重金属钝化的影响

付雪寒^1,2,
郭潇君^1,2,
刘龙^1,2,
周岭^1,2,

1. 塔里木大学机械电气化工程学院;
2. 新疆维吾尔自治区教育厅普通高校现代农业工程重点实验室

基金项目:

南疆重点产业创新发展支撑计划项目(2021DB006)

塔里木大学校长基金硕士人才项目(TDZKSS202215)

兵团研究生科研创新项目(TDGRI202244)

详细信息

作者简介:
付雪寒(1995—),女,硕士生,主要从事生物质资源利用研究,E-mail:1549769138@qq.com

通讯作者:
周岭(1972—),女,教授,博士,主要从事生物质资源利用研究,E-mail:zhoul-007@163.com

中图分类号: X705;S141.4
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2023-06-27
- 刊出日期: 2023-11-27

Effect of Humus in Compost with Wood Vinegar Liquid and Biochar Addition on Heavy Metal Passivation

FU Xue-han^1,2,
GUO Xiao-jun^1,2,
LIU Long^1,2,
ZHOU Ling^1,2,

1. College of Mechanical and Electrochemical Engineering, Tarim University;
2. Key Laboratory of Modern Agricultural Engineering for General Colleges and Universities,Department of Education of Xinjiang Uygur Autonomous Region

摘要

摘要: 腐殖质（HS）是有机肥养分质量的重要指标。在堆肥过程中，生物炭和棉秆木醋液的添加会导致堆体内部环境发生变化，但HS的化学性质变化尚不明确。本研究利用火焰原子吸收仪检测了重金属（HMs）(例如Pb、Cr、Cd、Ni)的形态，运用傅里叶变换红外光谱（FTIR）方法和三维激发发射矩阵荧光光谱（3D-EEM）方法以多个角度表征HS与HMs的络合物。同时，采用数理统计、相关性分析和冗余分析（Redundancy analyses, RDA）比较了试验组的腐熟指标（温度、pH值）、腐殖化能力(HS、富里酸（FA）、胡敏酸（HA）、胡敏酸与富里酸之比（H/F）)、官能团等。研究结果显示，木醋液处理能使堆肥腐殖化程度相对较高，且位于波数876～835 cm^-1的峰值明显增强表明芳香结构在不断累积，H/F最终均达到2.3以上。T1处理组生物炭处理的HS含量位于T4和T3处理组之间，H/F最终达到3.67。T1处理组对Cr钝化过程，交换态最终钝化比例至2%。T4处理组在Pb钝化过程中，最终残渣态的比例高达68%。Cd受T4处理组影响较大，最终表现为氧化态分别向交换态、还原态、残渣态转移2%、10%和11%。然而，无论是添加生物炭还是木醋液，对Ni的钝化在堆制过程中均未显示出明显趋势，交换态、还原态、氧化态和残渣态比例分别稳定在1%～2%、5%～7%、26%～35%和56%～68%,说明本次试验HS对Ni的影响较小。FTIR进一步证实了HS作为富含芳香族和羧基的核心农艺功能物质的基本特性。在堆肥过程中，HS的芳香性逐渐增加，从而增强了与Pb、Cr、Cd离子的络合能力。此外，研究确定了质量分数1.75%的木醋液在猪粪基料堆制过程中整体表现较佳。综上所述，木醋液和生物炭存在以下吸附机制：木醋液的特殊功能基团与HMs离子发生络合作用；生物炭与HMs主要依赖吸附作用；Ni在堆肥中的作用机制可能更倾向于与硝酸根离子结合。
- 堆肥 /
- 腐殖质 /
- 重金属 /
- 生物炭 /
- 木醋液 /
- 光谱
Abstract: Humus（HS） is an important indicator of the nutrient quality of organic fertilisers. During the composting process, the addition of biochar and cotton straw wood vinegar liquid leads to changes in the internal environment of the heap, but the changes in the chemical properties of HS are not clear. The morphology of heavy metals（HMs）（e.g. Pb, Cr, Cd, Ni） was detected by flame atomic absorber, and Fourier transform infrared spectroscopy（FTIR） method and three-dimensional excitation-emission matrix fluorescence spectroscopy（3D-EEM） were used to characterise the complexes of HS and HMs from different angles. Meanwhile, mathematical statistics, correlation analysis and redundancy analysis（RDA） were used to compare the decay indices（temperature, pH value）, humification capacity（HS, fulvic acid（FA）, huminic acid（HA）, huminic acid and fulvic acid ratio（H/F）） and functional groups of the test groups. The results of the study showed that the wood vinegar liquid treatment could make the humification of the compost relatively high, and the peak located at 876～835 cm^-1 was significantly enhanced, indicating the accumulation of aromatic structure, and the H/F finally reached more than 2.3 in all cases. The HS content of the T1 biochar treatment was located between T4 and T3, and the H/F finally reached 3.67. The passivation process of Cr by the T1 vs exchange state final passivation proportion to 2%. T4 treatment group in the Pb passivation process, the proportion of the final residue state was as high as 68%. Cd was more affected by T4, and eventually showed the transfer of 2%, 10% and 11% from the oxidation state to the exchange state, reduction state and residue state, respectively. However, the passivation of Ni by the addition of either biochar or wood vinegar liquid did not show any significant trend during the stacking process, and the proportions of exchange, reduced, oxidized and residual states were stable at 1%～2%, 5%～7%, 26%～35% and 56%～68%, respectively, indicating that the effect of HS on Ni was relatively small in this experiment. FTIR further confirmed the role of HS as a core agronomic and carboxylate-rich basic properties of functional substances. The aromaticity of HS was gradually increased during the composting process, which enhanced the complexing ability with Pb, Cr and Cd ions. In addition, it was found that the wood vinegar liquid with a mass fraction of 1.75% performed better overall in the composting process of the pig manure base. In summary, the following adsorption mechanisms existed for wood vinegar liquid and biochar: the special functional groups of wood vinegar liquid complexed with HMs ions; biochar relied mainly on adsorption with HMs; and the mechanism of Ni in composting may be more inclined to bind with nitrate ions.
- compost /
- humus /
- heavy metals /
- biochar /
- wood vinegar liquid /
- spectra

