移植手防苗损伤技术研究

陈大伟, 李业凯, 初麒, 刘淑梅, 柳甜甜, 辜松

陈大伟, 李业凯, 初麒, 刘淑梅, 柳甜甜, 辜松. 移植手防苗损伤技术研究[J]. 现代农业装备, 2020, 41(4): 22-26,38.
引用本文: 陈大伟, 李业凯, 初麒, 刘淑梅, 柳甜甜, 辜松. 移植手防苗损伤技术研究[J]. 现代农业装备, 2020, 41(4): 22-26,38.
CHEN Da-wei, LI Ye-kai, CHU Qi, LIU Shu-mei, LIU Tian-tian, GU Song. Study on Preventing Transplanting Manipulator from Damaging Seedlings[J]. Modern Agricultural Equipment, 2020, 41(4): 22-26,38.
Citation: CHEN Da-wei, LI Ye-kai, CHU Qi, LIU Shu-mei, LIU Tian-tian, GU Song. Study on Preventing Transplanting Manipulator from Damaging Seedlings[J]. Modern Agricultural Equipment, 2020, 41(4): 22-26,38.

移植手防苗损伤技术研究

基金项目:

山东省重点扶持区域引进急缺人才项目(2019YF0010)

详细信息
    作者简介:

    陈大伟(1982—),男,中级经济师,主要从事农业机器人设计研究

    通讯作者:

    辜松(1963—),男,博士,教授,主要从事现代园艺生产装备的研究。E-mail:sgu666@sina.com

  • 中图分类号: S223.9

Study on Preventing Transplanting Manipulator from Damaging Seedlings

  • 摘要: 移植手抓取种苗时,从种苗正上方直接下移至抓取位置易造成高株种苗受压破损,采取先在种苗侧方下移到作业高度再水平运动到抓取位置的运动轨迹可避免该情况发生,进而降低移植手对种苗的株高要求。但移植手水平运动至作业位置过程中,易与种苗伸展开的枝叶发生碰撞,导致枝叶折断,针对这一问题,设计一种可利用正压气流对种苗枝叶进行导向,进而防苗损伤的四齿伸缩式移植手。通过对正压气流管路的流体仿真分析,确定正压气流管路为2条,中心距离为15 mm。以红掌为移植对象,进行了移植手防苗损伤作业性能正交试验,确定移植手作业参数。即正压气流管路进口压力为0.4 MPa、管路内径为8 mm、移植手水平移动速度为0.04 m/s时,移植手对红掌种苗防损伤成功率为98%。
    Abstract: When the transplanting manipulator grabs the seedlings,moving directly from the top of the seedlings to the grabbing position will easily cause damage to the tall seedlings.The problem can be avoided by transplanting manipulator moving down to the working height from seedling side and then horizontally moving to the grab position,this method can reduce the plant height requirements for transplantation.However,during the movement of the transplanting manipulator to the working position,it is easy to collide with the seedlings,resulting in damage to the seedlings.Aiming at this problem,this paper designs a four-tooth telescopic transplanting manipulator that can use positive pressure air flow to guide seedlings and prevent damage to seedlings,Through the fluid simulation analysis of the positive pressure airflow pipeline,it is determined that two positive pressure airflow pipelines are required,and the center distance is 15 mm.An orthogonal experimental to avoid transplanting manipulator damaging seedlings was carried out,experimental results showed that when the positive pressure air flow pipeline inlet pressure was 0.4 MPa,the pipeline inner diameter was 8 mm,and the transplanting manipulator horizontal moving speed was 0.04 m/s.The success rate of preventing anthurium seedlings damage was 98%.
  • [1] 岳建魁,郭俊先,梁佳,等.国内外移植机械发展现状[J].新疆农机化,2016(5):30-32,36.
    [2] 辜松.设施园艺现代生产装备与技术[M].北京:中国农业出版社,2015:1-2.
    [3] 辜松.设施园艺装备化作业生产现状及发展建议[J].农业工程技术,2018,38(4):10-15.
    [4] 张跃峰,杨艳丽,初麒,等.设施园艺种苗生产装备系统[J].农机化研究,2018,40(10):257-261.
    [5] 金三林,朱贤强.我国劳动力成本上升的成因及趋势[J].经济纵横,2013,154(2):37-42.
    [6] 黎波,辜松,初麒,等.椰糠培育叶菜种苗移植机械手设计与试验[J].农业工程学报,2017,33(14):18-24.
    [7] 辜松,杨艳丽,张跃峰.荷兰温室盆花自动化生产装备系统的发展现状[J].农业工程学报,2012,28(19):1-8.
    [8]

    KUTZ L J,MILES G E,HAMMER P A,et al.Robotic transplanting of bedding plants[J].Transac-tions of ASAE,1987,30(3):586-590.

    [9] 蒋焕煜,施经挥,任烨,等.机器视觉在幼苗自动移钵作业中的应用[J].农业工程学报,2009,25(5):127-131.
    [10] 韩绿化,毛罕平,胡建平,等.温室穴盘苗自动移栽机设计与试验[J].农业机械学报,2016,47(11):59-67.
    [11] 蒋卓华,蒋焕煜,童俊华.穴盘苗自动移栽机末端执行器的优化设计[J].浙江大学学报(工学版),2017,51(6):1119-1125.
    [12] 高国华,冯天翔,李福.斜入式穴盘苗移栽手爪工作参数优化及试验验证[J].农业工程学报,2015,31(24):16-22.
    [13] 张丽华,邱立春,田素博,等.指针夹紧式穴盘苗移栽爪设计[J].沈阳农业大学学报,2010,41(2):235-237.