HTML全文

参考文献(28)

[1]	ZHOU Y,XIAO R,KLAMMSTEINER T,et al.Recent trends and advances in composting and vermicomposting technologies:a review[J].Bioresource Technology,2022,360:127591.
[2]	白玲,李倩,邓芸,等.沼渣与餐厨废弃物、牛粪联合堆肥的腐殖化进程研究[J].农业机械学报,2019,50(8):331-338.BAI Ling,LI Qian,DENG Yun,et al.Humification process of biogas residue combined with food waste and cattle manure Co composting[J].Transactions of the Chinese Society for Agricultural Machinery,2019,50(8):331-338.(in Chinese)
[3]	GUO X X,LIU H T,WU S B.Humic substances developed during organic waste composting:formation mechanisms,structural properties,and agronomic functions[J].Sci.Total Environ.,2019,662:501-510.
[4]	ZHANG J,CHEN L,YIN H,et al.Mechanism study of humic acid functional groups for Cr(Ⅵ) retention:two-dimensional FTIR and (13)C CP/MAS NMR correlation spectroscopic analysis[J].Environ.Pollut.,2017,225:86-92.
[5]	YAASHIKAA P R,KUMAR P S,VARJANI S,et al.A critical review on the biochar production techniques,characterization,stability and applications for circular bioeconomy[J].Biotechnol Rep (Amst),2020,28:e00570.
[6]	徐超,袁巧霞,覃翠钠,等.木醋液对牛粪好氧堆肥理化特性与育苗效果的影响[J].农业机械学报,2020,51(4):353-360.XU Chao,YUAN Qiaoxia,QIN Cuina,et al.Effect of wood vinegar on physicochemical properties and seeding capability of cow manure aerobic composting[J].Transactions of the Chinese Society for Agricultural Machinery,2020,51(4):353-360.(in Chinese)
[7]	GUO X X,LIU H T,ZHANG J.The role of biochar in organic waste composting and soil improvement:a review[J].Waste Manag,2020,102:884-899.
[8]	ZHU K,GU S,LIU J,et al.Wood vinegar as a complex growth regulator promotes the growth,yield,and quality of rapeseed[J].Agronomy,2021,11(3):510.
[9]	ZHOU X,SHI A,RENSING C,et al.Wood vinegar facilitated growth and Cd/Zn phytoextraction of Sedum alfredii Hance by improving rhizosphere chemical properties and regulating bacterial community[J].Environmental Pollution,2022,305:119266.
[10]	ZAFAR R,BANG T H,LEE Y K,et al.Change in adsorption behavior of aquatic humic substances on microplastic through biotic and abiotic aging processes[J].Science of the Total Environment,2022,843:157010.
[11]	LIU N,ZHOU J,HAN L,et al.Role and multi-scale characterization of bamboo biochar during poultry manure aerobic composting[J].Bioresour.Technol.,2017,241:190-199.
[12]	LIU H T,GUO H N,GUO X X,et al.Probing changes in humus chemical characteristics in response to biochar addition and varying bulking agents during composting:a holistic multi-evidence-based approach[J].Journal of Environmental Management,2021,300:113736.
[13]	FENG W,XIAO X,LI J,et al.Bioleaching and immobilizing of copper and zinc using endophytes coupled with biochar-hydroxyapatite:bipolar remediation for heavy metals contaminated mining soils[J].Chemosphere,2023,315:137730.
[14]	HONG C O,OWENS V N,KIM Y G,et al.Soil pH effect on phosphate induced cadmium precipitation in Arable soil[J].Bull.Environ.Contam.Toxicol,2014,93(1):101-105.
[15]	GE M,SHEN Y,DING J,et al.New insight into the impact of moisture content and pH on dissolved organic matter and microbial dynamics during cattle manure composting[J].Bioresource Technology,2022,344:126236.
[16]	AYAZ M,STULPINAITE U,FEIZIENE D,et al.Pig manure digestate-derived biochar for soil management and crop cultivation in heavy metals contaminated soil[J].Soil Use and Management,2022,38(2):1307-1321.
[17]	YANG F,TANG C,ANTONIETTI M.Natural and artificial humic substances to manage minerals,ions,water,and soil microorganisms[J].Chemical Society Reviews,2021,50(10):6221-6239.
[18]	SCHMIDT M P,MARTINEZ C E.Supramolecular association impacts biomolecule adsorption onto goethite[J].Environ.Sci.Technol.,2018,52(7):4079-4089.
[19]	HUANG Z,WEI Z,XIAO X,et al.Bio-oxidation of elemental mercury into mercury sulfide and humic acid-bound mercury by sulfate reduction for Hg0 removal in flue gas[J].Environmental Science & Technology,2019,53(21):12923-12934.
[20]	刘翠玲,李佳琮,孙晓荣,等.基于荧光光谱结合宽度学习的白菜农药残留量检测方法[J].农业机械学报,2023,54(10):198-204.LIU Cuiling,LI Jiacong,SUN Xiaorong,et al.Detection of pesticide residues in cabbage based on fluorescence spectroscopy combined with broad learning[J].Transactions of the Chinese Society for Agricultural Machinery,2023,54(10):198-204.(in Chinese)
[21]	TIBU C,ANNANG T Y,SOLOMON N,et al.Effect of the composting process on physicochemical properties and concentration of heavy metals in market waste with additive materials in the Ga West Municipality,Ghana[J].International Journal of Recycling of Organic Waste in Agriculture,2019,8(4):393-403.
[22]	BARTHOD J,RUMPEL C,DIGNAC M F.Composting with additives to improve organic amendments:a review[J].Agronomy for Sustainable Development,2018,38(2):1-23.
[23]	AWASTHI M K,SARSAIYA S,WAINAINA S,et al.A critical review of organic manure biorefinery models toward sustainable circular bioeconomy:technological challenges,advancements,innovations,and future perspectives[J].Renewable and Sustainable Energy Reviews,2019,111:115-131.
[24]	KONG X,LUO G,YAN B,et al.Dissolved organic matter evolution can reflect the maturity of compost:insight into common composting technology and material composition[J].Journal of Environmental Management,2023,326:116747.
[25]	YANG T,HODSON M E.Investigating the potential of synthetic humic-like acid to remove metal ions from contaminated water[J].Science of the Total Environment,2018,635:1036-1046.
[26]	WANG L,LI X,TSANG D C,et al.Green remediation of Cd and Hg contaminated soil using humic acid modified montmorillonite:immobilization performance under accelerated ageing conditions[J].Journal of Hazardous Materials,2020,387:122005.
[27]	GUO H N,WANG L X,LIU H T.Potential mechanisms involving the immobilization of Cd,As and Cr during swine manure composting[J].Scientific Reports,2020,10(1):1-9.
[28]	卓志清,李勇,兴安,等.东北旱作区土壤碳氮磷生态化学计量特征及其影响因素[J].农业机械学报,2019,50(10):259-268,336.ZHUO Zhiqing,LI Yong,XING An,et al.Characteristic of ecological stoichiometry of soil C,N and P and its influencing factors in dry farming region of northeast China[J].Transactions of the Chinese Society for Agricultural Machinery,2019,50(10):259-268,336.(in Chinese)
